Power Amplifiers
Owners Manual
EDA12000.1D-E6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDA12000.1D-E6 and is the answer not in the manual?

Questions and answers

Related Manuals for Edge EDA12000.1D-E6

Summary of Contents for Edge EDA12000.1D-E6

  • Page 1 Power Amplifiers Owners Manual EDA12000.1D-E6...
  • Page 2 Thank you for buying EDGE, we hope you enjoy listening to your product as much as we enjoyed creating it.

  • Page 3: Limited Warranty

    EDGE. Graphics and logos are trademarks or trade dress of EDGE audio or its subsidiaries. EDGE’s trademarks and trade dress may not be used in connection with any product or service that is not EDGE’s, in any manner that is likely to cause confusion among cus- tomers or in any manner that disparages or discredits EDGE.

  • Page 4: Mounting Guidelines

    Mounting Guidelines Your EDGE amplifier is designed with a swift installation routine in mind. Please mount the amplifier in a dry location on a solid surface. NEVER mount the amplifier upside down as this will cause the amplifier to over heat and will eventually damage the amplifier.

  • Page 5: Power Cable

    Power Cable • At least 0 gauge cable should be used for the power connection to the amplifier. • The power cable should be taken directly from the battery. Rubber grommets should be used when passing through any bulkheads to prevent the cable from becoming chaffed or cut.
  • Page 6 Terminals And Connections 1. Speaker terminals Used to connect speaker cables to the amplifier. See the wiring configuration section for more details 2. Remote input socket Used to connect the remote level control to the amplifier. 3. Gain control This control is used to match the input signal of the source to the amplifier. See the setup section for more details.

  • Page 7: Set Up Section

    Set Up Section To correctly set the gain control of the amplifier to match that of the source (headunit) use the following setup routine: Turn the gain control to minimum on the amplifier. Ensure the bass boost is set to 0 dB. On the headunit set all crossovers (if applicable) to flat and both bass and treble to zero.
  • Page 8 Amplifier Strapping Two EDGE EDA12000.1D amplifiers are capable of being strapped together to deliver the combined output of both amplifiers into a single channel. NOTE: only identical amplifiers may be strapped together. Strapping procedure · Connect the RCA input from the source unit to the left and right RCA input of the master amplifier.
  • Page 9 Single Amplifier Configuration Minimum impedance 1Ω Minimum impedance 1Ω Minimum impedance 1Ω WARNING Driving multiple subwoofers at an impedance lower than that recommended by EDGE could cause damage to this amplifier that is not covered by warranty.

  • Page 10: Specification

    Specification EDA12000.1D-E6 Model Competition Monoblock Configuration 3” (76mm) x 37.4” (950mm) x 11.8” Dimensions (299mm) (Height x Width x Depth) 2650 watts RMS @ 4Ω Mono 14.4v 1% THD 5200 watts RMS @ 2Ω Mono 14.4v 1% THD 11,000 watts RMS @ 1Ω...
  • Page 11 UK Technical Enquiries Call 09067031420 Calls cost 50p per minute. Call costs correct at date of publication (01/02/12) Hours of business 9.00am - 5.30pm GMT Monday - Friday. All calls are recorded for training purposes. MIDBASS Distribution PO Box 11000 B75 7WG International Technical Enquiries For international technical support please contact the...
  • Page 12 www.edgecaraudio.com...
