8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM THANK YOU ually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improv ement needs. Thank you for choosing Hampton Bay!
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED : Hardware not shown to actual size. NOTE Part Description...
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Lower bracket Upper bracket Base tube Upper base cover Lower base cover Pedal Turn plate Side base Middle base Crank Umbrella shade...
Assembly Pouring Sand and Water into the Bases Open the side bases (H) and the middle bases (I) in the counterclockwise direction. Pour sand and water into the side bases (H) and the middle bases (I). Close the side bases (H) and the middle bases (I) in the clockwise direction. NOTE: Place the bases in the area where the umbrella is to be used.
Page 6
Assembly (continued) Attaching the Brackets Attach the upper bracket (B) onto the lower bracket (A).
Page 7
Assembly (continued) Attaching the Turn Plate to the Brackets and Base Tube to the Turn Plate Attach the pedal (F) to the turn plate (G) using M6x10 bolt (DD) and the M6 hex wrench (EE). Attach the turn plate (G) to the brackets (A & B) using M10x20 combination bolts (BB) and the M10 hex wrench (FF). turn plate (G) using M10x25 combination bolts (AA) and the M10 hex wrench (FF).
Page 8
Assembly (continued) Attaching the Middle Bases to the Brackets Attach the middle bases (I) onto the brackets (A & B).
Page 9
Assembly (continued) Attaching the Side Bases to the Brackets Attach the side bases (H) to the bracket (A & B). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
Page 10
Assembly (continued) Inserting the Lower Base Cover and the Upper Base Cover into the Base Tube Insert the lower base cover (E) and the upper base cover (D) into the base tube (C).
Page 11
Assembly (continued) Inserting the Umbrella Shade to the Base Tube Insert the umbrella shade (K) into the base tube (C) using M6x15 bolts (CC) and M6 hex wrench (EE). Fully tighten all the bolts at this step. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
Operation Attaching the Crank to the Umbrella Shade Press the button on the handle of the umbrella shade (K) and push up to desired position. Attach the crank (J) to the handle.
Page 13
Operation (continued) Opening the Umbrella Shake the umbrella fabric before opening the umbrella. Slowly turn the crank (J) clockwise to open the umbrella, press the button on the handle, hold the handle, and push the umbrella shade to the desired position. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
Page 14
Operation (continued) Rotating the Umbrella Hold the pedal (F) with one foot and rotate the umbrella pole. (The umbrella can rotate up to 360 degrees.)
Page 15
Operation (continued) Adjusting the Umbrella To adjust the umbrella shade position, press the button on the handle and push up or push down to desired position. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
Page 16
Operation (continued) Closing the Umbrella Slowly turn the crank (J) in a counterclockwise direction to close the umbrella. Hold the umbrella handle, and press the button on the handle, and push the umbrella shade downward. Tie th e umbrella to the umbrella pole with the Velcro belt when not in use, as shown below.
Operation (continued) Attaching and Detaching the Crank Attach the crank (J) without using the tap as shown in figure 1. To detach the crank (J), just take the crank out. Attach the crank (J) to the handle as shown in figure 2. Attach the crank (J) by aligning the tap with the hole on the crank (J) until it snaps into place.
Page 18
