- Page 1 12/2011 Technical Manual MDT Shutter Actuator JAL-0206.01 JAL-0410.01 JAL-0810.01 JAL-0410D.01 JAL-0810D.01 JAL-0410A.01 JAL-01UP.01 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 2: Table Of Contents
4.2.1 Measure of the times for Movement ................... 19 4.2.2 Movement time ........................ 20 4.2.3 Step time for blinds ...................... 20 4.2.4 Duration of blind adjustment .................... 20 4.2.5 Pause at change of direction .................... 21 4.2.6 Switch‐on/Switch‐off delay motor .................. 21 4.2.7 Position of blinds at end of driving .................. 21 4.2.8 Short time operation ...................... 21 4.3 Objects for absolute position/ Status objects ................ 22 4.3.1 Driving to reference...................... 23 4.3.2 Commands for absolute positions .................. 23 4.3.3 Status objects (actual position/direction) ................ 23 4.3.4 Report objects ........................ 24 4.3.5 Status objects for Visualization .................... 24 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 3 4.8.3 Periodic observation ...................... 37 4.8.4 Action at reset of alarms/removal .................. 37 4.8.5 Reaction when bus power down/up .................. 38 4.9 Block functions .......................... 39 5 Index .............................. 42 5.1 Register of illustrations ........................ 42 5.2 List of tables.......................... 43 6 Attachment ............................ 44 6.1 Statutory requirements ....................... 44 6.2 Routine disposal .......................... 44 6.3 Assemblage .......................... 44 6.4 Datasheet ............................ 45 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 4: 2 Overview
JAL‐0410A.01 Shutter Actuator 4‐fold, 4TE, 230V AC, 10A, surface installation o 4‐fold, for shutter motors up to 600W JAL‐01UP.01 Shutter Actuator 1‐fold, 230VAC, 6A, flush‐mounted fitting o 1‐fold, for shutter motors up to 300W 2.2 Usage & possible applications The Shutter Actuator actuates shutters as well as blinds. According to the hardware design you can actuate up to eight shutters or jalousie. Every Channel can be adjusted to the corresponding shutter/jalousie by his parameter settings. For every channel you can adjust the travel time and actuate the channel manual as well as by absolute position devices. Furthermore you can restrict the travel area and blinds can be adjusted for jalousie. Every channel can be addicted to block functions and scenes. The automatic function enables the user to approach fixed adjusted positions by using 1‐bit objects. This function appertains excellent to adjust positions for sun protection, which are activated by a light sensor. Additional you can activate weather alerts for every channel, which can cause parameterized functions. Furthermore the MRDC devices dispose over a manual control, which enables the user to actuate the shutters/jalousie by hand. The manual control can be deactivated for each channel. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 5: Exemplary Circuit Diagrams
Technical Manual Shutter actuator JAL‐0X10X.01 2.3 Exemplary Circuit diagrams Illustration 1: exemplary circuit diagram shutter actuator 4‐fold Illustration 2: exemplary circuit diagram shutter actuator 8‐fold MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 6: Structure & Handling
Technical Manual Shutter actuator JAL‐0X10X.01 2.4 Structure & Handling The shutter actuator (MDRC) contains of a programming button as well as a programming‐LED, which shows an activated programming button. The shutter actuator works with 230V AC, only the actuators JAl‐0410D.01 and JAL‐0810D.01 work with 24V DC. Every channel of the MRDC device contains of two status‐LEDs, the first one for an activated run up command and the second one for an activated move down command. By using the four buttons you can activate the hand control. With the buttons left/right you can chose the channel and with the buttons up/down you can move the channel down or up. The shutter actuator for the surface installations consists only of the standard elements like bus connection, power connection, programming button and LED. The following illustration shows an 8‐fold shutter actuator for MDRC: Illustration 3: Overview hardware module (JAL‐0810.01) MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 7: Functions
shutter If you choose a channel as shutter, you have different possibilities to parameterize the moving of the shutters. By using different settings for movement, you can adapt the channel for every shutter. Furthermore you can adjust a pause at change of direction and a switch on delay or a switch off delay for the motor. Also you can restrict the driving area or move the shutter by giving absolutely driving commands. By using scene or automatic functions you can select more shutters with only one driving command. There are also preferences for weather alarms. blinds If you choose a channel as blinds, you have different possibilities to parameterize the moving of the blinds. By using different settings for movement you can adapt the channel for every type of blinds. Furthermore you can adjust a pause at change of direction and a switch on delay or a switch off delay for the motor. Also you can restrict the driving area or move the shutter by giving absolutely driving commands. By using scene or automatic functions you can select more shutters with only one driving command. There are also preferences for weather alarms. The functions for shutter and blinds are basically the same. However, there is no parameter for moving the slats at the blinds. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 8: Overview Functions
