Eastey SB-2EX User Manual

Standard & stainless industrial case taping system
Hide thumbs
Table of Contents

Advertisement

Quick Links

SB-2/3EX
Standard & Stainless
Industrial
Case Taping System
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Eastey SB-2EX

Summary of Contents for Eastey SB-2EX

  • Page 1 SB-2/3EX Standard & Stainless Industrial Case Taping System User Guide...
  • Page 3 Industrial Case Taping System User Guide Revised 10/15/2015 P/N 5001680 Rev D Copyright and Trademarks Copyright ©2013-2015 Eastey Enterprises All rights reserved. All trademarks and registered names are the property of their respective owners. Eastey Enterprises, Inc. 7041 Boone Ave. N Brooklyn Park, MN 55428 Phone: (763) 428-4846;...

  • Page 5: Table Of Contents

    Operation ........................15 Loading the Tape Cartridges ..................15 Check Tension ......................16 Thread Tape ........................ 16 Center Tape — Eastey-EX Tape Head only ................ 18 Main Spring ......................... 18 Power .......................... 19 Control Panel ......................19 Emergency Stop ......................20 Adjustments ........................

  • Page 7: Safety

    Safety 7 Safety Before installing, operating or servicing this equipment, please read the following precautions carefully:  This machine is equipped with moving belts. Do not place hands near the rear of this unit when the belts are moving as fingers may be pinched where belts enter the frame.

  • Page 8: Introduction

    8 Introduction Introduction General System Description Upper Vertical Tape Column Head Height Adjustment Crank Roller Table Squeezer Drive Belt Control Panel Casters Adjustable Width Adjustment Crank...

  • Page 9: Specifications

    Introduction 9 Specifications Model SB-2/3EX Standard Tape 1.5 inches (3.6 cm) or 2 inches (5 cm), up to 15 inches (36 cm) diameter rolls Belt speed 75.5 feet/min. (23 m/min.) (L) 4.7 inches (12 cm) to unlimited Capacity (W) 3.9 inches to 19.5 inches (10 cm to 50 cm) (H) 4.7 inches to 19.5 inches (12 cm to 50 cm) Power Consumption 450W...

  • Page 10: Dimensions

    10 Introduction Dimensions Dimensions are shown in inches.

  • Page 11: Installation

    Installation 11 Installation Carefully unpack the case taper from the shipping carton. Remove the shipping bolts that secure the Case Taper to the shipping pallet. Lift the Case Taper of the pallet. CAUTION! The SB-2/3EX Standard Case Taper is very heavy and will require a forklift, floor crane, or several people to move safely off the shipping pallet.

  • Page 12: Location Requirements

    12 Installation The locking casters allow the taper to be moved easily over a smooth flat surface. If the unit must be lifted to move it to the desired location you will need to use a pallet jack, floor crane, or fork lift to lift it. Location Requirements When installing the SB-2/3EX Standard Case Taper please be aware of the following considerations:...

  • Page 13: Install Front And Rear Tables

    Installation 13 Install Front and Rear Tables Front and rear tables are identical and therefore interchangeable. Temporarily loosen socket head cap screws at the locations shown in the following illustration. Align the keyhole slots in the table flanges with the loosened cap screw heads and position the end table so rollers are level with rollers in the case taper body, then re-tighten cap screws to secure table.
  • Page 14 14 Installation...

  • Page 15: Operation

    Operation 15 Operation Loading the Tape Cartridges Turn the main power switch to “Off” and disconnect the power. CAUTION! To avoid personnel injury, remove the tape cartridge before loading tape. When handling the tape cartridge be careful to avoid contact with the tape cutting blade.

  • Page 16: Check Tension

    Tape Head User Guide provided with the tape head. For convenience, diagrams for threading tape in the Eastey-EX Tape Head and EZ-EX Tape Head are provided on the following page. Follow the diagram that applies for your...
  • Page 17 Operation 17 Eastey-EX Tape Head Adhesive Side Adhesive Side Bottom Cartridge Upper Cartridge EZ-EX Tape Head Adhesive Side Adhesive Side Bottom Cartridge Upper Cartridge...

  • Page 18: Center Tape - Eastey-Ex Tape Head Only

    18 Operation Center Tape — Eastey-EX Tape Head only Make sure the tape is centered on all the rollers. There are several rollers in the tape cartridge where the tape alignment should be checked to verify the tape stays on center as it is being dispensed.

  • Page 19: Power

    Operation 19 Power Plug the power supply cord into a properly wired and grounded outlet. Press start button. CAUTION! When the power is turned on be aware of moving parts and belts Control Panel When the main power switch is in the “ON” position the power lamp should be illuminated.

