- Page 1 revolutionary car audio D D D D SERIES SERIES User Manual power amplif iers edbx1800.1d-e1 edbx2200.1d-e1...
- Page 2 Thank you for buying EDGE, we hope you enjoy listening to your product as much as we enjoyed creating it.
-
Page 3: Limited Warranty
EDGE. Graphics and logos are trademarks or trade dress of EDGE audio or its subsidiaries. EDGE’s trademarks and trade dress may not be used in connection with any product or service that is not EDGE’s, in any manner that is likely to cause confusion among cus- tomers or in any manner that disparages or discredits EDGE. -
Page 4: Mounting Guidelines
Mounting Guidelines Your EDGE amplifier is designed with a swift installation routine in mind. Please mount the amplifier in a dry location on a solid surface. NEVER mount the amplifier upside down as this will cause the amplifier to over heat and will eventually damage the amplifier. -
Page 5: Power Cable
Power Cable • At least 4 gauge cable should be used for the power connection to the amplifier. • The power cable should be taken directly from the battery. Rubber grommets should be used when passing through any bulkheads to prevent the cable from becoming chaffed or cut. - Page 6 EDS3000.1FD Terminals And Connections 1. Power / protect LED If the amplifier is operating normally, the GREEN LED will illuminate. If the amplifier is in protection mode the RED LED will illuminate. 2. Remote input socket Used to connect the remote level control to the amplifier. 3.
-
Page 7: Amplifier Configuration
Multi Amplifier Installation Amplifier Configuration Minimum impedance 1Ω WARNING Driving multiple speakers at an impedance lower than that recommended by EDGE could cause damage to this amplifier that is not covered by warranty. -
Page 8: Set Up Section
Set Up Section To correctly set the gain control of the amplifier to match that of the source (headunit) use the following setup routine: Turn the gain control to minimum on the amplifier. Ensure the bass boost is set to 0 dB. On the headunit set all crossovers (if applicable) to flat and both bass and treble to zero. - Page 9 UK Technical Enquiries Call 09067031420 Calls cost 50p per minute. Call costs correct at date of publication (01/02/12) Hours of business 9.00am - 5.30pm GMT Monday - Friday. All calls are recorded for training purposes. MIDBASS Distribution PO Box 11000 B75 7WG International Technical Enquiries For international technical support please contact the...
- Page 10 edgecaraudio.com facebook.com / EDGEaudio instagram.com / edge_caraudio...
