CCI-22 Dual Party-Line Interface Instruction Manual
DIODES AND TRANSISTORS
Designator
D102 D104 D202 D204
D103 D105 D106 D107
D203 D205 D206 D207
D108 D208
Q105 Q107 Q205 Q207
Q103 Q203
Q108 Q109 Q110 Q111
Q208 Q209 Q210 Q211
Q106 Q206
Q101 Q102 Q201 Q202
Q104 Q204
INTEGRATED CIRCUITS
Designator
IC105 IC106 IC205 IC206
IC103 IC104 IC203 IC204
IC102 IC202
IC101 IC201
Component Description
Diode 1N4001 RECT 1A 50PIV 4
Diode 1N4148 SIGNAL 10MA
75PIV
Diode 1N957B ZENER 6.8V
.4W 5%
Transistor 2N2222 NPN 30V
Transistor2N4401 NPN 40V
Transistor J174 JFET PCHAN
8V VGS
Transistor MPS-A13 NPN 30V
DARL
Transistor MPS-A55 PNP 60V
Transistor MPS-A63 PNP 30V
DARL
Component Description
Analog IC 4N26 OPTO COM-
PILER
Logic Chip 4001 CMOS QUAD 2
IN NOR
Op Amp LM741 IC OP AMP
8-PIN DIP
Op Amp NE5532 DUAL LO
NOISE OP AMP
Qty
8
2
4
2
8
2
4
2
Qty
4
4
2
2
3 - 3
