Listen Technologies LWR-1020 Quick Start Manual

Listen EVERYWHERE WiFi
Audio Receiver 1020
Quick Start Guide
This device is a dedicated assistive
listening receiver intended to be
used with a Listen EVERYWHERE
system, for streaming of real time
audio across a wireless local area
network. This device has been
locked down and configured for use
strictly as a WiFi Audio Receiver. No
other device services or applications
can be accessed.
Get to know the receiver
5
1. Volume 4. Home
2. Side Key 5. Charging Port
3. Audio Channels

Getting Started

Remove the protective screen cover
from the device.
Install the Protective Case on the
device (LA-511 sold separately).
1
Fully charge the device using the
included USB cable and charging
2
block. The device will indicate
charging status on screen and
3
indicate when battery is fully
charged.
Power on/off the device by pressing
and holding the power button

Connection Settings

4
The connection settings menu can
be accessed by quickly double
tapping the Side Key. The following
options are available in the settings
menu:
Wi-Fi – Select your Wi-Fi network
and log in as necessary. The
selected Wi-Fi network should be
the same network that the Listen
EVERYWHERE server is broadcasting
channels on.