drive to former position drive to bottom/top wind alert/ rain alert/ active/not active frost alert cycle time reaction on alert Reaction of bus power no action down/up drive to bottom drive to top MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 9: Starting Up
Order number: addicted to the used type, e.g.: JAL‐0810.01 2.7. Starting up After wiring, the allocation of the physical address and the parameterization of every channel follow: (1) Connect the interface with the bus, e.g. MDT USB interface (2) set bus power up (3) Press the programming button at the device(red programming LED lights) (4) Loading of the physical address out of the ETS‐Software by using the interface(red LED goes out, as well this process was completed successful) (5) Loading of the application, with requested parameterization (6) Switch the power supply on (7) If the device is enabled you can test the requested functions(also possible by using the ETS‐ Software) MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 10: 3 Communication Objects
DPT 1.007 In, Write Stopping the Up/Down movement 2 Stop Stopping running movement DPT 1.017 In, Write 3 Absolute position moves to an absolute position DPT 5.001 In, Write 4 Absolute position of blinds Collimates the blinds to an DPT 5.001 In, Write absolute position Chart 2: global communication objects MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 11: Communication Objects Automatic Function
5 Automatic A Automatic position 1 DPT 1.017 In, Write 6 Automatic A Automatic position 2 DPT 1.017 In, Write 7 Automatic A Automatic position 3 DPT 1.017 In, Write 8 Automatic A Automatic position 4 DPT 1.017 In, Write Chart 3: communication objects automatic function MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 12: Communication Objects Per Channel
Technical Manual Shutter actuator JAL‐0X10X.01 3.4 Communication objects per channel There are 19 numbers for the communication objects reserved for every channel. The numbers follows on the global objects and the objects for the automatic function. Therefore these objects have the numbers from 13. So the channel A has the numbers from 13 to 32 and the channel B from 33 and so on. The numbers for every channel are also reserved if not every object is used or one channel is completely deactivated. The following illustration shows the objects for channel A, which is selected as shutter: Illustration 6: communication objects per channel MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 13 29 Wind alarm Switches the wind alarm on DPT 1.005 In, Write 30 Rain alarm Switches the rain alarm on DPT 1.005 In, Write 31 Frost alarm Switches the frost alarm on DPT 1.005 In, Write 32 Block Blocks the channel DPT 1.003 In, Write Chart 4: Communication objects per channel MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 14: Default Settings Of The Communication Objects
1 Bit Low X X 27 Channel A Block absolute position mode 1 Bit Low X 28 Channel A Block universal mode 1 Bit Low X 29 Channel A Wind alarm 1 Bit Low X MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 15 31 Channel A Frost alarm 1 Bit Low X 32 Channel A Block 1 Bit Low X +20 next channel Chart 5: standard settings communication objects You can see the default values for the communication objects from the upper chart. According to requirements the priority of the particular communication objects as well as the flags can be adjusted by the user. The flags allocates the function of the objects in the programming thereby stands C for communication, R for Read, W for write, T for transmit and U for update. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 16: 4 Reference Ets-Parameter
ETS‐text Dynamic range comment [default value] Channel A‐D/H not active Operating mode of the channel Shutter Blinds Chart 6: possible settings for the channel selection Every of the 1 to 8 available channels can be assigned one of the three available conditions at the tab page “channel selection”. The following parameterization options depend on the selected conditions for the channel. If a channel is set to “not active”, there will be no further parameterization options. If a channel is selected to “shutter” or “blinds”, a new tab page will appear at the left drop‐down menu with the format Channel A: Shutter/Blinds. Trough selection the respective channel you can parameterize the channel according to the individual requirements. The available options for the parameterization depend on the function of the selected channel. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 17 Number Name Length Usage 13 Shutter up/down 1 Bit Movement of the shutter 14 Short time operation 1 Bit starts the short time operation 15 Stop 1 Bit Stopping the shutter movement Chart 8: communication objects blinds The communication object “shutter up/down” is used to move the shutter. Thereby is to consider that a logical “0” starts the up‐movement and a logical “1” starts the down‐movement. The communication object “Stop” is used to stop the current movement of the shutters. The object stop can be called by a logical “0” or “1”. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 18: Time For Movement
Technical Manual Shutter actuator JAL‐0X10X.01 4.2 Time for movement By setting different times for movement the user is able to parameterize the Actuator individually for almost every shutter/blind. To be sure that the movement function works properly, you have to parameterize these times carefully. If the channel is selected as shutter there are additional settings for the moving time of the blinds. You can see the screen for setting these times in the following illustration: Illustration 8: Time for movement Shutter Illustration 9: Time for movement Blinds MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 19: Measure Of The Times For Movement
