According to the universal DMX512 protocol, CODE GOBO 200 scanner controller can control sixteen 12-channel
scanners or other equipment. Chase program and manual control of scanners can be performed at the same time.
Its functions are compact. Its convenient and flexible operation made it be handled very easily. GOBO 200 is
suitable for different ballroom, taproom and small show.

Technical specifications

Output signal
DMX channels
Control amount of scanners
Maximum control channel amount of a
scanner
Manual operation of scanner
Amount of chase programs
Maximum chase steps in a chase
Total chase steps
Range of chase speed
Ratio range of cross between steps
Display mode
Port of DMX output
Other functions
Power supply
Size
Weight

Cautions for safety

GOBO 200 scanner controller must be connected to earth ground to ensure the safety of user.
When GOBO 200 and scanners are working, don't plug in or pull out DMX512 data cable to avoid
destroying the electric components of the port in the controller.
Don't splash any liquid to the controller to avoid destroying the electric components and the functions of
the controller.
The scanner controller is precision electric equipment. Please pay attention to moistureproof protection
and dustproof protection. And please clean the controller panel termly.

Installation of controller

Contents in the package of
GOBO 200 scanner controller
Power supply line
Certification of QC
User's Manual
Installing structure of GOBO 200 scanner controller follows international standard 19" 4U. It can be embedded
in operation board or directly installed in 19" shelf or cabinet.
The power of GOBO 200 scanner controller has steady voltage output in so wide range of power supply
voltage that it is adapted to the power supply of many countries. Before the power supply is connected, please
check whether the voltage is in normal range of GOBO 200 to ensure the safety.
When the fuse needs to be replaced, please use the fuse with the current capacity signed on the rear of
GOBO 200.
DMX512
1-192
16
12
16
50
580
0.25-60s/step
0-100%
LCD display and LED indicator
XLR-D3F
Auto save for every data when power off and auto save for
chase speed and cross ratio.
AC 90-240V，50-60Hz，4W
482mm x 178mm x 55mm
3Kg
GOBO 200 scanner controller
1;
1;
1;
1.
