Listen Technologies LR-4200-216 User Manual

Idsp receiver (072 mhz), idsp receiver (216 mhz)
Hide thumbs

Advertisement

Quick Links

Download this manual
U s e r M a n u a l
L R - 4 2 0 0 - 0 7 2 i D S P R e c e i v e r ( 0 7 2 M H z )
L R - 4 2 0 0 - 2 1 6 I D S P R e c e i v e r ( 2 1 6 M H z )
© 2017 Listen Technologies Corporation
For further details regarding use, adjustment, or programming of your Listen Technologies products visit
our website at www.listentech.com/support-manuals or contact us at +1.801.233.8992 or 1.800.330.0891.
All Rights Reserved
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the LR-4200-216 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Listen Technologies LR-4200-216

Summary of Contents for Listen Technologies LR-4200-216

  • Page 1 L R - 4 2 0 0 - 2 1 6 I D S P R e c e i v e r ( 2 1 6 M H z ) © 2017 Listen Technologies Corporation All Rights Reserved ® For further details regarding use, adjustment, or programming of your Listen Technologies products visit our website at www.listentech.com/support-manuals or contact us at +1.801.233.8992 or 1.800.330.0891.
  • Page 2 Dear Valued Customer, Thank you for choosing Listen! We are dedicated to providing you with the highest quality products available, and take pride in delivering outstanding performance to ensure you are completely satisfied. We independently certify each of our products to the highest quality standards and back them with a limited lifetime guarantee.
  • Page 3 TABLE OF CONTENTS iDSP™ Receivers ………………………………………………………………………………………………………………………………………………… LR-4200 Quick Reference ……………………………………………………………………………………………………………………………… LR-4200 Specifications …………………………………………………………………………………………………………………………………… Safety Cautions! ………………………………………………………………………………………………………………………………………………… Hearing Safety: …………………………………………………………………………………………………………………………………………………… Medical Device Safety: …………………………………………………………………………………………………………………………… Recycling : …………………………………………………………………………………………………………………………………………………………… Product Recycling Instructions: …………………………………………………………………………………………………………… Battery Recycling Instructions: ……………………………………………………………………………………………………………… Quick Setup and Operation Instructions: ………………………………………………………………………………………………… 1.
  • Page 4 iDSP Receivers ™ The LR-4200 is a powerful Assistive Listening Receiver designed to be compact and simple to use. The unique design of the iDSP™ receiver family allows them to be worn as a necklace, using the belt clip or con- cealed in a pocket, making this the most inconspicuous ALS receiver on the market.
  • Page 5 LR-4200 Quick Reference 1. OLED Display Area 3. Up/Down Volume Control 2. Micro USB 1. OLED Display Area: Displays battery status, unit ID, channel status, volume status and charge activation 2. Micro USB: USB charging, programming, firmware updates and inventory dispensing 3.
  • Page 6 LR-4200 Specifications Product Specification: LR-4200-072 / LR-4200-216 Audio System Frequency Response 50 Hz - 15 kHz (±3 dB) / 50 Hz - 10 kHz (±3 dB) System Signal to Noise Ratio SQ enabled 80 dB, SQ disabled 60 dB /...
  • Page 7 Always make sure you are using this product in accordance with the safety guidelines established by your physician or the implantable device manufactur- Recycling : Help Listen Technologies protect the environment! Please take the time to dispose of your equipment properly. Product Recycling Instructions: Please do NOT dispose of your Listen Technologies equipment in the household trash.
  • Page 8 3. Charge Battery Fully charge the rechargeable Lithium Ion battery by connecting the unit to one of Listen Technologies charging options. a. LA-380 Intelligent 12-Unit Charging/Carrying Case b. LA-381 Intelligent 12-Unit Charging Tray c.
  • Page 9 4. Connect Earphone Speaker Using The Earphone/Neck Loop Lan- yard Connect the Listen Intelligent ear phone/ neck loop lanyard to the two 3.5 mm output jacks on the unit. Then connect the short cable Ear Phone/ ear speaker or headphones to Neck Loop the 3.5mm output jack on the Lanyard...
  • Page 10 5. Turn the Unit On Press and hold the Power Button for 1 second to turn the receiver on, the unit display will show the unit ID, battery status and the current channel. Each item will be displayed and then the display will turn off. Power Button: OLED Display: Press and hold for...