Time for movement for short 50‐1000ms only at blinds time operation [200ms] adjusts the time for one short time from hardware version 2.2 operation Chart 9: Dynamic range time for movement The functions are described in detail at the following segments. 4.2.1 Measure of the times for Movement The individual times for the movement of shutter/blinds can normally determined very precise by using a stop watch. If there are very short times for the movement, the measuring by using a watch will maybe cause problems. In this case it is advisable to adjust initially an approximated value, which should be a little bit shorter than the real time for movement. Afterwards you can test the adjusted time by triggering the shutters or blinds and control whether the final positions are achieved. If they are not achieved, you should set the time for movement gradually higher by using small steps until the final positions are achieved. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 20: Duration Of Blind Adjustment
Step time for blinds = 300ms Number of steps=10 therefore the values 0%, 10%, …, 100% can be appointed 4.2.4 Duration of blind adjustment only at blinds The duration of blind adjustment sets the interval, which is required to drive the blinds from 0% to 100% or backwards. Therefore the shutter actuator triggers the blind adjustment. Tip for the measurement from very small durations of blind adjustment Drive the blinds in a final position (either 100% closed or 100% opened) Now send step commands until the other final position is achieved Multiply the number of steps with the adjusted time for the step time of blinds Enter the result to the “duration of blind adjustment” It is advisable to use the procedure, like under 4.2.1 described, by long blind adjustment times. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 21: Pause At Change Of Direction
4.2.6 Switch‐on/Switch‐off delay motor Some motors can not bring the full power at the moment of switching it on, but first after some milliseconds. The time, which the motor needs to get the full power, can be balanced with the adjustment of the switch‐on delay of the motor. On the other hand there are motors, which run after it was switched off. This characteristic can be balanced by using the setting switch‐off delay motor. 4.2.7 Position of blinds at end of driving only at blinds By using the adjustment “position of blinds at end of driving“ can be adjusted in which position the blinds shall be set after a down‐ or an up‐movement. The shutter actuator drives automatically to this position after the end of a blind‐movement. The position of blinds at end of driving can be set percentage in 1% steps, from 0% to 100%, whereby 0% full opened and 100% full closed correspond. 4.2.8 Short time operation only at blinds from hardware version 2.2 The short time operation helps you to drive the blinds to a certain position, e.g. for sun protection. With small steps, the blinds can be driven to every possible position. It is often useful to set the short time operation as a multiple of the movement time. So the blinds can be driven from the bottom to the top, or the other way around, in a certain number of steps. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 22: Objects For Absolute Position/ Status Objects
19 absolute position of blinds 1 Byte for adjustment of the blinds to a specific value (only at shutter) 20 Status actual position 1 Byte indicates the actual shutter‐/blinds position 21 Status act. position of 1 Byte indicates the actual position of the blinds (only at blinds shutter) 22 act. position valid 1 Bit indicates whether a driving to reference was already conducted MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 23: Driving To Reference
After every transfer of a new parameterization you have to conduct a reference run. This can either manual occurred, that means the upper and lower position are approached ones, or by the object “start driving to reference”. Now the reference run was conducted and the shutter actuator knows its actual state along the driving range. 4.3.2 Commands for absolute positions By the objects for absolute positions you can specify a constant value to the shutter actuator, on which the shutter shall be driven. This value is indicated in percent and has a range from 0‐100% with every 1% step between it. From the indicated percent value the shutter actuator calculates at the next step the real time for the movement of the shutter/blinds based on the appointed times for movement and the actual position. The commands for the absolute position are transmitted to the 1 byte communication objects. There is an object for the absolute height positions of the driving way at shutter and blinds. Additional there is an object for the opening angle of the blinds at shutters, the object “absolute position of blinds”. At the percentage description corresponds 0% always fully opened and 100% full closed. 4.3.3 Status objects (actual position/direction) The status objects “Status actual position” and “Status act. position of blinds” conduce the visualization of the absolute position. Both objects indicate the actual state of the height and the opening angle of the blinds, respectively after end of driving. The objects can be used e.g. for Visualization. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 24: Report Objects
