Ridder Motor Gearboxes RW 3-phase
RW70
RW100
RW140
RW200
RW240
RW400
RW600
RW45
Product Manual
Original product-manual
265003EN - 2021.12 - V01
RW800
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ridder RW Series
Summary of Contents for Ridder RW Series
- Page 1 3846 AX Harderwijk F +31 (0)341 416 611 PO Box 360 I ridder.com 3840 AJ Harderwijk E info@ridder.com the Netherlands Product Manual Ridder Motor Gearboxes RW 3-phase Original product-manual 265003EN - 2021.12 - V01 RW70 RW100 RW140 RW200 RW1000 RW1200...
-
Page 2: Table Of Contents
7.4 Installation covers 8. MAINTENANCE INSTRUCTIONS 8.1 Maintenance 9. SERVICE 9.1 Troubleshooting 9.2 Technical support 10. ENVIRONMENT 10.1 Decommissioning and removal 10.2 Waste disposal Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 3: Guidelines, Standards And Conditions
1.4 Warranty provisions For the warranty period and conditions refer to the ‘Conditions’ section on our website at ridder.com, or in the Ridder catalog. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 4: Safety, Precautions And Symbols
Refer to the permitted mounting positions in the product manual.* * Not applicable to motor gearboxes filled with grease! Ê Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 5: Precautions And Safety Instructions
RSU/RLS) during all work. There is a risk of short circuit, fire and corrosion. • Take sufficient precautions to prevent ElectroStatic Discharge (ESD). • Ridder is not responsible for injury, material damage or consequential damage if accessories are used that Ridder did not make. -
Page 6: Residual Risks
Persons can be in danger of life if they touch a system that is in operation. Forces Ridder cannot be sure that there will be no injury to persons or damage to the system because of the forces in the systems (in which the drive unit is installed). Ridder Drive Systems B.V. -
Page 7: Symbols And Abbreviations
Motor-Protection Circuit-Breaker Screw head “Torx” Neutral wire Safety transformer (EN 61558) “normally closed” Motor connection “normally open” Motor connection Protective earth Motor connection Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 8: Product Details
NOTE: Possibly the sequence of symbols is different and/or other symbols are included in the identification. Not all symbols and assembled configurations (such as LK, LD, ...) are included in the explanation. * K = Sprocket in an assembled configuration. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 9: Description
Optionally a 16-tooth 1⁄2”x5⁄16” zinc-plated sprocket for chain couplings is installed. The switching range of the limit-switch system is 86 revolutions of the drive shaft. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 10: Application
• The RW45TRA\RW240TRA motor gearboxes with a TRA520 rack drive are drive units to operate ventilation systems and hoisting systems in greenhouses and livestock houses or crop-storage buildings. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 11: Dimensions
RW45: RW-L/(LK) Ø15 H1 = 55–56 mm RW-TRA H2=144–158mm L1 = 166–170 mm RW-D L2 = 108–112 mm 70.5 Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... - Page 12 L2 = 115–195 mm RW800: H1 = 72.5–89 mm 62.5 H2 = 190–213 mm L1 = 217–246 mm L2 = 160–215 mm Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com...
- Page 13 L2 = 130–210 mm RW70/100/140/200-34\68: 188.5 77.5 Ø25 H1 = 75–88 mm H2 = 179–230 mm L1 = 215–246 mm L2 = 112–153 mm Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com...
-
Page 14: Technical Specifications
RW240–600 RW800 RW1000–2000 RW70–200 Protection rating IP54* Ambient temperature [°C (°F)] 0–60 °C (32–140 °F) * IP55 only applicable if in identification. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 15: Install Instructions
No special tools or equipment are necessary to install, to connect or for commissioning. Make sure that the correct equipment and tools are used. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 16: Mounting Positions
• After installation interchange the plug in the highest position with the vent plug! This is not applicable to motor gearboxes that are filled with grease! RW45 [grease lubrication]: RW240/400/600 [oil lubrication]: Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... - Page 17 RW240 [grease lubrication]: RW800 [oil lubrication]: Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com...
- Page 18 RW1000/1200/1400/1600/2000 [oil lubrication]: RW70/100/140/200-34\68 [oil lubrication]: Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com...
-
Page 19: Sprockets
Refer to the illustration (step ❶ and ❷) that follows for the configuration of shaft keys (a, b), retaining rings (c) and ring (d). For more information on item numbers and models refer to the Ridder catalog or website at ridder.com. -
Page 20: Installation
After installation interchange (of reductors filled with oil) the plug in the highest position with the vent plug! Refer to §4.2. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... - Page 21 C3. Do clamp mounting on lattices (different lattice widths and lattice heights possible). In this product manual shown illustrations can be different than the components and/or systems. For more information on item numbers and models refer to the Ridder catalog or website at ridder.com.
- Page 22 ≥ 16 mm! ≥ 14 mm! M12 (4x) M10 (3x) M10 x 25 (3x) - 45 Nm M12 x 25 (4x) - 80 Nm Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com...
- Page 23 Do the check of the minimum screw-in depth/free thread-length (SID/FTL) of the configuration that follows: SHEET THICKNESS and fixing-bolt LENGTH. This prevents damage or injury (breakage risk). Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com...
