ERX
Eastey ERX Series
Automatic Case Erector
User Guide
MAIN
CONTROL
SCREEN
ALARMS
CLEAR
MACHINE START
MANUAL MODE
ALARMS
JOG
AUTO
MACHINE
TO HOME
MANUAL
CONTROL
MONITOR
SETTINGS
SCREEN
ON LINE
OFF LINE
SCREEN
0, 843
AUTO MODE CYCLES
ERX-15

Advertisement

Table of Contents
loading

Related Manuals for Eastey ERX Series

Summary of Contents for Eastey ERX Series

  • Page 1 ERX-15 Eastey ERX Series Automatic Case Erector User Guide MAIN CONTROL SCREEN ALARMS CLEAR MACHINE START MANUAL MODE ALARMS AUTO MACHINE TO HOME MANUAL CONTROL MONITOR SETTINGS SCREEN ON LINE OFF LINE SCREEN 0, 843 AUTO MODE CYCLES...
  • Page 3 ERX-15 Eastey ERX Series Automatic Case Erector User Guide Revised 07/29/2021 P/N 5011681 Rev B Copyright and Trademarks Copyright ©2019-2021 Engage Technologies Corporation All rights reserved. All trademarks and brand names are the property of their respective owners. Eastey 7041 Boone Ave. N.

  • Page 5: Table Of Contents

    Contents Safety ..........................8 Safety Precautions ....................... 8 Explanation of Symbols ....................10 Introduction ......................... 12 ERX-15 Automatic Case Erector Overview ..............12 ERX-15 Case Erector Features & Specifications ............13 Dimensions ......................... 15 Machine Serial Number ....................16 Typical Applications ....................16 Unpacking ........................
  • Page 6 Major Flap Closer Unit ....................93 Major Flap Closer Seat Unit..................96 Left Seat Unit ......................97 Right Seat Unit ......................99 Opener–W Unit ......................100 Opener–L Unit ......................102 Suction Unit ......................104 Opener Guide Unit ....................105 Opener Cart Unit ...................... 107 Opener Track Unit ....................
  • Page 7 M: Major Flap Folding Cylinders, Fittings & Hoses ........... 170 L: Carton Suction Cups, Hoses & Fittings ..............171 Appendix A: Electrical Schematics ................. 172 Electrical Schematic Page 1 of 12 ................172 Electrical Schematic Page 2 of 12 ................173 Electrical Schematic Page 3 of 12 ................

  • Page 8: Safety

    Keep a copy of this User Guide available with the machine at all times. Additional copies are available on request (Eastey.com/contact-us). The development of a good safety program that is rigidly enforced is absolutely imperative when involved in the operation of industrial equipment.
  • Page 9 • Do not make any modifications to either the electrical circuitry or the mechanical assemblies of this machinery. Such modifications may introduce hazards that would not otherwise be associated with the machinery. Eastey will not be responsible for any consequences resulting from such unauthorized modification. Do not operate a machine if any modification has been made.

  • Page 10: Explanation Of Symbols

    10 Safety Explanation of Symbols Caution sign or Safety Alert symbol. Indicates caution, be alert, Your safety is involved. Knowledge of safe operation is required. Caution indicates a hazardous situation which, if not avoided, could result in minor or moderate injury or damage to equipment or nearby property.
  • Page 11 Safety 11 Warning symbol. Indicates a hazardous situation which, if not avoided could result in death or serious injury. A warning indicates a situation potentially more severe than indicated by a caution message but not immanent as a danger message. The warning symbol is associated with messages for conditions as shown below.

  • Page 12: Introduction

    12 Introduction Introduction The Eastey ERX-15 Case Erector automatically unfolds and forms corrugated cartons from flat stock placed in the magazine hopper area. A tape head, installed below the exit drive belt area, seals the bottom seam of each carton as they move through the exit area.

  • Page 13: Erx-15 Case Erector Features & Specifications

    Introduction 13 The Case Erector can be thought of as having two major sections: one of which is the hopper or magazine where flat carton blanks are placed to be dispensed one-by-one as needed; and the other section is the enclosed case erecting and bottom-sealing section, in which the case opener swings the case open as the bottom flaps are folded closed and then sealed as the case exits.
  • Page 14 14 Introduction ERX-15 Case Erector Specifications Speed Up to15 cases per minute Case Types RSC RH Flute Types B-flutes 3mm Wall Types Single Case Sealing 2” wide pressure sensitive tape, optional 3” wide Case Hopper Capacity 150 - 200 cases (200 cases with B-flutes) Machine Dimensions Width (A) Height (B) Length (C) 82 in.

  • Page 15: Dimensions

    Introduction 15 Dimensions 58.58 in. 148.8 cm 47.59 in. 120.8 cm Note: Legs of the Case Erector may be lengthened or shortened by ±3.94 in. (±10 cm) as required to obtain desired conveyor height. Lengthening or shortening all legs increases or decreases all height dimensions from the dimensions shown by the same amount as the legs are lengthened or shortened.

  • Page 16: Machine Serial Number

    Main document number Typical Applications FILE ERX-15 Eastey ERX-15 Automatic Case Erector This case erector can be used for a wide range of applications where case size minimum and minimum are within the minimum and maximum case size parameters specified in the Box Specifications table of the ERX-15 Case Erector Specifications.

  • Page 17: Unpacking

    We are willing to assist you in every reasonable manner to help you collect claims for loss or damage. However, this willingness on Eastey’s part does not make Eastey or its parent or related companies responsible for collections or claims or replacement of equipment damaged or lost in transit.
  • Page 18 18 Installation Forklift Tine Tubes Do This Do NOT Do This!

  • Page 19: Installation

    Installation 19 Installation Remove the shipping plastic covering the case erector and lift it up, off the shipping pallet. CAUTION! The ERX-15 Case Erection System is heavy and a forklift is recommended to move the machine safely off the shipping pallet.
  • Page 20 20 Installation 4. Avoid locating the case erector in an area that is too hot or too cold. Recommended ambient temperature range for operation of the case erector is between 32° F – 113° F (0° C – 45° C). When the case erector is positioned in the operating location you will need access to: 1.
  • Page 21 Installation 21 Move the case erector to its location. A forklift is recommended for moving the case erector. CAUTION! If the case erector must be lifted for moving, use proper equipment when lifting and moving it. A forklift is recommended to move the machine safely. See the illustration at the end of the previous section for location of tubes for forklift tines and recommended orientation for lifting.
  • Page 22 22 Installation Remove strapping intended to stabilize moving parts during transport Look for and remove straps for shipping in the locations indicated in the following illustrations. Attach the alarm signal light stack The Case Erector is shipped with the alarm signal light stack removed to protect it from being damaged in transit.
  • Page 23 Installation 23 A power cord (with optional electrical plug) should be installed by a licensed electrician. Connect the air line to the regulator. CAUTION! Before operating, ensure the following. 1. All shipping ties are removed. 2. The interior of the case erector is clear of any shipping materials or other items.