  • Page 20: Emergency Stop

    20 Operation Emergency Stop Emergency Stop Button (Red) Emergency Stop Button (Red) Press the button for emergency stop. To reset the Emergency Stop button once the emergency condition has been cleared and it is safe to operate the machine again, press the Emergency Stop button in while turning it approximately a quarter-turn in the direction of arrows.

  • Page 21: Adjustments

    Adjustments 21 Adjustments Carton Height and Width Adjustments With the power off, place an appropriate size box filled with product in the Case Sealer. Position the box centered with the rollers, drive belts, and tape heads. Use the filled box to adjust the width of the side belts and squeezers, and height of the top tape head.
  • Page 22 22 Adjustments Height Adjustment Crank for Upper Tape Head Set Screw The height adjustment crank can be mounted on either side of the machine by loosening the set screw, removing the crank, and mounting the crank onto the adjustment spindle on the opposite side of the machine. Re -tighten the set screw to secure the adjustment crank.

  • Page 23: Belt Adjustment

    Adjustments 23 Belt Adjustment You do not have to remove the drive belt cover to adjust the drive belt. To adjust the belt, use an Allen wrench and loosen the belt nut. Adjust the belt to a suitable tension by turning the adjustment screw with a Philips screwdriver.
  • Page 24 24 Adjustments Tape Head Adjustment — Refer to Tape Head User Guide. Refer to instructions in the Tape Head User Guide that is provided with the tape head for instructions regarding adjustment information for the tape head.

  • Page 25: Maintenance

    Maintenance 25 Maintenance The SB-2/3EX Standard Industrial Case Taping System will provide many hours of maintenance free operation. There are a few items that may require attention from time to time. Rollers Make sure rollers stay clean and grease free. If you should have to clean the rollers simply wipe them down with a clean lint free cloth.
  • Page 26 26 Maintenance...

  • Page 27: Troubleshooting

    Illustrated Parts List 27 Troubleshooting Problem Solution Taper will not start  Check power input.  Release the Emergency Stop button.  Press the Start button to release overload.  Replace Fuse. (Access fuse by removing plug from underside of control box as shown at right.) Machine is not operating ...
  • Page 28  Check wipe down brush. Tape Curling and Bunching Up Eastey-EX Tape Head Only — Eastey EX Tape Head Only  Adjust the tape cartridge height (approximately .06 inches from box)  Check tape tension set by the spring tension at...

  • Page 29: Parts List

    Illustrated Parts List 29 Parts List Electrical...
  • Page 30 30 Illustrated Parts List Electrical Layout...
  • Page 31 Illustrated Parts List 31 Electrical Layout Cont.
  • Page 32 32 Illustrated Parts List Q’TY PART NO. DESCRIPTION 7155BC20 EMG. SWITCH 7158BZ12 BUTTON SEAT CONTACTOR NCx1 7066P001 1/2” CONNECTOR 7065C062 1/2” PROTECT TUBE 7066C064-1 1/2” 90˚ CONNECTOR 70560601 TERMINAL BLOCKS TB6P 7032SW01 CONNECTOR 71570002-01 BREAKER LC1-D09F7 110V 71570003-01 BREAKER LC1-D09M7 220V 71570002-02 OVERLOAD PROTECTOR LR3-D106(4-6A)(110V) 71570003-02...

  • Page 33: Side Belt Assembly

    Illustrated Parts List 33 Side Belt Assembly...
  • Page 34 34 Illustrated Parts List Q’TY PART NO. DESCRIPTION CA3006L0 SIDE BELT COVER 10170610 SCREW M6*10L & S.W & W CA3010L0 GUIDE PLATE 10100870 SCREW M8*70L & W CA302700 BELT CA30250A MOTOR SHAFT CA301900 PULLEY DRIVER CA301700 SPEDIAL SCREW 10925300 KEY 5*5 CA301600 SUPPORT SHAFT 11301200...
  • Page 35 Illustrated Parts List 35 CA302200 CHAIN SPPOCKET 3240S355 CHAIN CA300700 SPINDLE WIDTH ADJUSTMENT 10100612 SCREW M6*12L & S.W & W CA300900 SHAFT CA303200 HANDLE RING CA201500 HANDLE CRANKK ARM 10100620 SCREW M6*20L & S.W & W CA300800 SPINDLE WIDTH ADJUSTMENT 30302031 BEARING 6203ZZ CA3015R0...

  • Page 36: Side Belt Assembly (Stainless)

    36 Illustrated Parts List Side Belt Assembly (Stainless) Q’TY KEY NO PART NO. DESCRIPTION KA111138L0-S SIDE BELT COVER 10170610S SCREW M6*10L & S.W & W CA3010L0 GUIDE PLATE 10100870S SCREW M8*70L & W CA302700 BELT CA30250A-S MOTOR SHAFT CA301900 PULLEY DRIVER CA301700-S SPEDIAL SCREW 10925300...
  • Page 37 Illustrated Parts List 37 745111R4 MOTOR 110V/60HZ,T18:1 745122R4 MOTOR 220V/50HZ,T15:1 745124R3 MOTOR 240V/50HZ,T15:1 745138R3 MOTOR 380V/50HZ,T15:1 745140R3 MOTOR 400V/50HZ,T15:1 CA302000-S SHAFT SEAT CA3022S0 CHAIN SPPOCKET 3240S355-S CHAIN CA300700-S SPINDLE WIDTH ADJUSTMENT CA300900-S SHAFT CA303200 HANDLE RING CA201500 HANDLE CRANK ARM 10100620S SCREW M6*20L &...