-
Page 24: Installation Options A-F For Output Shafts
** D is supplied as two parts (chain, chain connector). In this product manual shown illustrations can be different than the components and/or systems. For more information on item numbers and models refer to the Ridder catalog or website at ridder.com. -
Page 25: Installation Chain (For A-D)
❻ Put the chain onto the sprockets with the chain ends at the top. Install the chain ❶–❽ Install the chain connector and chain (on the sprockets). Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 26: Tra Drive-Unit Onto Rw45\240Tra Motor Gearbox
M12 fasteners (l or m) to install the TRA system onto the structure. Obey the instructions for installation of M12 fasteners (l or m). Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... - Page 27 In this product manual shown illustrations can be different than the components and/or systems. For more information on item numbers and models refer to the Ridder catalog or website at ridder.com. Ridder Drive Systems B.V.
-
Page 28: Belt Drum Onto Rw45\240/400L Motor Gearbox
HEX 3 mm - 10 Nm In this manual shown illustrations can be different than the components and/or systems. For more information on item numbers and models refer to the Ridder catalog or website at ridder.com. Ridder Drive Systems B.V. -
Page 29: Cable Drum Onto Rw45\240/400L Motor Gearbox
In this manual shown illustrations can be different than the components and/or systems. For more information on item numbers and models refer to the Ridder catalog or website at ridder.com. Note: Ridder does not supply steel cables and steel cable clamps. -
Page 30: Connect Instructions
• Install the covers (2x) again after the work! Refer to the end of chapter 7. PH2 (4x) PH/PZ (4x) In this product manual shown illustrations can be different than the components and/or systems. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 31: Electrical Material
* If your decision is not to use this cable gland, make sure to put the sealing plug back. Tighten the cable gland with the correct tool and tightening torque! - 5 Nm Ø6.0–12.0 mm - 2.5 Nm Ø5.0–10.0 mm M20x1.5/M16x1.5 Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 32: Protection - Conditions And Starting Points
Always make sure that the protections comply with the, local or national, laws and regulations of the country. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 33: Tightening-Torque Motor-Connections
Tighten the motor connections with the correct tightening torque! 2 Nm! M4 connections: 2 Nm • • M5 connections: 3 Nm. 3 Nm! Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 34: Control-Circuit Connection
5.5 Control-circuit connection Connect all safety switches (ES21/22) and duty switches (ES11/12). This is necessary for safety and correct functional operation. RSU connections: 1–12 Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 35: Change Direction-Of-Rotation - Switching Sense
Interchange 1 and 7 of the RSU. 5.7 OPTIONAL - Position Feedback You can connect a digital positioning-meter (RPU) or a Ridder Potentiometer installation set to the RW motor-gearbox. Refer to the product-manuals at ridder.com for the installation and connections. -
Page 36: User Instructions
Make sure that the system can be safely operated. • If necessary: Adjust the end positions again. This prevents damage or injury. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 37: Direction-Of-Rotation Rw Motor-Gearboxes
Direction-of-rotation A = Limit switch A = ES11/ES21 - Refer to §7.2. Direction-of-rotation B = Limit switch B = ES12/ES22 - Refer to §7.2 Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... - Page 38 Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com...
-
Page 39: Operation
Operation is possible with a manual control (MC) and/or other Ridder control components, which are compatible with (if applicable) “Automatic Control-Systems” (ACS). Refer to the Ridder catalog or website ridder.com for more information. Always refer to the related information and manuals (ACS and control components). -
Page 40: Rsu Limit-Switch System
ES21/ES22 SAFETY SWITCH An RW motor-gearbox has a limit-switch system with connection nuts (4). Ridder does not lock the adjusting rings (3). The drive unit can turn freely (temporarily, until the end positions are adjusted) in the two directions. This prevents damage to the limit-switch system (before it is electrical... - Page 41 • If a failure of the duty switch occurs, the switching spring (5) operates the safety switch (ES21 or ES22). This makes sure the motor gearbox stops. It prevents consequential damage to the system. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com...
-
Page 42: Adjusting The End Positions
3. Tighten the long adjusting screw (a) again with a tightening torque of 0.5–0.6 Nm. The adjusting ring (3) cannot turn freely at this time. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 43: Installation Covers
PH2 - 1.5 Nm (4x) Plastic cover - 0.5 Nm PH/PZ (4x) In this product manual shown illustrations can be different than the components and/or systems. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 44: Maintenance Instructions
• A problem is found with no solution. Refer to chapter 9 first. Refer to the Ridder catalog or the website at ridder.com for more information about spare parts (or accessories) that are available. Also refer to available documentation (maintenance instructions) at ridder.com of the Ridder products in the operated system. -
Page 45: Service
The connections on the connection block/connection blocks of the limit-switch system are not correct. Solution 1 Interchange the connections 1 and 7 on the connection block. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 46: Technical Support
4. Make the product unserviceable and make a mark on the product. This prevents that the product is (accidentally) used again. 5. The permanent decommissioning is completed. Refer to §10.2 “Waste disposal”. Ridder Drive Systems B.V. T +31 (0)341 416 854 - F +31 (0)341 416 611 - I ridder.com... -
Page 47: Waste Disposal
10.2 Waste disposal Discard products of Ridder Drive Systems after their lifespan and obey the applicable national and/ or local regulations. Make sure that after disassembly there is a separation of: • The collected operating materials (if applicable) such as oil, grease and such •...
