- Page 1 TAC ECO TOWER ORIGINAL INSTRUCTIONS HIGH-PERFORMANCE AIR PURIFIER...
-
Page 2: Table Of Contents
Information marked with this symbol helps you to carry user maintenance shall not be made by children out your tasks quickly and safely. without supervision. Follow the manual Information marked with this symbol indicates that the instructions must be observed. high-performance air purifier TAC ECO Tower... - Page 3 • When positioning the device, observe the minimum distances from walls and other objects as well as the storage and operating conditions specified in the Technical annex. high-performance air purifier TAC ECO Tower...
-
Page 4: Information About The Device
In combination with the integrated G4 Z line prefilter system, the Do not touch the mains plug with wet or damp hands. Trotec H14 HEPA filter guarantees to separate airborne germs, Hold onto the mains plug while pulling the power cable viruses and dust, bacteria, spores or micro fibres from paper or out of the mains socket. -
Page 5: Transport And Storage
HEPA air filter (inside the device) power cable. If there are doubts as to the sound condition, contact the customer service. • Have the device checked once a year by an electrically skilled person at any rate. high-performance air purifier TAC ECO Tower... -
Page 6: Assembly And Installation
• Make sure that extension cables are completely unrolled. • When positioning the device, keep a sufficient distance to heat sources. • Make sure that no curtains or other objects interfere with the air flow. high-performance air purifier TAC ECO Tower... -
Page 7: Operation
3. Clean the device according to the Maintenance chapter. Filter indicator light 1 Indicator light for prefilter 4. Store the device according to the Storage chapter. Filter indicator light 2 Indicator light for H14 HEPA filter 10 Operating switch Adjusting the fan stage high-performance air purifier TAC ECO Tower... -
Page 8: Available Accessories
• Check the air inlets and air filters for dirt. Remove external dirt. • From the outside, check the device for dirt (see chapter Maintenance). If the inside of the device is dirty, have it cleaned by a specialist company or by Trotec. high-performance air purifier TAC ECO Tower... - Page 9 11. Date: ........12. Date: ........Signature: ........ Signature: ......... Signature: ......... Signature: ......... 13. Date: ......... 14. Date: ........15. Date: ........16. Date: ........Signature: ........ Signature: ......... Signature: ......... Signature: ......... high-performance air purifier TAC ECO Tower...
- Page 10 Clean the housing with a soft, damp and lint-free cloth. Make sure that no moisture enters the housing. Protect electrical components from moisture. Do not use any aggressive cleaning agents such as cleaning sprays, solvents, alcohol-based or abrasive cleaners to dampen the cloth. high-performance air purifier TAC ECO Tower...
- Page 11 8. Install a new HEPA air filter. 9. Put the discharge hood (1) back on the device. 10. Fasten the discharge hood in place using the screws and the hold-down devices. 11. Put the protective caps back on the screws. high-performance air purifier TAC ECO Tower...
- Page 12 3. Insert the new air filter into the device. ð Observe the installation direction. The black fleece must be on the outside. 4. Put the air inlet (4) back on the device and tighten the screws on both insides of the device. III. high-performance air purifier TAC ECO Tower...
-
Page 13: Technical Annex
Minimum distance to walls and other objects: top (A): 10 cm rear (B): - cm sides (C): 50 cm front (D): - cm Weight 76.1 kg *Sound pressure level according to ISO 11203 in dB(A), depending on configuration (sound protection caps, FlowExtender Silence+) high-performance air purifier TAC ECO Tower... - Page 14 Circuit diagram high-performance air purifier TAC ECO Tower...
- Page 15 Sheet metal cover (sheet metal cover heating mantle) Hexagon nut (DIN 934 M5 VZ, galv.) Insulation top part (T0001358) Cylinder Allen screw (DIN 912 M4x10 VZ, galv.) Discharge hood (T0001209) Serrated lock washer (Ø5.3 x Ø10 x 0.6) high-performance air purifier TAC ECO Tower...
- Page 16 Screw (Liko cross, DIN7380-1 M4x8 VA stainl. steel) End stop (ZES 35/2 BG (beige), screwless) Screw (Liko cross, DIN7985 M5x6 VA stainl. steel) Differential pressure switch (DDW/H40 50Pa-500Pa) Washer (DIN 125 – A Ø5.3xØ10x1 VA stainl. steel) high-performance air purifier TAC ECO Tower...
- Page 17 Spare part Spare part Hood (T0000737) Velcro dot (self-adhesive, Ø13 black) Hexagon screw (DIN 933 M10x25 VZ, galv.) Protective fleece (495x495x8mm RT-150W, black) Detent-edged washer (Ø10.2 x Ø22.3 x 2.5 VZ, galv.) high-performance air purifier TAC ECO Tower...
- Page 18 Allen screw (Liko DIN7380-1 M5x12 VZ, galv. black) Support plate (T0000553) Washer (DIN 125 – A Ø5.3xØ10x1 VZ, galv.) Closure plug (retaining bolt M5) Insulation lower part (T0001364) Hexagon nut (DIN 934 M5 VZ, galv.) Self-adhesive needle felt (20x1mm L=1500mm) high-performance air purifier TAC ECO Tower...
- Page 19 Setscrew (M 6x30 VZ) Screw (Liko cross, DIN7985 M5x16 VZ, galv., black) Sealing plug (Ø30xØ25.5xØ20.5x1.5x8, black) Hexagon nut (DIN 439-2 M6 VZ, galv.) Pin with head (DIN 1444 Ø8 x 29 x Ø2) high-performance air purifier TAC ECO Tower...
- Page 20 Spare part Spare part Fan (fan TAC V+) Protective grid (bolt circle 206.6 or 226.6mm hole 5.4mm, black plastic) Hexagon screw (DIN 933 M10x25 VZ, galv.) high-performance air purifier TAC ECO Tower...
- Page 21 Knurled nut (M4 black Ø20x9.5mm) Locking sleeve (snap lock lower part M5) Cylinder Allen screw (DIN 912 M4x12 VZ, galv.) Self-adhesive needle felt (25x1mm L=2920mm) Cylinder Allen screw (DIN 912 M5x10 VZ, galv.) Self-adhesive needle felt (20x1mm L=500mm) high-performance air purifier TAC ECO Tower...
- Page 22 Upper housing (T0000746) Self-adhesive needle felt (25x1mm L=1160mm) Cover for maintenance work (T0000711) Allen screw (Liko DIN7380-1 M6x12 VZ, galv., black) Self-adhesive needle felt (20x1mm L=1950mm) Detent-edged washer (Ø6 x Ø12.2 x 1.2 VZ, galv.) high-performance air purifier TAC ECO Tower...
-
Page 23: Disposal
The icon with the crossed-out waste bin on waste electrical or electronic equipment stipulates that this equipment We – Trotec GmbH – declare in sole responsibility that the must not be disposed of with the household waste at the end of product designated below was developed, constructed and its life. - Page 24 Trotec GmbH Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
