Neilsen CT4188 Instructions

600lb trailer dolly

600LB TRAILER DOLLY CT4188

Read this material before using this product.Failure to do so can result in serious injury.

SAVE THIS MANUAL.

Capacity

600LBS

Hitch ball

50mm

IMPORTANT SAFETY INFORMATION

1. Study, understand, and follow all instructions before operating this device.

2. Do not exceed rated capacity.

3. Use only on hard level surface.

4. Avoid working on slopes as the force of gravity is difficult to judge.

5. Before moving a trailer, assure that the load is centered and coupler secured.

6. No alterations shall be made to this product.

7. Wear ANSI-approved safety goggles and heavy-duty work gloves during

Table of Contents

Do you have a question about the CT4188 and is the answer not in the manual?

Page 1 600LB TRAILER DOLLY CT4188 INSTRUCTIONS Read this material before using this product.Failure to do so can result in serious injury. SAVE THIS MANUAL. Specifications Capacity 600LBS Hitch ball 50mm IMPORTANT SAFETY INFORMATION 1. Study, understand, and follow all instructions before operating this device.
Page 2 assembly and use. 8. Keep clear of trailer’s path while placing on and removing from dolly, and while moving. 9. Use as intended only. Do not use for aircraft purposes. 10. Inspect before every use; do not use if parts loose or damaged. 11.
Page 3 Use two Bolts (11)+Washer (15) + Install Tyres (7) on to Axle Assy Nut (14) to secure Brace (4) +Handle (1).Insert Washer (9) and a Pin (10). Mount (3) +T-Bar Handle (2) + Stand (5) all-together. Firmly tighten all bolts using a 19mm Socket and adjustable wrench.
Page 4 PARTS LIST Description Axle assembly T-bar handle Handle mount Brace Stand Trailer ball Tyre assembly Rubber grip Larger washer M12 x 50 Bolt M12 x 40 Bolt M12 x 30 Bolt M12 washer M12 lock nut CANNON TOOLS LTD Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K. Made in China...
