Ardo WDE 1207X Quick Start Manual

MAIN FUNCTIONS OF THE WASHING MACHINE
A
WASHING MACHINE OPERATION
(follow these instructions and the washing machine will run the selected wash cycle)
Load the washing machine, add the detergent and softener (see "Detergent drawer") using
the manufacturer's recommended doses reported on the packet. Check that the machine
is plugged into the mains socket, that the door is closed, the water feed valve is open and
that the ON/OFF button is pressed.
Rotate the programmer knob to select the required program and temperature according to
the type of fabric to wash (see program table).
Rotate the timer knob to set the required drying time.
When setting the drying time, the "drying" led will stay lit until the "Start" button is pressed,
at which time it switches off and the machine starts the wash cycle.
The figure alongside shows the main functions of a wash cycle:
WASH, RINSES, SPIN, END.
During the cycle, each of these functions is highlighted by a led informing the user what
0'
Prelavaggio/
25' 150'
Lavaggio
the washing machine is doing at that moment. After the spin phase, the corresponding led
40' 130'
Risciacqui
60' 120'
Centrifuga will stay lit for approximately 2 minutes; this is the time lapse necessary before the door
70' 110' Asciugatura
can be opened. At this point the "END" led will light up.
End
80' 100'
Fine
90'
The DRY function led lights up while the drying time is being set and flashes during the final
ten minutes (cooling) of the drying phase..
1.
1
2.
2
3.
3
DESCRIPTION OF THE FUNCTION BUTTONS
START BUTTON:
After selecting the required programme, press this button to start the wash cycle Button (L) will light
up to indicate the wash cycle has started.
PREWASH:
Press this button and the machine will perform a prewash at the maximum temperature of 40°C.
This function can only be used on the "COTTON" and "SYNTHETICS" programmes.
N.B. When this option is used, the detergent must also be added to the appropriate prewash
compartment..
MODELLO: WDE 1207X
C L H
S
0'
25' 150'
Start
40' 130'
60' 120'
Prelavaggio
70' 110'
Risciacqui
80' 100'
supplementari
90'
USING THE APPLIANCE
Pre-wash detergent com-partment
Wash detergent compartment
Softener and other additives
G
P
Scarico e
COTONE
centrifuga Stop
Risciacqui
90
75
Lavaggio
Prelavaggio/
rapido 40 60
Lavaggio
Risciacqui Asciugatura 40
Centrifuga 30
°C
30 60
Asciugatura
End 40 50
Fine
40
I
LANA
30 30
40
O
SINTETICI
DELICATI
N.B. When using a liquid detergent
(recommended for programs without pre-wash), use the special
container (if provided) and follow the manufacturer's instructions.
Remember to remove the liquid detergent container when
using soap powder.
SM1505
A Programme table
C Optional function buttons
G On/Off button
Timer knob
H
L Start button
P Programme and temperature knob
S Programme status led
5
GB