  • Page 24: Operation

    24 Operation Operation Before operating the Case Erector, be familiar with the machine controls and where they are located. Main Power On / Off Switch and E-Stop 1. Main Power — The main power switch is located on top of the main electrical cabinet enclosure, outside and to the right of the clear-window guard for the erected carton exit area.

  • Page 25: Control Panel

    Operation 25 Control Panel MAIN SCREEN ALARM MACHINE READY MACHINE IDLE MANUAL MODE AUTO MACHINE TO HOME MANUAL CONTROL MONITOR SETTINGS IN-LINE CONTINUOUS SCREEN MODE MODE SCREEN CONTINUOUS DEMAND AUTO CYCLE 0002, 843 005 007 CLEAR COUNTS CARTON OPEN CARTON OPEN Green Blue Start...

  • Page 26: Main Screen

    26 Operation 6. HMI Touchscreen – The HMI (Human Machine Interface) Touchscreen provides access to controls, status information, and programable settings of the case erector. Main Screen MAIN SCREEN ALARM MACHINE READY MACHINE IDLE MANUAL MODE AUTO MACHINE TO HOME MANUAL CONTROL MONITOR...

  • Page 27: Case Dimensions - Case Blank To Finished Carton

    Operation 27 Case Dimensions — Case Blank to Finished Carton To begin setup for each run of cases, you will need to know the desired finished size dimensions of the case. The dimensions of the finished cases relate directly to the case blanks as shown in the following illustration.

  • Page 28: Hand Cranks And Locations For Machine Adjustments

    28 Operation Hand Cranks and Locations for Machine Adjustments Hand cranks for making adjustments for dimensional changes in case sizes are on the outside of the case erector and are labeled with numbers 1 through 5. Adjustments 6 and 7 are inside the case erector enclosure and are not labeled with numbers. The following illustration shows the locations of the five hand cranks.

  • Page 29: Machine Adjustments

    Operation 29 Machine Adjustments Following is a short outline of how the seven adjustments (five crank handle adjustments and two internal adjustments) relate to the dimensions of the case blank and resulting erected case: Adjustment 1: Magazine Hopper adjustment for Case Width; the width of the case minor panel, W.
  • Page 30 30 Operation Check to make sure the pushdown bracket bar will not crash into sensor brackets. NOT OK Check to make sure magazine belts and pusher paddles will not crash into sensor brackets. NO BOX SENSOR LOW BOX SENSOR Making Initial Settings VIDEO: ERX-15 Case Erector –...
  • Page 31 Operation 31 VIDEO: ERX-15 Case Erector Box Width Adjustment To see a video to guide you through this adjustment for setting up the ERX-15 case blank width, click this link: https://www.youtube.com/watch?v=Ix6dONOnPGw or scan the QR code at right using the camera app on your mobile device. 1.
  • Page 32 32 Operation VIDEO: ERX-15 Case Erector Box Height Adjustment To see a video to guide you through this adjustment for setting up the ERX-15 case blank height, click this link: https://www.youtube.com/watch?v=VjSQN4sUhLs&list=PLw2fFM1Tj1XV lqawAzk0PZmhsFO16VsZo&index=2 Or scan the QR code at right using the camera app on your mobile device.
  • Page 33 Operation 33 VIDEO: ERX-15 Case Erector Staging Area Adjustment To see a video to guide you through this adjustment for setting up the staging area adjustment, click this link: https://www.youtube.com/watch?v=vTIuezBxdG8 or scan the QR code at right using the camera app on your mobile device. 1.
  • Page 34 34 Operation 3. Adjust hand crank 4 up or down until the scored line on the box matches the dashed line on the back or the staging area. Align Crease with Dashed Line VIDEO: ERX-15 Case Erector Push-Down Bracket Adjustment To see a video to guide you through this adjustment of the height of the push-down bracket,...
  • Page 35 Operation 35 VIDEO: ERX-15 Case Erector Case Holdback Pin Alignment To see a video to guide you through adjustment for alignment of the case holdback pin, click this link: https://www.youtube.com/watch?v=5cTzmXwu9DA or scan the QR code at right using the camera app on your mobile device. The pin in the bottom plate below the case blank is instrumental in the opening and expanding the blank as it is being erected.
  • Page 36 36 Operation VIDEO: ERX-15 Case Erector Suction Cup Adjustment To see a video to guide you through adjustment of the suction cups, click this link: https://i.ytimg.com/an_webp/aCLeCY7mekY/mqdefault_6s.webp?du=30 00&sqp=CNb5_PwF&rs=AOn4CLAq8MZWvpwhqsDfpS_CLcA1LYpT1A or scan the QR code at right using the camera app on your mobile device.
  • Page 37 Operation 37 3. Suction cups can be repositioned by loosening the handles on the outside of the bracket and then moving the set of suction cups. 4. Position the suction cups so the weight of each carton will be distributed evenly by each pair of cups.
  • Page 38 38 Operation 5. When the suction cups are positioned correctly, retighten handles to secure the suction cups in position. Note: When positioning the suction cups take care to make sure the suction cup will not interfere with the sensor plate of the magazine when swinging back to pull the next case blank.
  • Page 39 Operation 39 Position unused suction cups to the outside of case panels and retighten positioning handles of all suction cups to secure them in position. Shut off the valve to the unused suction cups. The valve label placed on the case expander crossbeam shows the valve position for Open (1) or Closed (0).
  • Page 40 40 Operation VIDEO: ERX-15 Case Erector Exit Belt Width Adjustment To see a video to guide you through adjustment of the case erector exit belt width, click this link: https://www.youtube.com/watch?v=Ix6dONOnPGw or scan the QR code at right using the camera app on your mobile device. 1.
  • Page 41 Operation 41 VIDEO: ERX-15 Case Erector Loading and Threading the Tape Cartridge To see a video to guide you through threading tape in the case erector tape cartridge, click this link: https://www.youtube.com/watch?v=OR0Nct4fz3k or scan the QR code at right using the camera app on your mobile device. Loading the Tape Cartridges Turn the main power switch to “Off”...
  • Page 42 42 Operation Check Tension Check the tape for correct tension. Tighten or loosen the tape core holder to adjust tension. Thread Tape Carefully thread the new tape through the rollers in the tape head as shown in the applicable diagram in the Tape Head User Guide provided with the tape head. The following diagram shows the path for the tape in a typical tape head used with the ERX-15 Case Taper.
  • Page 43 Operation 43 Center Tape Make sure the tape is centered on all the rollers. There are several rollers in the tape cartridge where the tape alignment should be checked to verify the tape stays on center as it is being dispensed. Return the tape cartridge to the operation position.
  • Page 44 44 Operation VIDEO: ERX-15 Case Erector Tape Sensor Adjustments To see a video to guide you through tape sensor adjustments, click this link: https://www.youtube.com/watch?v=gqVVuNN3z-c or scan the QR code at right using the camera app on your mobile device. Tape sensors are located down below the tape head mounting area and are visible through the space between the tape head and the belt nearest the main electrical enclosure.
  • Page 45 Operation 45 The position of the tape low sensor can be adjusted to determine how low the tape supply can be before the low tape alarm is triggered. Tape Sensor Bracket Tape Break Tape Low Sensor Sensor Adjustment To trigger the tape low condition when less tape remains on the roll, reposition the tape low sensor closer to the center of the tape core;...
  • Page 46 46 Operation 3. Press the case blank stack against the machine, tightly at the top and bottom. 4. Once all case blanks are in position, place the slotted paddles behind the case blank stack. Close the case magazine pusher paddles to hold the case blank stack.
  • Page 47 Operation 47 VIDEO: ERX-15 Case Erector Single Case Test Run To see a video to guide you through jogging a single case through the case erector to use the full jog run function to test the settings made to this point, click this...
  • Page 48 48 Operation In Jog mode, each press of the green button will advance the case one step ahead through each of the steps MAIN SCREEN ALARM MACHINE READY involved in the process of erecting a case, from case MACHINE IDLE MANUAL MODE AUTO MACHINE...
  • Page 49 Operation 49 3. With the next jog, the case opening frames swing into the central erector space, opening the box. Check to see that the box corners are square at 90°. If necessary, adjust the left/right hand crank for centering the box. Note that as each case is swung out and opened, another case blank is advanced into the staging area from the magazine hopper and pushed down onto the base frame plate.
  • Page 50 50 Operation At the same time the major flaps are being closed, the suction cups will release and withdraw from the carton. 5. The box feeder will then push the erected box into the taper area for a bottom tape seal.
  • Page 51 Operation 51 VIDEO: ERX-15 Case Erector HMI Manual Control Settings To see a video to guide you through using the HMI manual control settings, click this link: https://www.youtube.com/watch?v=8yukcCA6bLI or scan the QR code at right using the camera app on your mobile device.

