Item # 1001 163 167
1001 163 168
Model # YJAF-008-1-G
YJAF-008-1-T
USE AND CARE GUIDE
10 FT. STEEL ROUND OFFSET UMBRELLA
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1
8 -
5 5
H -
D
H -
A
M
P
O T
N
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this umbrella. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY YJAF-008-1-G
Summary of Contents for HAMPTON BAY YJAF-008-1-G
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this umbrella. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Safety Information ............2 Hardware Included ..............3 Product Caution ...............2 Package Contents ..............4 Safety Warnings ..............2 Warranty ................. 2 Assembly ............... 5 Operation ..............10 What is Covered ...............2 Care and Cleaning ............ -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non- abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to complete the assembly of this product. NOTE: For proper stability of the offset umbrella, please place 176 lbs. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Lower bracket Upper bracket Lower umbrella pole Umbrella shade... -
Page 5: Assembly
Assembly ATTACHING THE BRACKETS Attach the upper bracket (B) onto the lower bracket (A). NOTE: This umbrella should be set up in its desired location to avoid moving it after assembly. HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance. - Page 6 Assembly (continued) ATTACHING THE LOWER UMBRELLA POLE TO THE BRACKETS Attach the lower umbrella pole (C) to the upper bracket (B) and lower bracket (A) using M8x20 combination hex bolts (AA). NOTE: Fully tighten all bolts using the wrench (BB).
- Page 7 Assembly (continued) ATTACHING THE UMBRELLA SHADE INTO THE LOWER UMBRELLA POLE Insert the umbrella shade (D) into the lower umbrella pole (C). Attach the locking knob (CC) to the lower umbrella pole (C) by turning the locking knob (CC) clockwise until fully tightened. HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
- Page 8 Assembly (continued) RAISING THE UMBRELLA Shake the canopy to separate the umbrella ribs (1). Loosen the lock handle (2). Push the lock handle upward (3). Lock handle...
- Page 9 Assembly (continued) RAISING THE UMBRELLA Tighten the lock handle (1). Push the long tube upward (2). Pull down the plastic collar to lock the sunshade (3). Plastic collar Lock handle HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 10: Operation
Operation OPENING THE UMBRELLA Slowly turn the crank clockwise to open the umbrella (1). When the umbrella is fully open, fasten the velcro belt to stabilize the umbrella. Make sure the velcro belt is tightened (2). Velcro belt... - Page 11 Operation (continued) CLOSING THE UMBRELLA Loosen the velcro belt (1). Slowly turn the crank counterclockwise to close the umbrella (2). Velcro belt HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
- Page 12 Operation (continued) STORING THE UMBRELLA Pull up the plastic collar to loosen the sunshade (1). Pull the long tube downward (2). Plastic collar...
-
Page 13: Care And Cleaning
Operation (continued) STORING THE UMBRELLA Loosen the lock handle (1). Pull the lock handle downward (2). Tighten the lock handle (3). Lock handle Lock handle Care and Cleaning For best results, clean the frame and fabric with a damp cloth, and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. - Page 14 Questions, problems, missing parts? Before returning to the store call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday HOMEDEPOT.CA Retain this manual for future use.
