Automatic Systems ClearLock Technical Manual page 54

MASTER
SLAVE 1
SLAVE 2
SLAVE 3
- Turn all the booths on.
- Adjust the Function 1 parameter on the master booth only.
Technical Manual
NAM-CLEAR-MT-EN-A
M6
M6
M6
M6
4 3 2 1
DS1
Master
4 3 2 1 4 3 2 1
DS1 DS1
Master Slave 1
4 3 2 1 4 3 2 1
DS1 DS1
Master Slaves 1 and 2
4 3 2 1 4 3 2 1
DS1 DS1
Master Slaves 1, 2 and 3