  • Page 52: Manual Control Screen

    52 Operation Manual Control Screen From the Manual Control Screen, allows for the operation each machine function manually and independently. Buttons at the top of the Manual Control Screen provide quick access to the Home Main Screen, the Monitor Screen and NOTE: Several of the buttons in the Manual Control Screen have small indicators with a letter and number at a corner or...
  • Page 53 Operation 53 Magazine Forward The Magazine Forward buttons provide manual control to advance the magazine belts forward. The two belts, one each side, can be operated individually. • W-Side is for the case blank width-side conveyor • L-Side is for the case blank length-side conveyor. W-Side or Width Side L-Side or...
  • Page 54 54 Operation Separator Suction Cup The separator suction cups can be extended, or suction activated by touching the buttons in this section of the Manual Control Screen. Carton Suction Cup The carton-opener structure can be extended to pick up position or returned back to home and carton suction cups can be extended or suction activated by touching the buttons in this section of the Manual Control Screen.
  • Page 55 Operation 55 Driving Belt The driving belt refers to the exit conveyor belts that move the erected case through the base sealing area and out through the exit of the case erector. The driving belt motor can be turned on to run or shut off using the button in this section. Minor Flap Folding The minor flap folding mechanism can be activated to execute the minor flap folding motion.
  • Page 56 56 Operation Major Flap Folding The major flap folding mechanism can be activated to rise, perform the major flap folding motion, and return down. Carton Feed Pusher The carton feed pusher can be activated to perform the carton feed motion and to return it back to home position.
  • Page 57 Operation 57 VIDEO: ERX-15 Case Erector Continuous and On Demand Mode To see a video to guide you through using the full jog run function, click this link: https://www.youtube.com/watch?v=fVJ_jlFGNvE or scan the QR code at right using the camera app on your mobile device. There are two modes of operation of the ERX-15 case taper.
  • Page 58 58 Operation Every Delay Timer Settings allows you to insert in a delay for every action the case erector makes to process a case from collapsed blank to erected, bottom-sealed carton. This can be helpful in troubleshooting any problems that may occur in forming specific cases.
  • Page 59 Operation 59 VIDEO: ERX-15 Exit Box Sensor Modes To see a video explaining the exit box sensor modes, click this link: https://www.youtube.com/watch?v=sU4-K3c2Pws or scan the QR code at right using the camera app on your mobile device. There are two modes for the Exit Box Sensors. •...
  • Page 60 60 Operation VIDEO: ERX-15 Case Erector Retreat Speed Settings To see a video explaining the retreat speed settings, click this link: https://www.youtube.com/watch?v=66qvLu5ykr8 or scan the QR code at right using the camera app on your mobile device. There are two available settings for Opener Retreat Speed, Low and High.

  • Page 61: Monitoring Screens

    Operation 61 Monitoring Screens There are three screens for monitoring functions of the ERX-15 Case Erector. They are divided by functional areas of the Case Erector. • Magazine Hopper Area • Taping Area • Carton Opening Area Monitor Magazine The Monitor Magazine screen is a reference that allows you to inspect each sensor or valve in the magazine hoper area of the case erector to see that they are functioning normally.
  • Page 62 62 Operation Monitor Carton Open The Monitor Carton Open screen allows you to inspect sensors and valves in the carton opening area of the case erector to see if they are functioning normally. This screen also allows setting the values of important parameters. •...
  • Page 63 Operation 63 Component Description To see descriptions of the valves and sensors pictured, touch the Component Description button. Monitor Taping...

  • Page 64: Alarms

    64 Operation Alarms The Alarms screen displays system alarms, both current and past. The screen is divided into two windows: the top window shows currently active alarms; and the lower window shows a scrolling list of alarms that have been recorded by the system. Return Touch the Return Button to return to the system Main screen.
  • Page 65 Operation 65 Emergency Stop Press the E-Stop (Emergency Stop) to stop all machine motion in the event of an emergency. To reset after the emergency situation has been cleared, turn the E-Stop button a quarter-turn to release the switch. Reset Button After an Emergency Stop, and the emergency situation has been cleared, reset the E-Stop button as described above and press the Reset button to reset the machine...

  • Page 66: Adjustments

    66 Adjustments Adjustments Shut off power and disconnect electrical connections before making any adjustments. WARNING: Unless otherwise specifically stated, before performing any adjustments, maintenance, or repairs, power off the system, disable the power source, and do the same for all connected equipment consistent with logout/tagout best practices.
  • Page 67 Adjustments 67 1. To adjust the belt tension, begin by loosening the screw through the center of the roller, shown in position “A” in the following illustration, that secures the roller in place. Intake Belt Taping Area Exit Belt 2. Adjust tension by tightening or loosening the tensioning screw in position “B.” 3.

