2. DESCRIPTION

2.1. Component location

61
Canopy containing the
control electronics and
the motorization
devices
62
Side glass panels (2)
63
Button inside the booth
to unlock the entry door
(optional)
64
Base
Non Secured Area (NSA)
(=Entry side)
Technical Manual
NAM-CLEAR-MT-EN-A
71
Metal detector
(optional)
The information contained in this document is the property of Automatic Systems
and is confidential. The recipient shall refrain from using it for any purpose other
than for the use of the products or the execution of the project to which it refers
and from communicating it to third parties without prior written agreement from
Automatic Systems. The document is subject to change without notice.
5
65
Intercom
(optional)
66
Function
pictogram
67
Mobile obstacles (2)
(sliding doors)
68
Safety photocells on
each side of the
obstacles
Secured Area (SA)
(=Exit side)
72
Lifting eye bolts