  • Page 38: Vertical Column

    38 Illustrated Parts List Vertical Column...
  • Page 39 Illustrated Parts List 39 Q’TY PART NO. DESCRIPTION CA10010A TAPING SET SUPPORT CA10110A SUPPORT SET 10100612 SCREW M6*12L & S.W & W CA101500 LINING CA10040A COVER PLATE 10140406 SCREW M4*6L CA101600 HANDLE KNOB CA100900 LOCKING BRACKET CA100800 SCREW KNOB CA100500 COMPRESSION ROLLER SEAT CA101000 SUPPORT BAR...
  • Page 40 40 Illustrated Parts List 10100635 SCREW M6*35L & S.W & NUT CA201500 HANDLE CRANKK ARM 10170816 SCREW M8*16L & S.W & W 91350001 RUBBER PLUG CA100300 B-PLATE CA100200 A-PLATE 30302020 BEARING 6202ZZ CA304500 BEARING SEAT 10140616 SCREW M6*16L...

  • Page 41: Vertical Column (Stainless)

    Illustrated Parts List 41 Vertical Column (Stainless) Q’TY KEY NO PART NO. DESCRIPTION CA10010B -S TAPING SET SUPPO RT CA10110A-S SUPPORT SET 10100612S SCREW M6*12L & S.W & W CA101500-S LINING CA10040A-S COVER PLATE 10140406S SCREW M4*6L CA101600 HANDLE KNOB CA100900-S LOCKING BRACKET CA100800-S...
  • Page 42 42 Illustrated Parts List 3240S356-S CHAIN CA201100-S CHAIN COVER 10190410S SCREW M4*10L & S.W & W CA201600-S CHAIN WHEEL CA201700-S CHAIN WHEEL SHAFT CT212100 BUSH Ø10 x Ø12 x 10L 10100635S SCREW M6*35L & S.W & NUT CA201500 HANDLE CRANK ARM 10170816S SCREW M8*16L &...

  • Page 43: Machine Body

    Illustrated Parts List 43 Machine Body...
  • Page 44 44 Illustrated Parts List Q’TY PART NO. DESCRIPTION CA30010A MACHINE FRAME CA300200 MACHINE LEG 10100816 SCREW M8*16L & S.W & W 10101016 SCREW M10*16L & S.W & W CA30040A CLAMP CA30030A ADJUSTABLE LEG 9201L501 CASTER CA400100 ROLLER SEAT CA30280A ELECTRICAL BOX 10170510 SCREW M5*10L CA304300...

  • Page 45: Machine Body (Stainless)

    Illustrated Parts List 45 Machine Body (Stainless) Q’TY KEY NO PART NO. DESCRIPTION CA30010A-S MACHINE FRAME CA300200-S MACHINE LEG 10100816S SCREW M8*16L & S.W & W 10101016S SCREW M10*16L & S.W & W CA30040A-S CLAMP CA30030A-S ADJUSTABLE LEG 9201L501-S CASTER CA400100-S ROLLER SEAT CA30280A-S...
  • Page 46 46 Illustrated Parts List Tape Head (2" or 3" ) — Refer to Tape Head User Guide Refer to the User Guide provided with the Tape Head for the Illustrated Parts List and part numbers for Tape Head parts.

  • Page 47: Warranty Statement

    SB-2/3EX Standard Carton Sealing Machine Warranty Statement Eastey Enterprises warrants that all of the products it ships will be in good working order and free from defects in material and workmanship and will conform to the published specifications for that product.
  • Page 48 LIABLE FOR ANY SPECIAL, CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES, INCLUDING LOST PROFIT OR LOST OPPORTUNITIES OF ANY TYPE ARISING OUT OF THE USE OR INABILITY TO USE THESE PRODUCTS EVEN IF EASTEY ENTERPRISES, INC. HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH...

  • Page 49: Customer Support

    For help setting up or operating the SB-2/3EX Standard Case Taper, please contact Eastey Technical Service at one of the numbers listed below. Toll-Free Phone 800-835-9344 Phone 763-428-4846 763-795-8867 E-mail info@eastey.com www.eastey.com Thanks again for your purchase of Eastey products. We are pleased to be a part of your packaging needs.

This manual is also suitable for:

Sb-3ex
