- Page 1 User DP(MST)&USB-C KVM Switch Manual EDID PCK0402A10 PCK0402A10 English...
- Page 3 English...
- Page 4 If you have any questions, comments or suggestions, please contact us via the following email: support@tesmart.com. Copyright Notice The user manual, compiled by Tesla Elec Technology Co.,Ltd, shall not be duplicated or translated by any person or organizations without written permission.
-
Page 5: Table Of Contents
Contents 1. Safety Tips and Warnings ··································01 9.3 Auto Scan Mode 2. Battery Description···········································02 9.4 Mouse Wheel Switching 3. Warranty Information········································03 10. Switching Method··········································· 21 4. Preface··························································04 10.1 Front Panel Button 5. Features·························································05 10.2 IR Remote Control 6. Packing List·····················································06 10.3 Keyboard Hot Keys 7. -
Page 6: Safety Tips And Warnings
1. Safety Tips and Warnings Tips: Please read the safety tips and warnings for DP(MST)&USB-C KVM Switch comprehensively before use. Use this produce in accordance with its instructions, safety tips and warnings to prevent unnecessary damage to the product and potential dangers to users. Keep the product away from water. -
Page 7: Battery Description
2. Battery Description Tips: By default, the remote control is not equipped with batteries, due to the safety requirements of some express companies. Install AAA dry cells before use. Caution: Improper disposal of the lithium battery may cause an explosion. Do not throw the battery into fire. -
Page 8: Warranty Information
3. Warranty Information We warrant that this product will be free of defects in material and workmanship for a period of one (1) year from the date of shipment. If within the period of warranty this product proves defective under normal use, we will repair or replace this product, provided that the product has not been subjected to mechanical and electrical damage, or other abuse or modifications. -
Page 9: Preface
PCs always having correct display information. Tips: If you need to control more computers or conduct more complex and professional switching, you can also choose other products of our company. For more details, please visit our official website: www.tesmart.com. -
Page 10: Features
5. Features Using only 1 set of keyboard, mouse and 2 monitors to control 4 computers Ÿ Support MST(Multi-Stream Transport) mode and SST(single stream transport) mode Ÿ Support for dual displays from 1 single DisplayPort source (The PC source must be DisplayPort 1.2 Ÿ... -
Page 11: Packing List
6. Packing List 1 * 4x2 DP(MST)&USB-C KVM Switch Ÿ 1 * IR Remote Control Ÿ 1 * DC 5V Power Adapter Ÿ 1 * User Manual Ÿ 1 * USB-C Cable Ÿ 5 * DisplayPort Cable Ÿ 3 * USB-A to USB-B Cable Ÿ... -
Page 12: Panel Description
7. Panel Description Dual Monitor KVM Function Name Audio integration port Integrated microphone and L/R audio output which can connect such devices like headset. USB connection status LEDs will be lit (blue) if the KVM's USB ports are connected to the computers' USB ports. indicators Input selection status The corresponding LEDs will be lit (blue) to indicate the current selected computer device. - Page 13 Function Name DC 5V 5V DC power supply. DisplayPort output ports Connect to DisplayPort displays for video output. Keyboard and mouse input For USB keyboard and mouse input. Standard USB 2.0 port Connect to USB 2.0 device. Input ports Connect to USB-C(input 1) and DisplayPort(input 2-4) input devices. USB input ports Connect to corresponding input devices for USB data signal input.
-
Page 14: Connection Description
8. Connection Description 8.1 Connection Diagram PC 4 PC 3 PC 2 Monitor 2 Monitor 1 DP Cable USB-A to USB-B Cable USB-C Cable Barcode Scanner Driver Keyboard Mouse Laptop... -
Page 15: Connection Preparation
8.2 Connection Preparation Take into consideration all devices required to be connected and prepare a workbench large Ÿ enough before the connection. Lay out the cables properly to facilitate the layout of power supply as a lot of power sockets Ÿ... -
Page 16: Connection Steps
8.3 Connection Steps 1. Connect PC 1 with one USB-C cable. 2. Connect PC 2~4 with DisplayPort cables and USB-A to USB-B cables. - Page 17 3. Connect external mouse and keyboard to KVM's keyboard and mouse input port. Tips: For the normal service of hotkeys, we recommend you use the full-key external keyboard with a separate [Scroll Lock] key (as shown above). 4. Connect an USB 2.0 device to KVM's standard USB 2.0 port.
- Page 18 5. Connect KVM's DisplayPort output ports to 2 DisplayPort displays with 2 DisplayPort cables. 6. Connect external audio device and microphone to KVM's L/R out port and microphone in port.
- Page 19 7. Connect the power cable to KVM's DC 5V port and plug it to a power socket. 8. By now, the connection has been completed. Turn on the power supply and the KVM Switch will begin to work.
