heat-timer DiGi-SPAN Elite Series Installation And Operation Instruction Manual page 12

RSM Specifications
Voltage Input: . . . . . . 120 VAC 60 Hz(2 Black wires) /24VAC 60 Hz (24VAC terminals) (Only One Power Source)
Power Consumption:
Operating Temperature: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20°F to 120°F
Operating Humidity: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20% to 80%
Dimensions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4"W x 4"H x 2½"
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pound
Display: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Lite 2 Line Alphanumeric LCD Display
Display Units: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fahrenheit (ºF) and Celsius (ºC)
Outputs: . . 3 S.P.S.T (Yellow = System Pump.), (White = Open MOV.), (Blue = Close MOV), (Red = Common MOV)
Output Relay Ratings: . . . . . . . . . . . . 1 Amp inductive (Maximum of 1/8 HP), 6Amp resistive at 120 VAC 60 Hz
Curve: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . from -10 to +10
Slab ΔT: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5˚F (3˚C) To 50˚F (28˚C)
Maximum Temperature: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . from 70˚F (21˚C) to 180˚F (82˚C)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . from 20˚F (-7˚C) to 50˚F (10˚C), On, Off
Outdoor Cutoff:
Pump Run-On: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . from 0 to 60 minutes
Valve Mode: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Auto, Close , Open
gain: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . from -10 to +10
LED: . . . . . . . . . . . . . . . . 3 representing the Output relays (Left=Close, Middle=Open, Right=System Pump)
Inputs: . . . . . . . . . . 3 Temperature Sensors (Slab Supply, Slab Return, and Outdoor), and Enable/Disable input
Buttons: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 (Set, Up, Down)
Enable/Disable: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Terminals EXT+, EXT-
C O R P O R A T I O N
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 VA Max
R
20 New Dutch Lane, Fairfield, NJ 07004 973-575-4004 • Fax 973-575-4052 • http://www.heat-timer.com
12
HT #059091-00 A
