USE AND CARE GUIDE
10 FT X 10 FT SQUARE OFFSET UMBRELLA
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this umbrella. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improv
ement needs.
Thank you for choosing Hampton Bay!
Advertisement
Related Manuals for HAMPTON BAY YJAF-819C-SCS
Summary of Contents for HAMPTON BAY YJAF-819C-SCS
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this umbrella. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improv ement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly................3 Safety Information ..............2 Planning Assembly..............3 Product Caution ..............2 Hardware Included..............3 Safety Warnings ..............2 Package Contents..............4 Warranty ..............Assembly.................5 What is Covered..............2 Operation................ -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED : Hardware not shown to actual size. NOTE Part Description... -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Lower bracket Upper bracket Base tube Lower umbrella pole Crank Umbrella shade Pedal Turn plate Side base Middle base Upper base cover Lower base cover... -
Page 5: Assembly
Assembly Attaching the brackets Attach the upper bracket (B) onto the lower bracket (A). NOTE: This umbrella should be set up in its desired location to avoid moving it after assembly HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 6 Assembly (continued) Attaching the pedal to the turn plate Attach the pedal (G) to the turn plate (H) using M6x10 bolt (AA) and the M6 hex wrench (FF).
- Page 7 Assembly (continued) Pull out the lower umbrella pole from the base tube Pull out the lower umbrella pole (D) from the base tube (C). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 8 Assembly (continued) Attaching the turn plate to the brackets Attach the turn plate (H) to the brackets (A & B) using M10x25 combination bolts (DD) and the M10 hex wrench (EE). Attach the base tube (C) to the turn plate (H) using M10x22 combination bolts (CC) and the M10 hex wrench (EE).
- Page 9 Assembly (continued) Pouring sand and water into the bases Open the side bases (I) and the middle bases (J) in the counterclockwise direction. Pour sand and water into the side bases (I) and the middle bases (J). Close the side bases (I) and the middle bases (J) in the clockwise direction. OPEN WATER SAND...
- Page 10 Assembly (continued) Attaching the middle bases to the brackets Attach the middle bases (J) onto the brackets (A & B).
- Page 11 Assembly (continued) Attaching the side bases to the brackets Attach the side bases (I) to the bracket (A & B). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 12 Assembly (continued) Inserting the middle umbrella pole into the base tube Insert the lower base cover (L) into the base tube (C). Insert the upper base cover (K) into the base tube (C). Insert the lower umbrella pole (D) into the base tube (C).
- Page 13 Assembly (continued) Connecting the umbrella shade into the base tube Connect the umbrella shade (F) into the base tube (C) using one M6x15 bolt (BB) and M6 hex wrench (FF). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 14 Assembly (continued) Attaching the crank to the umbrella shade Attach the crank (E) to the umbrella shade (F).
-
Page 15: Operation
Operation Opening the umbrella Shake the umbrella fabric before opening the umbrella. Press the button on the umbrella shade (F) and slowly turn the crank (E) clockwise to open the umbrella. BUTTON HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 16 Operation (continued) Rotating the umbrella Hold the pedal (G) with one foot and rotate the umbrella pole (The umbrella can rotate up to 360 degrees). 360°...
- Page 17 Operation (continued) Tilting the umbrella To tilt the umbrella, push the button on the top of the umbrella shade (F), and push up or push down to desired position. Button HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 18 Operation (continued) Closing the umbrella Slowly turn the crank in a counterclockwise direction to close the umbrella. Press the button on the umbrella shade (F) and push down.
- Page 19 Operation (continued) Tie the umbrella to the umbrella pole Tie the umbrella to the umbrella pole with the Velcro belt when not in use. Velvro HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 20: Care And Cleaning
Operation (continued) Attaching and detaching the crank Attach the crank (E) without using the tap as shown in figure 1. To detach the crank (E), just take the crank out. Attach the crank (E) to the handle as shown in figure 2. Attach the crank (E) by aligning the tap with the hole on the crank (E) until it snaps into place. - Page 21 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