-
Page 20: Kvm Workbench
8.4 KVM Workbench A workbench with DP(MST)&USB-C KVM Switch successfully connected is shown as below:... -
Page 21: Function Description
9. Function Description 9.1 Display Mode Description The traditional dual monitor KVM switch needs to connect two cables to each input device for the normal use of the dual monitor function. But our DP(MST)&USB-C KVM Switch support Multi-Stream Transport(MST) mode allowing dual DisplayPort displays from a single DisplayPort source. - Page 22 Duplicate displays Extend displays Tips: 1. If your devices do not support DisplayPort MST, there will be only 1 monitor to display even if you have connected 2 monitors to the KVM Switch. 2. Up to now, devices running Apple’s Mac OS operating systems do not support DisplayPort MST mode.
- Page 23 Single Stream Transport mode: When you only connect 1 DisplayPort display to any output port on this KVM Switch, you can also get the resolution up to 4K@60Hz. Operation method Ÿ Connect DisplayPort port input devices and 1 monitors to any one of the display port on the KVM, the display mode will enable SST mode automatically.
-
Page 24: Edid Emulator
9.2 EDID Emulator DP(MST)&USB-C KVM Switch with EDID emulators in each input port, can keep PCs always having correct display information. And the KVM will maintain EDID before and after switching, ensure that the window you open stays in the fixed place. The DIP switch can enable or disable EDID emulators. -
Page 25: Auto Scan Mode
9.3 Auto Scan mode Auto Scan can automatically switch the display at regular intervals between the input devices that are powered on and connected to the KVM. As a result, any input devices connected to each port can be monitored without user intervention. Auto scan mode is off by default. -
Page 26: Switching Method
10. Switching Method 10.1 Front Panel Button This 4x2 DP(MST)&USB-C KVM Switch can switch to any input devices at any time with front panel keypad, IR remote control, keyboard hot keys and mouse gesture mode. You can choose your favorite switching method according to your personal needs and habits. Switch the input devices by pressing the button [Select] on the front panel of the KVM à... -
Page 27: Ir Remote Control
10.2 IR Remote Control Use IR remote to switch the input devices. à [M]-Disable or enable buzzer sound [1]-Switch to input port 1 [2]-Switch to input port 2 [3]-Switch to input port 3 [4]-Switch to input port 4 Tips: Unspecified buttons at above are non-functional. -
Page 28: Keyboard Hot Keys
10.3 Keyboard Hot Keys Use external keyboard hot keys to switch the input devices. à Tips: The keyboard hot keys can only work with the external keyboard correctly connected to the keyboard and mouse input port of the KVM. For the use of hot keys, we recommend you use an external keyboard with a separate [Scroll Lock] key. - Page 29 Select port by port number: Scroll Scroll Scroll [Scroll Lock]→[Scroll Lock]→[1]~[4] Lock Lock Lock Turn on auto switching mode: Scroll Scroll Space [Scroll Lock]→[Scroll Lock]→[Space] Lock Lock Tips: Enter auto switching mode by following the operation order shown above. The default auto switching time interval is 5 seconds.
- Page 30 Turn on/off mouse wheel switching mode: Scroll Scroll Lock Lock [Scroll Lock] →[Scroll Lock] →[F6] Tips: The default setting of mouse wheel switching mode is off. Turn on mouse wheel switching mode by following the operation order above. Enable or disable buzzer sound: Scroll Scroll [Scroll Lock]→[Scroll Lock]→[F11]...
-
Page 31: Mouse Gesture Mode
10.4 Mouse Gesture Mode Mouse gesture mode is also called fast switching mode. The fast switching mode is not activated under standard settings. You need to follow the hot key command in page 23 to turn on the fast switching mode. Use your mouse to touch the left edge Use your mouse to touch the right à... - Page 32 11. Change Hot Key Combinations There are two kinds of trigger hot keys in this product, the default is [Scroll Lock] key, and the alternative is the [Right-Ctrl] key. If [Scroll Lock] Key has been used for other functions, you can switch the hot key to [Right-Ctrl] by: Method 1: 10 seconds after powering on the KVM, press and keep holding the [Select] button on à...
-
Page 33: Pass Through Mode Description
12. Pass Through Mode Description 12.1 Introduction of Pass through mode Pass through mode is a built-in function of KVM, which is able to improve keyboard and mouse compatibility and enhance user experience. In the pass through mode, the keyboard and mouse are equivalent to directly connecting to the computer. -
Page 34: Keyboard And Mouse Compatible Model List
12.2 Keyboard and mouse compatible model list Tips: The following list is from the most representative models of keyboard and mouse that have been tested in the laboratory, mainly from manufacturers with a high market share. Model Brand Model Brand Model Brand Brand... - Page 35 31.00.0418-V011...
- Page 36 To Enjoy Smart PCK0402A10 Tesla Elec Technology Co.,Ltd WEEE-Reg.-Nr. DE 66784279...