Technical Manual Shutter actuator JAL‐0X10X.01 4.3.4 Report objects The 1 bit objects „state lower position“ and „state upper position“ will conduct respectively an 1‐ signal, if the lower end position or the upper end position is achieved. The signal of the object changes from 1 to 0, when the end position is left. Both objects are useful for the observation of the shutter/blinds. 4.3.5 Status objects for Visualization The 1 bit status object “Status of movement” shows, that a movement of these shutters/blinds is active right now. A running movement is indicated by a logical “1”. The 1 bit object “Status act. direction” conducts with a logical 0 a running up driving and with a logical 1 a running down driving. The state is respectively displayed, when a movement starts. The state exists intern as long as a new command for driving is sent. The 1 bit object “act. Position valid” will conduct, if a reference run was started after a new programming. This object can be used through a visualization to indicate that there is still a reference run necessary. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 25: Limitation Of Driving Area
Number Name Length Usage 24 Drive to limitation 1 Bit drives to the lower/upper limit Chart 13: communication object limitation You set new limits for the height adjustment to the shutter actuator By the parameter limitation of the driving area. The shutter actuator accepts the new limits thereby as new virtual end positions. If you set for example a new limitation of 40% to the lower limitation, the shutter actor will display the achievement of the lower position through the object “state lower position” as soon as the 40% is reached. The object “actual position” also displays for this height 0% now. By the 1 bit object “drive to limitation”, you can control the up‐ and down‐movement between the appointed limits. Analog to the standard driving commands, also at this object, an 1‐signal starts the up‐movement and an 0‐signal starts the down movement. The normal driving objects „shutter up/down“ still drive to the real end positions. But now the actor notifies already at the achievement of the adjusted limitation 0% respectively 100% for the actual position. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 26: Central Objects
1 Byte absolute command for height at every channel 4 absolute position of blinds 1 Byte absolute command for opening angle of blinds at every channel, which is defined as shutter Chart 15: central communication objects Activating the central objects in selected channels enables the triggering of several channels to the same time with only one command. The object 0 “shutter up/down” is the central driving object and controls as well channels selected as shutter as channels selected as blinds in which the parameter was activated. The object 1 “blinds up/down/stop” controls only channels selected as shutter in which the central function was activated. It drives the blinds and stops a running up‐ or down‐ movement. Object number 2, called “stop”, is the central stop function for every channel. Also object 3 “absolute position” is for shutter‐ and blind‐channels with activated central function. By this object, you can give the actor absolute commands for the height of the shutter/blinds. The object 4 “absolute position of blinds” controls only channels selected as shutter. It controls the opening angle of the blinds by an absolute position command. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 27: Scenes
Illustration 13: scene function Number Name Length Usage 16 Scene 1 Byte Call of the respectively scene Chart 16: communication object scene To call a specific scene, you have to send the value of the respectively scene to the communication object for the scene function. The value, to call the scene, is thereby always one number less than the adjusted scene number. If you for example want to call scene number 1, you have to send a 0. Consequently the scene number can have the values from 1 to 64, but the values to call a scene only from 0 to 63. If you activate the call of a scene at a binary input, you have to set the same scene numbers at your binary input and at your shutter actor. The binary input sends automatically the right value to call the scene. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 28: Subitem Scene
Technical Manual Shutter actuator JAL‐0X10X.01 4.6.1 Subitem scene Every channel has 8 opportunities to save scenes. This 8 memory cells have the names A‐H. Every of the 8 scenes can get one of the possible 64 scene numbers. The following illustration shows the setting options at the sub item scene (channel X: scene) for the scenes A‐D and a channel, which was selected as shutter (scenes E‐H are the same as the first four): Illustration 14: subitem scene The subitem for blinds is almost the same like the one for a shutter channel, but the setting options for position of blinds are dropped out. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 29 Scene number; pick‐up value = one number [1] less than the scene number (default values increase by every alphabetic increment, B=2; C=3,…) Chart 17: dynamic range scenes If a scene is activated in a channel, a subitem scene for this channel will appear. At this subitem the channel can be allocated a reaction for the call of this scene. This reaction contains a command for an absolute height (0‐100%) for this channel or additional an absolute position of blinds at a shutter channel (see also Chart 17). Every channel can react to eight different scenes. By sending the according pick‐up value for the scene, the scene is called and assumes its parameterized conditions. During this process the channel regards also its individual parameterization. If the channel shall for example drive to 0% by calling the scene and still drives down at 70%, the pause at change of direction will be observed before the channel starts driving up to 0%. You have to observe at the programming, that if two or more channels shall refer to the same scene numbers, the communication objects are hosted in the same group address. By sending the pick‐up value for the scene, all channels with the according scene number respond. It is useful to divide your group addresses after scenes to make the programming more clearly. That means if a channel shall react to eight different scenes, the communication object is also integrated in eight different group addresses. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
