Summary of Contents for MicroTouch IC-156P-AW4
- Page 1 User Guide IC-156P-AW4 Touch Computer Version 1.2 2022/02...
- Page 2 MICROTOUCH reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of MICROTOUCH to notify any person of such revisions or changes. Windows is a registered trademark of...
- Page 3 Compliance Information For FCC (USA) This equipment has been tested and fund to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. There limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Renseignements relatifs à la conformité Pour la FCC (États-Unis). Ce matériel a fait l’objet d’essais qui ont déterminé qu’il respectait les limites d’un appareil de classe A selon la partie 15 des règlements de la FCC. Ces limites sont établies pour assurer une protection raisonnable contre les parasites nuisant à...
- Page 5 Usage Notice Warning - To prevent the risk of fire or shock hazards, and do not expose the product to moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Warning - Power cord shall be connected to a socket-outlet with earth connection.
- Page 6 Avis d’utilisation Mise en garde — Pour prévenir les risques d’incendie ou d’électrocution, ne pas exposer le produit à l’humidité. Mise en garde — Prière de ne pas ouvrir ou démonter le produit, car cela pourrait entraîner l’électrocution. Mise en garde – Le cordon d’alimentation doit être branché à une prise pourvue d’une mise à...
-
Page 7: Table Of Contents
Table of Contents Chapter 1 ........................7 1.1 Overview ........................8 1.2 Feature ........................8 1.3 Specifications ......................8 1.4 Block Diagram......................11 1.5 Interface Connectors ....................12 1.6 Package Overview ....................15 Chapter 2 ........................16 2.1 About VESA Mount ....................17 2.2 Power On / Off Switch .................... -
Page 8: Chapter 1
Chapter 1 Product Introduction... -
Page 9: Overview
1.1 Overview The IC-156P-AW4 is a thin 15.6” touch computer that offers a unique design with expandability and flexibility, making expansion and accessory installation easy. The versatility of IC-156P-AW4 is an exceptional choice for applications in all business sectors, especially in the retail market. - Page 10 1 x Power button 1 x USB Type-C (USB3CM:1x USB 3.1 gen1 with Display ALT Mode and PD2.0, support 5V@3A / 12V@2.5A output, Maximum 30W.) 1 x MiniDP (4K@60HZ) External IO Ports 2 x USB2.0 Type-A, 2 x USB3.0 Type-A 1 x LAN (Support 10/100/1000Mbps) 1 x DB9 (RS232, pin9 with NA/5V/12V support that select by BIOS)
- Page 11 System Only：2.01 Kg Net Weight System with Stand Module：4.01 Kg System Only：3.01 Kg Gross Weight System with Stand Module：6.01 Kg...
-
Page 12: Block Diagram
1.4 Block Diagram... -
Page 13: Interface Connectors
1.5 Interface Connectors 24V DC In Pin # Signal Name Pin # Signal Name RJ45 for LAN Pin # Signal Name Pin # Signal Name TP1+ TP1- TP2+ TP3- TP3+ TP2- TP4+ TP4- Function Color 1000 Orange LED1 Speed Green LED2 Active Yellow... - Page 14 SBU1 VBUS VBUS SSRXn2 SSTXn2 SSRXp2 SSTXp2 Note USB3CM: Support DP ALT mode and 5V@3A / 12V@3A output; USB 3.0 Dual Pin # Signal Name Pin # Signal Name USB5V USB5V StdA_SSRX- StdA_SSRX- StdA_SSRX+ StdA_SSRX+ GND_DRAIN GND_DRAIN StdA_SSTX- StdA_SSTX- StdA_SSTX+ StdA_SSTX+ Note Every on USB3.0 Power current provide 0.9A...
- Page 15 Mini DP Pin # Signal Name Pin # Signal Name Hot Plug Detect ML_Lane 0 (p) CONFIG1 ML_Lane 0 (n) CONFIG2 ML_Lane 1 (p) ML_Lane 3 (p) ML_Lane 1 (n) ML_Lane 3 (n) ML_Lane 2 (p) AUX_CH (p) ML_Lane 2 (n) AUX_CH (n) DP_PWR DB9 for RS232...
-
Page 16: Package Overview
1.6 Package Overview Touch Computer Power Cord DC Power Supply Screw Stand (Optional) Warning! This product is intended to be supplied by a UL Listed Power Adapter, rated 24Vdc, 5A minimum. (complied with LPS or PS2) Tma = 40 degree C minimum, and the altitude of operation = 3048m minimum. -
Page 17: Chapter 2
Chapter 2 Product Installation... -
Page 18: About Vesa Mount
The VESA mount is located on the back of this unit. The IC-156P-AW4 may be wall mounted in the horizontal position (output connector facing down) or vertical position (output connector facing left or right). - Page 19 Mise en garde! Sélectionner les vis d’origine de TES! La distance entre la surface du couvercle arrière et le bas de l’orifice de la vis est de 8 mm. Utiliser quatre vis M4 de 8 mm de diamètre pour le montage de votre moniteur.
-
Page 20: Power On / Off Switch
2.2 Power On / Off Switch Power On/Off Switch Function Description Power on Press the power button. Sleep With OS settings, sleep or shut down choose one. Power off Force Press the power button 4 sec. power off... -
Page 21: Dimension
2.3 Dimension 2.3.1 System Only Front View Side View Rear View Bottom View... -
Page 22: System With Stand Module
2.3.2 System with Stand Front View Side View Rear View... -
Page 23: Optional Accessory Installation
Bottom View 2.4 Optional Accessory Installation Note: Please install the accessories when the touch computer is in a powered off state. 2.4.1 Install the Stand Place stand module on back of touch computer and align the screw holes. Install the four M4 screws to fasten the stand module. -
Page 24: Install The Cables
2.4.2 Remove the Stand Step 1: Loosen the screws Step 2: Pull it to out from touch computer and remove stand module. Step 2 Step 1 2.4.3 Install the Cables... -
Page 25: Install The Camera Module
2.4.4 Install the Camera Module Camera Module weight 19g Step 1: Remove the side cover. Step 2: Connect the camera module cable to the touch computer. Step 3: Install the two M3 screws to fasten the camera module. Step 1 Step 3 Step 2... -
Page 26: Remove The Camera Module
2.4.5 Remove the Camera Module Step 1: Loosen the screws. Step 2: Remove the camera module cable from the touch computer. Step 3: Replace the side cover. Step 3 Step 2 Step 1 2.4.6 Install the MSR Module MSR Module weight 62g. Step 1: Remove the side cover. - Page 27 Step 3: The metal bracket hook into the gap between cover glass and bezel. Step 4: Install the two M3 screws to fasten the MSR module. Step 4...
- Page 28 2.4.7 Remove the MSR Module Step 1: Loosen the screws. Step 1 Step 2: Remove the MSR module cable from the touch computer. Step 3: To assemble the side cover. Step 3 Step 2...
- Page 29 Appendix...
- Page 30 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：觸控電腦 型號（型式）：IC-156P-AW4 Equipment name: Touch Computer Type designation (Type): IC-156P-AW4 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 Unit 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Hexavalent Polybrominated Polybrominated Lead Mercury...
