Technical Manual
Glass Room Temperature Controller Smart
Behaviour on reset
The following parameter defines the behaviour at the initialization of the device:
Figure 34: Ventilation control – Behaviour on reset
"Behaviour on reset" defines the level to be called after a reset if the controller has no value yet.
This can be "automatic mode" or "Levels 0 – 4".
Sticking protection
The following parameter activates a sticking protection:
Figure 35: Ventilation control – Sticking protection
To protect the ventilation from getting stuck, a sticking protection can be activated. This lets the
ventilation run briefly at the highest level if it has not been moved for 24 hours (= level 0).
Priority
The priority can call a certain state:
Figure 36: Ventilation control – Priority
When the polarity is set (value = 1), the set state is called up. With "Value 0" the priority is taken
back again.
The following table shows the communication objects for priority control:
Number Name/Function
44 Ventilation control – Object priority
Table 75: Communication object – Ventilation control: Priority
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
71
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
SCN-RTRGx.02
Length Usage
1 Bit Value 1 calls the adjusted level