  • Page 68: Hand Crank And Case Size Dimension Adjustments

    68 Adjustments Hand Crank and Case Size Dimension Adjustments Adjustments to the case erector to accommodate case dimensional size changes are made by turning hand cranks on the outside of the case erector. These cranks are labeled with numbers 1 through 5. Adjustments 6 and 7 are inside the case erector enclosure and are not labeled.
  • Page 69 Adjustments 69 Adjustment 3: Case Height plus the Case Width; the overall height of the case blank. W/2 + H + W/2, or simply H + W. Adjustment 4: Half of the Case Width; the width of a case flap or W/2. Adjustment 5: Case Width;...
  • Page 70 70 Adjustments Case Blank Dimensions Blank Thickness = 2 × T For practical ≈ purposes, consider the case blank Score Line thickness (T ) to be approximately equal to twice the case Major Minor wall thickness (T Panel Panel ≈ Position the suction cups so they will be centered vertically on the panels, and spaced at regular intervals horizontally at approximately one-third and two-thirds of each panel when they grip each case.
  • Page 71 Adjustments 71 ≈ ≈ ≈ ≈ ≈ ≈ ≈ Major Minor Panel Panel Score Line ≈ For cases with one or both panels too small for both pairs of suction cups, use only the inner pair of suction cups, aligned to be centered on the panel, and shut off vacuum to the outer pair.
  • Page 72 72 Adjustments To reposition suction cups on either case-opening frame (long side or wide side), loosen the lever on the back frame corresponding to the cups to be moved. Move the suction cups to the required position and then re-tighten the lever to secure the suction cups in place.

  • Page 73: Maintenance

    Maintenance 73 Maintenance WARNING: Unless otherwise specifically stated, before performing any adjustments, maintenance, or repairs, power off the system, disable the power source, and do the same for all connected equipment consistent with logout/tagout best practices. https://www.osha.gov/control-hazardous-energy scan the QR code at right using the camera app on your mobile device.

  • Page 74: Cleaning Exterior Surfaces

    74 Maintenance  Adjustment hand cranks: every 250 hours of operation, apply a small amount of silicone to the end of each spring where the loop is secured to an eyelet. Wipe off excess silicone as it will attract dust which can cause premature equipment wear and jamming.

  • Page 75: Troubleshooting

    Troubleshooting 75 Troubleshooting The following table provides troubleshooting information for identifying and correcting possible problems. Problem Possible Cause Corrective Action 1. Suction cups do not 1. Is there sufficient air 1. Verify air supply meets grab case blanks well. supply pressure? specifications: 80 PSI @ 12 CFM.
  • Page 76 76 Troubleshooting Problem Possible Cause Corrective Action correctly? time setting if necessary. 5. Is the score line aligned 5. Check to make sure the correctly with the scoring line is aligned separator pin? correctly with the separator pin. 3. Cases do not open to 1.
  • Page 77 Troubleshooting 77 Problem Solution Tape Folding • Check that all rollers turn freely. • Check to be sure tape is threaded properly on front roller (page Error! Bookmark not defined.). • Check wipe down brush. Tape Curling and Bunching Up •...

  • Page 78: Parts

    78 Parts Parts Case Erector Case Erector Item Part Number Description Reference Q’ty 5030775 Forming Unit 5030776 Magazine Unit...

  • Page 79: Forming Unit

    Parts 79 Forming Unit...
  • Page 80 80 Parts Forming Unit Item Part Number Description Reference Q’ty 5030778 Machine Body 5030779 Taper Unit 5030780 Major Flap Closer Unit 5030781 Motor, 220V/380V P0503-0009300 5030782 Opener-W Unit 5030783 Opener-L Unit 5030784 Opener Guide Unit 5030785 Opener Cart Unit 5030786 Opener Track Unit 5030787 Box Feeder Unit...
  • Page 81 Parts 81 Forming Unit Item Part Number Description Reference Q’ty 5030811 Motor Arm Spacer P01-0610700 5030778 Bracket P01-052640A 5030812 Vacuum Generator Seat 5030813 Vacuum Generator P0319-C13748 5030814 Fix Plate 5030815 Door P06-006160A 5030816 Door P06-006140A 5030817 Handle P1112-0000700 5030818 Hinge P1110-020000500 5030819 Magnetic...

  • Page 82: Taper Unit

    82 Parts Taper Unit...
  • Page 83 Parts 83 Taper Unit Item Part Number Description Reference Q’ty 5030831 Left Belt Unit 5030832 Taper Frame Unit 5030833 Adjust Front Unit 5030834 Adjust Rear Unit 5030835 Roller P08-0003900 5030836 Right Belt Unit 5030837 Minor Flap Closer Unit 5030838 Sliding Block P02-032690A 5030839 Sprocket...

  • Page 84: Left Belt Unit

    84 Parts Left Belt Unit...
  • Page 85 Parts 85 Left Belt Unit Item Part Number Description Reference Q’ty 5030853 Motor Seat P02-0080300 5030854 Spacer P02-0080400 5030855 Bearing P1104-0262032RS0 5030856 Motor Shaft P02-0323400 5030857 Bearing P1104-026003ZZ0 5030858 Shaft Connect P1121-0000100 5030859 Belt Motor - Left P0503-0011300 5030860 Driving Pulley P06-0061200 5030861 Belt Seat...

  • Page 86: Right Belt Unit

    86 Parts Right Belt Unit...
  • Page 87 Parts 87 Right Belt Unit Item Part Number Description Reference Q’ty 5030853 Motor Seat P02-0080300 5030854 Spacer P02-0080400 5030855 Bearing P1104-0262032RS0 5030856 Motor Shaft P02-0323400 5030857 Bearing P1104-026003ZZ0 5030858 Shaft Connect P1121-0000100 5030881 Belt Motor - Right P0503-0012100 5030860 Driving Pulley P06-0061200 5030882 Belt Seat...

  • Page 88: Taper Frame Unit

    88 Parts Taper Frame Unit Taper Frame Unit Item Part Number Description Reference Q’ty 5030891 SEAT-LEFT 5030892 BRACKET 5030893 SENSOR PLATE 5030894 MOUNTING BLOCK P01-013510A 5030895 SENSOR PLATE 5030896 ROLLER BRACKET 5030897 GUIDE PLATE 5030898 MOUNTING BLOCK P01-013520A 5030899 CONNECT PLATE 5030900 SEAT-RIGHT 5030901...

  • Page 89: Adjust Front Unit

    Parts 89 Adjust Front Unit Adjust Front Unit Item Part Number Description Reference Q’ty 5030793 SCREW M6*12L P1101-0906012AN 5030904 BUSHING P02-0088800 5030905 SPROCKET P0702-0010500 5030906 FIX RING P02-0083500 5030907 SEAT P01-0135000 5030908 THREAD ROD FRONT P02-032830A 5030909 SUPPORT...