- Page 30 29 0x1C 28 0x9C 156 30 0x1D 29 0x9D 157 31 0x1E 30 0x9E 158 32 0x1F 31 0x9F 159 Chart 18: Calling and saving scenes MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 31: Automatic Function
4.7 Automatic function You can activate an automatic function for every channel. Through the automatic function, you can call up to 4 different conditions. The automatic function is divided into two different blocks (A and B). It is also possible to call several moves to the same time through the automatic function, for example drive the blinds as well as the shutter and change the opening angle of the blinds. The following Illustration shows the activation of the automatic function for a channel: Illustration 15: automatic function If the automatic function is activated for a channel, at the left drop down menu a new subitem (channel X: Automatic) will appear to parameterize the automatic function for this channel. 4.7.1 Subitem automatic function The following illustration shows the setting options for an automatic function at the subitem channel X: automatic: Illustration 16: subitem automatic function MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 32: Automatic Blocks
[0%] automatic function(only at shutters) Chart 19: dynamic range automatic function At the subitem for the automatic function, you can depose values for 4 different automatic calls. The values are absolute values, which the channel accepts at the call of the according automatic function. Additional you can determine for every channel to which automatic block the channel shall refer. Here are the blocks A and B disposal. The activation of the blocks is descripted below. 4.7.2 Automatic blocks To call appointed values by the automatic function, you have to activate the appointed automatic blocks at the subitem for the automatic function. The blocks A and B can be activated or deactivated separately. The following illustration shows the setting options for the automatic blocks: Illustration 17: automatic blocks If an automatic block gets activated, the according communication objects appear. There are four communication objects for every block, respectively one for every automatic function. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 33: Alert Functions/ Superior Functions
By calling one of the communication objects, the deposited values for the automatic function are called. It is possible to move all channels of one shutter actuator to their parameterized values with only one command, but also to move only one channel. This happens in according to the parameterization, which was made for the individual channel at the subitem automatic function (have a look at 4.7.1). To move more channels to the same time to a specific value, you have to choose the same blocks for these channels and set the same values for this automatic positions. 4.8 Alert functions/ superior functions The shutter actuator can react to specific weather situations and introduce several reactions for this channel to protect the shutters/blinds by using the alarm function. Additional reactions on a bus power breakdown or a bus power return can be defined. The alarm functions can be activated or deactivated for every several channel. The signals for the alarms can be recovered of a KNX weather station. Now the shutter actuator is able to evaluate these signals and assemble them according to the parameterization. The following Illustration shows the activation of the alert functions for a channel: Illustration 18: Alert functions If the alert function is activated for a channel, at the left drop‐down menu appears a subitem (channel X: Alarms), in which the following parameterization can ensue. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 34: Subitem Alert Functions
Technical Manual Shutter actuator JAL‐0X10X.01 4.8.1 Subitem alert functions If the alert function is activated, you can make the following parameterization at the appeared subitem. The following illustration shows the drop‐down menu for the alert function: Illustration 19: subitem alert function The several parameters of the alert function, as well as the setting options, are descripted in detail at the following segments. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 35: Order Of Alarms
[default value] Order of alarms Wind, Rain, Frost, Block sets the priority of the Wind, Rain, Block, Frost alarms Wind, Block, Rain, Frost Block, Rain, Wind, Frost Chart 21: Order of alarms If there are two or more alarms activate to the same time, the shutter actuator will evaluate the alarms according to the appointed order of alarms. The shutter actuator implements only the function of the alarm with the highest priority. The function for the alarm with the lower priority does not implement, as far the alarm with the higher priority is active. When the alarm with the higher priority is deactivated and the alarm with the lower priority is still active, the function for the alarm with the lower priority is activated afterwards. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 36: Alarm Types
