Automatic Systems ClearLock Technical Manual page 6

80
LED lighting
81
Infrared presence
detector inside the
booth
90
Electrical power supply
91
Backup batteries (2)
92
Speaker for voice
synthesizer
Technical Manual
NAM-CLEAR-MT-EN-A
Non-secured area
Secured area
The information contained in this document is the property of Automatic Systems
and is confidential. The recipient shall refrain from using it for any purpose other
than for the use of the products or the execution of the project to which it refers
and from communicating it to third parties without prior written agreement from
Automatic Systems. The document is subject to change without notice.
6
82
Keyed locking device to
lock the obstacle on the
entry side (NSA)
(optional)
83
Single-presence
volumetric detectors
(8)
(optional)
84
Left object detector
(optional)
93
Obstacle motor
94
Main board VB3406
95
Metal detector
(optional)
96
Single-presence
detection
(optional)
97
Door closed detector