  • Page 90: Adjust Rear Unit

    90 Parts Adjust Rear Unit Adjust Rear Unit Item Part Number Description Reference Q’ty 5030904 BUSHING P02-0088800 5030905 SPROCKET P0702-0010500 5030911 THREAD ROD REAR P02-032680B 5030906 FIX RING P02-0083500 5030907 SEAT P01-0135000 5030912 INDICATOR P1130-0000100 5030913 HANDLE P1112-0000300 5030914 SUPPORT...

  • Page 91: Minor Flap Closer Unit

    Parts 91 Minor Flap Closer Unit...
  • Page 92 92 Parts Minor Flap Closer Unit Item Part Number Description Reference Q’ty 5030916 SEAT 5030917 ROD END P1104-060000800 5030918 FIX PLATE P01-0535000 5030919 MINOR FLAP CLOSER P01-053480B 5030920 PIN SHAFT P02-0326600 5030921 STOPPER P01-053520B 5030922 BUSHING P1104-081012100 5030923 SHOULDER SCREW P02-0081600 5030924 BUSHING...

  • Page 93: Major Flap Closer Unit

    Parts 93 Major Flap Closer Unit...
  • Page 94 94 Parts Major Flap Closer Unit Item Part Number Description Reference Q’ty 5030927 WASHER 8 P1103-010816C5Z 5030931 ROD END P0403-050000200 5030932 I CONNECTOR P0403-020000600 5030933 P02-0325600 5030934 MAJOR FLAP CLOSER SEAT UNIT 5030935 STOPPER P01-0613800 5030936 BEVEL GEAR P0701-0003000 5030793 SCREW M6*12L P1101-0906012AN 5030937...
  • Page 95 Parts 95 Major Flap Closer Unit Item Part Number Description Reference Q’ty 5030959 SLIDING BLOCK P1104-140000800 5030960 FIX SEAT - RIGHT P01-053320A 5030961 LINEAR BUIDE P1104-140000900 5030732 CYLINDER SENSOR P0319-C13747 5030736 CYLINDER SENSOR P0319-C13748...

  • Page 96: Major Flap Closer Seat Unit

    96 Parts Major Flap Closer Seat Unit Major Flap Closer Seat Unit Item Part Number Description Reference Q’ty 5030963 Connect Block 5030964 Seat 5030965 Fix Block 5030793 Screw M6*12L P1101-0906012AN...

  • Page 97: Left Seat Unit

    Parts 97 Left Seat Unit...
  • Page 98 98 Parts Left Seat Unit Item Part Number Description Reference Q’ty 5030967 Seat - Left 5030968 Bearing P1104-026205ZZ0 5030969 Bearing Seat P02-032590A 5030970 Block 5030971 Bearing P1104-026202ZZ0 5030972 Sliding Block P1104-140001000 5030973 Shaft Fixer - Front 5030974 Shaft Fixer - Rear 5030975 Connect Block 5030976...

  • Page 99: Right Seat Unit

    Parts 99 Right Seat Unit Right Seat Unit Item Part Number Description Reference Q’ty 5030982 Block 5030983 Connect Block 5030984 Seat - Right 5030969 Bearing Seat P02-032590A 5030968 Bearing P1104-026205ZZ0 5030972 Sliding Block P1104-140001000 5030985 Adjust Block P02-0328400...

  • Page 100: Opener-W Unit

    100 Parts Opener–W Unit...
  • Page 101 Parts 101 Opener–W Unit Item Part Number Description Reference Q’ty 5030987 FIX PLATE 5030988 SHAFT P02-0323500 5030989 LINEAR BUSHING P1104-01100 5030990 SUCTIONS SEAT P02-032360B 5030991 SUCTIONS FIX PLATE - LEFT P01-0531300 5030992 SUCTIONS UNIT 5030993 CONNECTOR 90 DEGREE P0401-0001200 5030994 BRACKET - RIGHT 5030995 BRACKET - LEFT...

  • Page 102: Opener-L Unit

    102 Parts Opener–L Unit...
  • Page 103 Parts 103 Opener–L Unit Item Part Number Description Reference Q’ty 5031002 Fix Plate 5031003 Shaft P02-0323700 5030989 Linear Bushing P1104-01100 5030990 Suctions Seat P02-032360B 5031004 Cylinder Fix Plate 5031005 Suctions Fix Plate P01-0531200 5031013 Suctions Unit 5030993 Connector 90 Degree P0401-0001200 5031006 Bracket - Left...

  • Page 104: Suction Unit

    104 Parts Suction Unit Suction Unit Item Part Number Description Reference Q’ty 5031014 Connector P02-0330100 5030745 Suction Cups P0407-020000200...

  • Page 105: Opener Guide Unit

    Parts 105 Opener Guide Unit...
  • Page 106 106 Parts Opener Guide Unit Item Part Number Description Reference Q’ty 5031016 Guide Left 5031017 Connect Plate 5031018 Cable Chain Fixer 5031019 Sensor Plate P01-0532300 5031020 Fix Plate 5031021 Screw M5*12L P1101-0905012AN 5031022 Guide Right 5031023 Sliding Guide P1104-140000300 5031024 Spacer 5030793 Screw M6*12L...

  • Page 107: Opener Cart Unit

    Parts 107 Opener Cart Unit Opener Cart Unit Item Part Number Description Reference Q’ty 5031026 Seat P02-032860A 5031027 Connect Shaft P02-032540B 5031028 Sliding Block P1104-140000400 5030999 Bearing P1104-220000100...

  • Page 108: Opener Track Unit

    108 Parts Opener Track Unit Opener Track Unit Item Part Number Description Reference Q’ty 5031030 Support Bracket P01-0541800 5031031 Sliding Guide P1104-140000700...

  • Page 109: Box Feeder Unit

    Parts 109 Box Feeder Unit...
  • Page 110 110 Parts Box Feeder Unit Item Part Number Description Reference Q’ty 5031033 Motor Seat 5031034 Drive Seat 5031035 Feeder Motor P0503-0018700 5031036 Belt P0902-0008800 5031037 Driving Pulley P02-0329900 5031038 Driven Pulley P02-0329800 5031039 Belt Clamp P02-0330000 5031040 Fix Plate P01-0534600 5031041 Pully Shaft P02-0326500...

  • Page 111: Stand Unit

    Parts 111 Stand Unit Stand Unit Item Part Number Description Reference Q’ty 5031055 5031056 Clamp 5031057 Fix Plate 5030849 Screw M10*25L P1101-0910025AN 5031058 Screw M6*12L P1101-0506012AN 5031059 Stand P1111-0001500...