If an alarm is activated the according communication object appears. If the according communication object receives an “1‐signal”, the alarm function will be activated. By sending a “0‐signal”, the alarm gets deactivated. The following chart shows the according communication objects: Number Name Length Usage 29 Wind alarm 1 Bit Activation/deactivation of the wind alarm 30 Rain alarm 1 Bit Activation/deactivation of the rain alarm 31 Frost alarm 1 Bit Activation/deactivation of the frost alarm Chart 23: communication objects alarms MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 37: Periodic Observation
Dynamic range comment [default value] Action at reset of alarms no action Adjustment for the repeal of the drive to former position alarm functions and blocking drive to top functions drive to bottom Chart 24: Action at reset of alarms The user has 4 different setting options for the parameter “action at reset of the alarms”, which the shutter actuator can conduct for this channel. By using the setting “no action” the channel stays in its position, which he had during the active alarm. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 38: Reaction When Bus Power Down/Up
drive to bottom Reaction when bus power no action Reaction to a bus power return up drive to top drive to bottom Chart 25: Reaction to bus power faults For the “reaction when bus power down” as well as for the “reaction when bus power up” three setting options are available. The channel can drive to a defined value as well for the bus power breakdown as for the bus power return and drive to the top or to the bottom. The setting “no action” let the channel maintain in its actual position. It is important to note, that the shutter actuator can not be addressed via the bus during a bus power breakdown and so can not be driven in its „normal way“. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 39: Block Functions
Technical Manual Shutter actuator JAL‐0X10X.01 4.9 Block functions The block function can be activated for every channel by a separately subitem. When the block function was activated for a channel, a new subitem appears, under the according channel, called channel X: block at the drop down menu. The following illustration shows the activation of the block function: Illustration 21: Activation block function The following illustration shows the distribution at the submenu of the block function: Illustration 22: Block function MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 40 When the particular block functions are activated the according communication objects appears. The chart shows the according communication objects: Number Name Length Usage 27 block absolute position 1 Bit blocks the object absolute position 28 block universal mode 1 Bit blocks the channel according to the appointed parameterization 32 block 1 Bit blocks the according channel Chart 27: communication objects block function MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
- Page 41 Block up/down movement blocks the driving commands of the channel (also the blind adjustment at shutters) Block absolute position mode blocks the receiving of absolute position commands via the object “absolute position” Block automatic mode blocks the automatic function for this channel, that means the call of the channel via the automatic function is blocked for this channel Block scene mode blocks the scene mode for this channel, that means at a scene calling, in which the blocked channel is integrated, the channel is not called with and stays instead in its actual position All blocking function can be activated by a logical “1” and deactivated by a logical “0”. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de...
-
Page 42: Index
Page 37 Illustration 21: Activation block function Page 39 Illustration 22: Block function Page 39 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 43: List Of Tables
Page 38 Chart 26: Block functions Page 40 Chart 27: Communication objects block function Page 40 MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... -
Page 44: 6 Attachment
6.1 Statutory requirements The above‐described devices must not be used with devices, which serve directly or indirectly the purpose of human, health‐ or lifesaving. Further the devices must not be used if their usage can occur danger for humans, animals or material assets. Do not let the packaging lying around careless, plastic foil/ ‐bags etc. can be a dangerous toy for kids. 6.2 Routine disposal Do not throw the waste equipment in the household rubbish. The device contains electrical devices, which must be disposed as electronic scrap. The casing contains of recyclable synthetic material. 6.3 Assemblage Risk for life of electrical power! All activities on the device should only be done by an electrical specialist. The county specific regulations and the applicable EIB‐directives have to be observed. MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de... - Page 45 • Two contacts share one supply phase (MDRC device) • Common supply phase (UP and AP device) • Integrated bus coupling unit • 3 years warranty DIN EN ISO 9001 MDT technologies GmbH 51766 Engelskirchen Papiermühle 1 • • TAW Cert Tel.: + 49 - 2263 - 880...
- Page 46 100mm x 40mm x 88mm 41mm x 41mm x 24mm ** no three-phase asynchronous motor Examplary circuit diagram JAL-0410.01 Examplary circuit diagram JAL-0410D.01 DIN EN ISO 9001 MDT technologies GmbH 51766 Engelskirchen Papiermühle 1 • • TAW Cert Tel.: + 49 - 2263 - 880 Fax: + 49 - 2263 - 4588 knx@mdt.de...
