Hardware Explanations
1 Plug the adapter into the DCIN port, and press the power switch.
2 The power LED will light up when your hardware is ready.
Button and Port Explanations
LAN ports 1-2
2.5G / 1G WAN port
2.5G / 1G LAN port
2.5G / 1G WAN port
Connect your optical modem to this port with a network cable.
LAN ports 1-2
Connect your PC to a LAN port with a network cable.
2.5G / 1G LAN port
Connect your PC to a 2.5G / 1G LAN port with a network cable.

Specifications:

DC Power adapter
Operating Temperature
Operating Humidity
APAC19130_ZenWiFi_Pro_XT12_2PK_booklet_QSG.indb 3 APAC19130_ZenWiFi_Pro_XT12_2PK_booklet_QSG.indb 3
DC Output: +19V with max 2.37A current
DC Output: +19.5V with max 2.31A current
0~40 C Storage Temperature
o
50~90% Storage Humidity
WPS button
Reset button
Power switch
DCIN port
0~70 C
o
20~90%
2021/10/26 11:50:26 2021/10/26 11:50:26
3