  • Page 112: Top Pusher Unit

    112 Parts Top Pusher Unit Top Pusher Unit Item Part Number Description Reference Q’ty 5031061 Right Guide Unit 5031062 Pusher Unit 5031063 Left Guide Unit...

  • Page 113: Right Guide Unit

    Parts 113 Right Guide Unit...
  • Page 114 114 Parts Right Guide Unit Item Part Number Description Reference Q’ty 5031065 Shaft P02-0324400 5031066 Thread Rod P02-032470A 5031067 Thread Rod Seat P02-0328900 5031068 Cylinder Fix Plate 5031069 Seat P02-0324800 5030971 Bearing P1104-026202ZZ0 5030849 Screw M10*25L P1101-0910025AN 5030906 Fix Ring P02-0083500 5031070 Linear Bushing...

  • Page 115: Left Guide Unit

    Parts 115 Left Guide Unit...
  • Page 116 116 Parts Left Guide Unit Item Part Number Description Reference Q’ty 5031065 Shaft P02-0324400 5031079 Thread Rod P02-032490A 5031070 Linear Bushing P1104-01200 5031080 Bracket 5031081 C Clip P1105-0132B 5031069 Seat P02-0324800 5030971 Bearing P1104-026202ZZ0 5030849 Screw M10*25L P1101-0910025AN 5030906 Fix Ring P02-0083500 5031074 Connector...

  • Page 117: Pusher Unit

    Parts 117 Pusher Unit...
  • Page 118 118 Parts Pusher Unit Item Part Number Description Reference Q’ty 5031089 Roller Shaft - W P02-0354600 5031090 Roller - W P06-006800A 5031091 Holding Plate - W P01-0566300 5031092 Washer P1103-01102502Z 5031093 Roller - L P06-0073500 5031094 Knob P1113-0003800 5031095 Roller Shaft - L P02-0354500 5031096 Holding Plate - L...

  • Page 119: Top Adjust Unit

    Parts 119 Top Adjust Unit...
  • Page 120 120 Parts Top Adjust Unit Item Part Number Description Reference Q’ty 5030980 Bushing Seat P01-0135000 5031108 Shaft P02-0325000 5031109 Cover P06-0022600 5031110 Seat P02-0326300 5030976 Bushing P1104-0315100 5031021 Screw M5*12L P1101-0905012AN 5030978 Bevel Gear P0701-0004400 5030906 Fix Ring P02-0083500 5031111 Indicator P1130-0000200 5030913...

  • Page 121: Opener Cart Guide Unit

    Parts 121 Opener Cart Guide Unit Opener Cart Guide Unit Item Part Number Description Reference Q’ty 5031113 Seat Plate 5031114 Linear Guide P1104-140001200...

  • Page 122: Exit Guard Unit

    122 Parts Exit Guard Unit...
  • Page 123 Parts 123 Exit Guard Unit Item Part Number Description Reference Q’ty 5030819 Magnetic P1106-020000100 5031116 Door Bracket 5031117 Door Frame - Left 5031118 Door - Left P06-0061500 5031119 Fix Plate P01-0080500 5031120 Door - Right P06-0061700 5030817 Handle P1112-0000700 5031121 Screw M5*30l P1101-0305030AS 5030818...

  • Page 124: Adjust Connect Unit

    124 Parts Adjust Connect Unit...
  • Page 125 Parts 125 Adjust Connect Unit Item Part Number Description Reference Q’ty 5031125 Seat 5031126 Shaft P02-0394000 5031127 Bearing Seat P06-0022500 5030971 Bearing P1104-026202ZZ0 5030936 Bevel Gear P0701-0003000 5030980 Bushing Seat P01-0135000 5031128 Cover 5030906 Fix Ring P02-0083500 5030978 Bevel Gear P0701-0004400 5030869 Screw M8*20l...

  • Page 126: Electric Box Unit

    126 Parts Electric Box Unit...
  • Page 127 Parts 127 Electric Box Unit Item Part Number Description Reference Q’ty 5031132 Electric Box 5031133 Electric Door 5030818 Hinge P1110-020000500 5031134 Electric Fix Plate 5031135 Emergency Stop Button P0313-010006300 5031136 Emergency Stop Sticker P1001-0001400 5031137 Pneumatic Box 5031138 Cover P06-006680A 5031139 Cable Fixer...

  • Page 128: Opener Drive Unit

    128 Parts Opener Drive Unit Opener Drive Unit Item Part Number Description Reference Q’ty 5031141 Drive Roller P06-006180C 5031142 Bearing P1104-020626ZZ0 5031143 Screw M6*30L P1101-0506030AN 5031144 Spacer P02-0392700...

  • Page 129: Magazine Unit

    Parts 129 Magazine Unit...
  • Page 130 130 Parts Magazine Unit Item Part Number Description Reference Q’ty 5031146 Magazine Base Unit 5031147 Base Plane Unit 5031213 Adjust Connect Unit 5031148 Magazine Belt-Right Unit 5031149 Magazine Belt-Left Unit 5031150 Shaft P02-0354300 5031151 Separate Suction Unit 5031152 Cover 5031153 Cover 5031154 Cover...

  • Page 131: Magazine Base Unit

    Parts 131 Magazine Base Unit...
  • Page 132 132 Parts Magazine Base Unit Item Part Number Description Reference Q’ty 5031161 Bush Seat P01-0135000 5031162 Thread Rod - Left P02-032220A 5031163 Thread Rod -Right P02-0322400 5030906 Fix Ring P02-0083500 5031164 Frame 5030912 Indicator P1130-0000100 5031165 Centering Plate 5030905 Sprocket P0702-0010500 5031166 Base Plate...

  • Page 133: Magazine Guide Unit

    Parts 133 Magazine Guide Unit Magazine Guide Unit Item Part Number Description Reference Q’ty 5031174 Support 5031175 Linear Guide P1104-140001100 5031021 Screw M5*12L P1101-0905012AN...

  • Page 134: Cable Fixer Unit

    134 Parts Cable Fixer Unit Cable Fixer Unit Item Part Number Description Reference Q’ty 5031177 Fix Plate 5031021 Screw M5*12L P1101-0905012AN 5031178 Cover...

  • Page 135: Base Plane Unit

    Parts 135 Base Plane Unit Base Plane Unit Item Part Number Description Reference Q’ty 5031177 Extension Shaft Unit 5031021 Bevel Gear P0701-0003000...
  • Page 136 136 Parts Base Plane Unit Item Part Number Description Reference Q’ty 5031178 Bevel Gear P0701-0004400 5031179 Shaft P02-0328100 5031180 Seat P02-0328900 5030936 Shaft P02-0322700 5030978 Spring P1202-0004700 5031181 Screw M5*25L P1101-0505025AN 5031182 Sensor Plate P01-0535400 5031183 Seat P02-0392800 5031184 Screw M5*12L P1101-0905012AN 5031185 Lift Thread Rod...

