Original Instructions
Installation Operations and Maintenance manual
series
VORT NRG MEGA-R
Incorporated in this manual there are the following documents:
Declaration of conformity •
Technical schedule •
Dimensional drawing •
Wiring diagrams •
RETAIN FOR FUTURE REFERENCE
cod. 5.571.084.976
19/01/2021
