3.4. Packing list

If the booth is delivered unassembled:
Ref. Qty
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 1
11 1
12 1
30 4
31 8
32 4
33 4
34 sq
35 3
36 12
37 12
38 12
39 8
40 10
41 4
42 4
43 4
Technical Manual
NAM-CLEAR-MT-EN-A
Description
Base
Right upright NSA
Left upright NSA
Right upright SA
Left upright SA
Canopy
6a: Canopy with electronics
6b: Canopy cover – section 1
6c: Canopy cover – section 2
Ceiling mount with detectors
Right-side glass panel
8e: Glass panel bracing
8i: Glass panel bracing
Left-side glass panel
9e: Glass panel bracing
9i: Glass panel bracing
Mobile obstacle NSA
Mobile obstacle SA
Inside column
#5-M8 x 20 Flat socket cap screw
#3-M5 x 10 Button socket cap screw
#5-M8 x 20 Flat socket cap screw
Ring
Plastic shims
Gray silicone cartridge
M8 x 35 Hex cap screw (13-mm wrench) 6a, 10, 11
M8 Lock washer
Nylon washer
#4-M6 x 16 Button socket cap screw
#2.5-M4 x 10 Button socket cap screw
#4-M5 x 16 Socket cap screw
M5 Flat washer
M5 Lock washer
Location (most of the screws are on the specified
component or assembly)
6b
4
9i
9e
7
12
11
9
3
10
2, 3, 4, 5
6a, 6b, 6c
6a, 2, 3, 4, 5
6a, 2, 3, 4, 5
6a, 8, 9
8, 9
6a, 10, 11
6a, 10, 11
6a, 7
12
1, 6a, 12b
1, 6a, 12b
1, 6a, 12b
The information contained in this document is the property of Automatic Systems
and is confidential. The recipient shall refrain from using it for any purpose other
than for the use of the products or the execution of the project to which it refers
and from communicating it to third parties without prior written agreement from
Automatic Systems. The document is subject to change without notice.
8
6c
6a
5
8i
8e
8
2
1
