TPS51125 Buck Controller Evaluation Module User's
Guide
1
Introduction.............................................................................................................................................................................2
2 Performance Specification Summary...................................................................................................................................
3
Schematic................................................................................................................................................................................3
4 Test Setup and Results..........................................................................................................................................................
5 Configuration..........................................................................................................................................................................
6 Physical Layouts....................................................................................................................................................................
Materials.....................................................................................................................................................................10
8
References.............................................................................................................................................................................11
History....................................................................................................................................................................11
Trademarks
Out-of-Audio
and D-CAP
All trademarks are the property of their respective owners.
SLUU311B - APRIL 2008 - REVISED JANUARY 2022
Submit Document Feedback

Table of Contents

are trademarks of Texas Instruments.
Copyright © 2022 Texas Instruments Incorporated
TPS51125 Buck Controller Evaluation Module User's Guide
Table of Contents
2
4
6
7
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPS51125 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Texas Instruments TPS51125

  • Page 1: Table Of Contents

    D-CAP are trademarks of Texas Instruments. All trademarks are the property of their respective owners. SLUU311B – APRIL 2008 – REVISED JANUARY 2022 TPS51125 Buck Controller Evaluation Module User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 2: Introduction

    1 Introduction The TPS51125 is a cost-effective, dual-synchronous buck controller targeted for notebook system power supply solutions. It provides 5-V and 3.3-V LDOs and requires few external components. The 270-kHz VCLK output can be used to drive an external charge pump, generating gate drive voltage for the load switches without reducing the efficiency of the main converter.
  • Page 3: Schematic

    Schematic 3 Schematic Figure 3-1. TPS51125-EVM Schematic Diagram SLUU311B – APRIL 2008 – REVISED JANUARY 2022 TPS51125 Buck Controller Evaluation Module User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 4: Test Setup And Results

    6. When SW3 stays on and turn on SW1 (ENTRIP1), CH1-output starts up. 7. When SW3 stays on and turn on SW2 (ENTRIP2), CH2-output starts up. TPS51125 Buck Controller Evaluation Module User's Guide SLUU311B – APRIL 2008 – REVISED JANUARY 2022 Submit Document Feedback Copyright ©...
  • Page 5 Figure 4-2. 5-V Start-Up Waveforms Figure 4-5. 3.3-V Load Transient Response Figure 4-4. 5-V Load Transient Response SLUU311B – APRIL 2008 – REVISED JANUARY 2022 TPS51125 Buck Controller Evaluation Module User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 6: Configuration

    Table 5-3. VLCK Control END CONNECTION VCLK OPEN ENABLED Pull down to GND with 620 kΩ DISABLED TPS51125 Buck Controller Evaluation Module User's Guide SLUU311B – APRIL 2008 – REVISED JANUARY 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 7: Physical Layouts

    6-2), and inner layer views (Figure 6-3 Figure 6-4) of the EVM. Figure 6-1. Top Layer Routing SLUU311B – APRIL 2008 – REVISED JANUARY 2022 TPS51125 Buck Controller Evaluation Module User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 8 Physical Layouts www.ti.com Figure 6-2. Bottom Layer Routing Figure 6-3. Inner Layer 1 TPS51125 Buck Controller Evaluation Module User's Guide SLUU311B – APRIL 2008 – REVISED JANUARY 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 9 Physical Layouts Figure 6-4. Inner Layer 2 SLUU311B – APRIL 2008 – REVISED JANUARY 2022 TPS51125 Buck Controller Evaluation Module User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 10: List Of Materials

    0.100 × 0.200 Shunt, 2POs, gold Molex 15-29-1025 inch Standoff M/F hex 4-40 nylon 0.625 in Keystone 4803 TPS51125 Buck Controller Evaluation Module User's Guide SLUU311B – APRIL 2008 – REVISED JANUARY 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 11: References

    References Table 7-1. TPS51125 List of Materials (continued) RERERENCE DESCRIPTION SIZE PART NUMBER DESIGNATOR Building Nut hex 4-40 nylon NY HN 440 Fasteners 8 References Texas Instruments, TPS51125 Dual-Synchronous Buck Controller data sheet 9 Revision History NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