  • Page 137: Extension Shaft Unit

    Parts 137 Extension Shaft Unit Extension Shaft Unit Item Part Number Description Reference Q’ty 5031207 Bracket 5031208 Extension Shaft P02-0328700 5031209 Bushing P01-0135000 5030906 Fix Ring P02-0083500 5030912 Indicator P1130-0000100...

  • Page 138: Idle Sprocket Unit

    138 Parts Idle Sprocket Unit Idle Sprocket Unit Item Part Number Description Reference Q’ty 5031211 Sprocket Fix P02-032530A 5031212 Sprocket P0702-0004700 5030922 Bushing P1104-081012100...

  • Page 139: Adjust Connect Unit

    Parts 139 Adjust Connect Unit Adjust Connect Unit Item Part Number Description Reference Q’ty 5031214 Frame 5031215 Fix Block P02-0060900 5031216 Thread Rod P02-0323900 5031217 Fix Block P02-0060800 5031218 Shaft P02-0324000 5031219 Cover 5030905 Sprocket P0702-0010500 5031067 Thread Rod Seat P02-0328900 5031220 Cover...

  • Page 140: Magazine Belt - Right Unit

    140 Parts Magazine Belt – Right Unit...
  • Page 141 Parts 141 Magazine Belt – Right Unit Item Part Number Description Reference Q’ty 5031226 Base Plate 5031227 Bearing P1104-076004ZZ1 5031228 Spacer Block P02-0353200 5031229 Belt P0902-000870A 5031230 Shaft-Long P02-0353400 5031231 Shaft-Short P02-0353500 5030793 Screw M6*12L P1101-0906012AN 5031232 C Clip P1105-0120B 5031233 Driven Pulley P06-0073000...
  • Page 142 142 Parts Magazine Belt – Right Unit Item Part Number Description Reference Q’ty 5031255 Advance Cylinder - Right P0319-C13744 5031256 Cylinder Fixer P0403-020000700 5031257 Rod End P1104-060000100 5031258 Holding Plate P02-035150A 5031259 Fix Block P02-0353300 5031260 Driving Pulley P06-0073100 5030817 Handle P1112-0000700 5031261...
  • Page 143 Parts 143 Magazine Belt – Right Unit Item Part Number Description Reference Q’ty 5031283 Spring Washer 6 P1103-0206Z 5031284 Nut M6 P1102-0106BZ 5031285 Ring P06-0073200 5031286 No Box Sensor P0319-C13725 5031287 Low Box Sensor P0319-C13726...

  • Page 144: Sensor Plate - Right Unit

    144 Parts Sensor Plate – Right Unit...
  • Page 145 Parts 145 Sensor Plate – Right Unit Item Part Number Description Reference Q’ty 5031289 Bracket P01-0526900 5030976 Bushing P1104-0315100 3.1 5031290 Right Upper Sensor P0319-C13727 3.2 5031291 Right Lower Sensor P0319-C13729 5031292 Sensor Plate P01-0527100 5031293 Roller Shaft P02-0322800 5031294 Sensor Roller P06-0062200 5030922...

  • Page 146: Bottom Guide - Right Unit

    146 Parts Bottom Guide – Right Unit Bottom Guide – Right Unit Item Part Number Description Reference Q’ty 5031307 Support Bracket 5031308 Shaft P02-0327500 5031309 Bottom Guide P06-006230B 5031310 Fix Ring P02-0324300 5031311 Linear Bushing P1104-01060 5031103 Spring P1201-0003300...

  • Page 147: Magazine Belt - Left Unit

    Parts 147 Magazine Belt – Left Unit...
  • Page 148 148 Parts Magazine Belt – Right Unit Item Part Number Description Reference Q’ty 5031313 Base Plate 5031314 Base 5031315 Base Plate 5031316 Base Plate 5031260 Driving Pulley P06-0073100 5031227 Bearing P1104-076004ZZ1 5031317 Pulley Shaft P02-0353600 5031244 Shaft P02-0047500 5031246 Bearing P1104-17HF25200 5031245 P01-010430A...
  • Page 149 Parts 149 Magazine Belt – Right Unit Item Part Number Description Reference Q’ty 5031252 Linear Bushing P1104-01201 5031234 Belt P0902-000920A 5031326 Advance Plate P01-0526100 5031264 Stopper P06-006690A 5031247 Driven Pulley P06-0072900 5031327 Support Block P02-0353300 5031328 Support Plate 5031329 Support Plate 5031263 Ring P02-035370A...

  • Page 150: Bottom Guide - Left Unit

    150 Parts Bottom Guide – Left Unit Bottom Guide – Left Unit Item Part Number Description Reference Q’ty 5031308 Shaft P02-0327500 5031309 Bottom Guide P06-006230B 5031310 Fix Ring P02-0324300 5031338 Support Bracket P01-052820A 5031311 Linear Bushing P1104-01060 5031103 Spring P1201-0003300...

  • Page 151: Sensor Plate - Left Unit

    Parts 151 Sensor Plate – Left Unit...
  • Page 152 152 Parts Sensor Plate – Left Unit Item Part Number Description Reference Q’ty 1.1 5031340 Left Upper Sensor P0319-C13728 1.2 5031341 Left Lower Sensor P0319-C13730 5031342 Sensor Adjust Plate P01-0527100 5031293 Roller Shaft P02-0322800 5031294 Sensor Roller P06-0062200 5031343 Sensor Plate P01-052750A 5031295 Shaft...

  • Page 153: Separator Suction Unit

    Parts 153 Separator Suction Unit...
  • Page 154 154 Parts Separator Suction Unit Item Part Number Description Reference Q’ty 5031351 Seat 5031352 Suction Cup P0407-040000500 5031353 Shaft P02-032260A 5031354 Fix Plate P02-0393500 5031008 Connector P0401-0002600 5030752 Cylinder P0319-C13706 5030793 Screw M6*12L P1101-0906012AN 5031355 Cylinder Bracket P01-0541500 5031356 Cylinder Fix Plate P01-053090A 5031357 Shaft...

  • Page 155: Main Electrical Panel

    Parts 155 Main Electrical Panel February 21, 2020...

  • Page 156: Control Panel & Hmi

    156 Parts Control Panel & HMI February 21, 2020...
  • Page 157 Parts 157 Electrical Parts List Item Part Number Description Reference Q’ty 1Q2 5030701 ZH-HD-48-BY P0311-010002800 5S10 5030702 Pressure Detect P0319-C13715 5030703 Air Power Solenoid Valve Unit P0319-C13739 5030704 Sucker Solenoid Valve Unit P0319-C13740 5030705 Pressure Detect P0319-C13714 1Q2A 5030706 Fuse P0305-010002800 1Q4 5030707 Power Supply...
  • Page 158 158 Parts Electrical Parts List Item Part Number Description Reference Q’ty Photo Eye P0302-020000600 5030725 5030726 Cylinder Sensor P0319-C13747 PLC Expansion Module P0308-010005200 5030727 5030728 Proximity Switch P0319-C13727 5030729 Proximity Switch P0319-C13728 5030730 Cylinder Sensor P0319-C13748 5030731 Proximity Switch P0319-C13729 5030731 Proximity Switch P0319-C13719...

