Technical Manual
Glass Room Temperature Controller Smart
4.5.3.8
Basic function – Blinds/Shutter
Single-button function
Two- button function
Important:
Basic functions for the single-button function are available for selection if the
function of buttons 1 or 2 is set to "external function"!
The blinds/shutter function is used to control shutter actuators, which can be used for the
adjustment and control of blinds/shutters.
The following figure shows the available settings (here: Two-button function):
Figure 50: Settings – Blinds/Shutter
The following table shows the available settings:
ETS-Text
Button assignment 1/2
Operating function
Table 97: Settings – Blinds/Shutter
Two communication objects are displayed for the "blinds/shutter" function: the object "stop/slats
open/close" and the object "blinds up/down ".The moving object is used to move the
blinds/shutters up and down. The stop/step object is used to adjust the slats. In addition, this
function stops the up/down movement as far as the end position has not yet been reached.
In the case of the two-button function, the button assignment can be set.
The table below shows the relationships:
Input
Moving object
Stop/Step object
Table 98: Functionality – Two-button movement blinds/shutter
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
91
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
Dynamic range
[Default value]
UP/DOWN
▪
DOWN/UP
▪
long=move /
▪
short=stop/slats
open/close
short=move /
▪
long=stop/slats open/close
Function Up/Down
Button 3
Button 4
UP
DOWN
Stop/slats open
Stop/slats close
SCN-RTRGx.02
Comment
Only with two-button function!
Setting the button assignment for
the up/down function.
Setting the concept of how to
operate with long/short buttons.
Function Down/Up
Button 3
DOWN
Stop/slats close
Button 4
UP
Stop/slats open