  • Page 11 7. Adjust Volume Adjust the listening volume to a comfortable listening level via the volume up/down buttons. OLED: Volume Up/Down Indicates the Use the volume up level in a % of or down to raise/ maximum level lower volume If the volume is adjusted while there is no audio present the unit will output a momentary tone each time the button is pressed allowing the user to gauge and adjust the audio level to a comfortable listening level.
  • Page 12 Battery & Belt Clip Low Battery Indication When the unit detects a low battery condition it will cause the status LED to flash slowly indicating that the unit needs to be charged. When the light begins to flash the unit has approximately 30 minutes of receiver use before the unit will turn off.
  • Page 13 Accessing Battery Compartment To access the battery compartment simply remove the belt clip and battery door by pulling down and out on the battery door locking tab. Note: The product labeling information can be found behind the battery and includes the product model number, description, serial number, contact information and compliance statement. Door locking Battery door...
  • Page 14 To manage the advanced program features on any of the iDSP™ receivers a windows based User Interface (UI) software is required. This software is available free of charge from Listen Technologies. To download the software log onto http://www.listentech. com/support/software/idsp-software-suite/ and follow the instructions.
  • Page 15 Squelch The purpose of squelch is to mute the audio output of the receiver when the signal from the transmitter is turned off or the level is too weak to be received. Without squelch radio noise will be heard in the earphone. The squelch on the receiver can be adjusted to mute the audio at different RF signal strengths.
  • Page 16 Unit ID The unit ID number provides a unique identification for each receiver that is displayed on the OLED status screen. This can be any 3 digit number between 000 and 999. The unit ID allows venues to track individual units and for easy dispensing and inventory control.
  • Page 17 RF Reception Maximization Strategies: For proper and reliable operation, Listen receivers should receive a strong and consistent signal from the originating transmitter. Follow these strategies should be used to maximize this signal: When designing and installing a system, keep in mind that the location of both the transmitter and receivers is critical to maximizing signal strength Eliminate or minimize obstructions between the transmitter and receivers Minimize the distance between the transmitter and receivers...
  • Page 18 72 MHz Compatibility Chart: Frequency Phonic Frequency Phonic Listen Comtek Phonak Williams* Gentner Telex Drake Listen Comtek Phonak Williams* Gentner Telex Drak e 72.0250 (11, 1) 74.6250 (36, 40) 72.0500 74.6500 (41) 72.0750 (12, 3) 74.6750 (37, 42) 72.1000 A, (13, 4) 72.1 74.7000 I, (38, 43)
  • Page 19 216 MHz Compatibility Chart: Frequency Phonic Light Listen Phonak Comtek Williams Gentner Speed 216.0125 216.0250 216.0375 216.0625 216.0750 216.0875 216.1125 216.1250 216.1375 216.1625 216.1750 216.1875 216.2125 216.2250 216.2375 216.2625 216.2750 216.2875 216.3125 216.3250 216.3375 216.3625 216.3750 216.3875 216.4125 216.4250 216.4375 216.5125 216.5250 216.5375...
  • Page 20 Troubleshooting LR-4200 Receivers: The receiver has no power Make sure the unit has either a fully charged battery or a Listen approved wall charging transformer is connected. Make sure the Power button on the top of the unit has been pressed to turn the unit ON. If this does not work, make sure the battery is installed properly and / or install a replacement battery.
  • Page 21 Compliance Notice and FCC Statement and Industry Canada Statements Compliance Notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) These devices may not cause harmful interference, and (2) these devices must accept any interference received, including interference that may cause undesirable operation.
  • Page 22 The terms of the warranty are governed by the laws of the state of Utah, USA. Warranty does not include normal wear and tear on the product. In addition, Listen Technologies is not liable for consequential damages due to any failure of equipment to perform as intended.
  • Page 23 Contacting Listen If technical service is needed, please contact Listen. Pre-authorization is required before returning Listen products. If products were damaged in shipment, please contact the carrier, then contact Listen for replacement or repair requirements payable by the carrier. Listen’s corporate headquarters are located in Bluffdale, Utah U.S.A. and are open Monday through Friday, 8am to 5pm Mountain Time.

This manual is also suitable for:

Lr-4200-072