  • Page 159: Main Panel Pneumatic Controls

    Parts 159 Main Panel Pneumatic Controls...
  • Page 160 160 Parts February 21, 2020 Pneumatic Parts List Item Part Number Description Reference Q’ty 5030742 Description P0319-C13736 5S10 5030702 Air F.R.L Tube Fitting P0319-C13715 5030703 Pressure Detect P0319-C13739 5030704 Air Power Solenoid Valve Unit P0319-C13740 5030743 Sucker Solenoid Valve Unit P0319-C13748 5030705 Vacuum Generator...
  • Page 161 Parts 161 Pneumatic Parts List Item Part Number Description Reference Q’ty 5030750 Y-Connect P0401-0002500 5030751 Cylinder P0319-C13744 Cylinder P0319-C13722 5030752 Cylinder P0319-C13723 5030753 Cylinder P0319-C13745 5030754 Cylinder Sensor P0319-C13747 5030755 Cylinder Sensor P0319-C13748 5030756 Valve P0401-0013500 3V6A 5030757 Cylinder P0319-C13743 Cylinder P0319-C13724 5030758...

  • Page 162: A: Main Air In - Filter / Regulator, Fittings & Hose

    162 Parts A: Main Air In — Filter / Regulator, Fittings & Hose...

  • Page 163: B: Carton Push-Down Cylinders, Fittings & Hoses

    Parts 163 B: Carton Push-Down Cylinders, Fittings & Hoses...

  • Page 164: C: Carton Suction Cup Extension

    164 Parts C: Carton Suction Cup Extension...

  • Page 165: D: Separator Suction Cup Extension

    Parts 165 D: Separator Suction Cup Extension E: Separator Suction Cup Suction...

  • Page 166: F: Magazine Stopper Cylinder & Fittings

    166 Parts F: Magazine Stopper Cylinder & Fittings...

  • Page 167: G & K: Magazine Forward Cylinders - Long Side & Wide Side

    Parts 167 G & K: Magazine Forward Cylinders — Long Side & Wide Side...

  • Page 168: H: Minor Flap Folding Cylinders, Fittings & Hoses

    168 Parts H: Minor Flap Folding Cylinders, Fittings & Hoses...

  • Page 169: J: Major Flap Folding Rise Cylinders, Fittings & Hoses

    Parts 169 J: Major Flap Folding Rise Cylinders, Fittings & Hoses...

  • Page 170: M: Major Flap Folding Cylinders, Fittings & Hoses

    170 Parts M: Major Flap Folding Cylinders, Fittings & Hoses...

  • Page 171: L: Carton Suction Cups, Hoses & Fittings

    Parts 171 L: Carton Suction Cups, Hoses & Fittings...

  • Page 172: Appendix A: Electrical Schematics

    172 Appendix A: Electrical Schematics Appendix A: Electrical Schematics Electrical Schematic Page 1 of 12 February 21, 2020...

  • Page 173: Electrical Schematic

    Appendix A: Electrical Schematics 173 Electrical Schematic Page 2 of 12 February 21, 2020...

  • Page 174: Electrical Schematic Page 3 Of 12

    174 Appendix A: Electrical Schematics Electrical Schematic Page 3 of 12 February 21, 2020...

  • Page 175: Electrical Schematic Page 4 Of 12

    Appendix A: Electrical Schematics 175 Electrical Schematic Page 4 of 12 February 21, 2020...

  • Page 176: Electrical Schematic Page 5 Of 12

    176 Appendix A: Electrical Schematics Electrical Schematic Page 5 of 12 February 21, 2020...

  • Page 177: Electrical Schematic Page 6 Of 12

    Appendix A: Electrical Schematics 177 Electrical Schematic Page 6 of 12 February 21, 2020...

  • Page 178: Electrical Schematic Page 7 Of 12

    178 Appendix A: Electrical Schematics Electrical Schematic Page 7 of 12 February 21, 2020...

  • Page 179: Electrical Schematic Page 8 Of 12

    Appendix A: Electrical Schematics 179 Electrical Schematic Page 8 of 12 February 21, 2020...

  • Page 180: Electrical Schematic Page 9 Of 12

    180 Appendix A: Electrical Schematics Electrical Schematic Page 9 of 12 February 21, 2020...

  • Page 181: Electrical Schematic Page 10 Of 12

    Appendix A: Electrical Schematics 181 Electrical Schematic Page 10 of 12 February 21, 2020...

  • Page 182: Electrical Schematic Page 11 Of 12

    182 Appendix A: Electrical Schematics Electrical Schematic Page 11 of 12 February 21, 2020...

  • Page 183: Electrical Schematic Page 12 Of 12

    Appendix A: Electrical Schematics 183 Electrical Schematic Page 12 of 12 February 21, 2020...

  • Page 184: Appendix B: Pneumatic Schematic

    184 Appendix B: Air System Components Appendix B: Pneumatic Schematic Pneumatic Schematic Sheet 1 of 4...

  • Page 185: Pneumatic Schematic Sheet 2 Of 4

    Appendix B: Air System Components 185 Pneumatic Schematic Sheet 2 of 4...

  • Page 186: Pneumatic Schematic Sheet 3 Of 4

    186 Appendix B: Air System Components Pneumatic Schematic Sheet 3 of 4...

  • Page 187: Pneumatic Schematic Sheet 4 Of 4

    Appendix B: Air System Components 187 Pneumatic Schematic Sheet 4 of 4...

  • Page 188: Warranty Statement

    Eastey ERX-15 Automatic Case Erector Warranty Statement Eastey warrants that all of the products it ships will be in good working order and free from defects in material and workmanship and will conform to the published specifications for that product.
  • Page 189 Warranty Statement 189 PROFIT OR LOST OPPORTUNITIES OF ANY TYPE ARISING OUT OF THE USE OR INABILITY TO USE THESE PRODUCTS EVEN IF EASTEY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

  • Page 190: Customer Support

    For help setting up or operating the Eastey ERX-15, please contact Eastey Technical Service at one of the numbers listed below. Toll-Free Phone 800-835-9344 Phone 763-428-4846 763-795-8867 E-mail info@eastey.com www.eastey.com Thanks again for your purchase of Eastey products. We are pleased to be a part of your packaging needs.

This manual is also suitable for:

Erx-15

Table of Contents
