- Page 1 Power Amplifiers Owners Manual EDA4500.2AB-E6 EDA2000.4AB-E6...
- Page 2 Thank you for buying EDGE, we hope you enjoy listening to your product as much as we enjoyed creating it.
-
Page 3: Limited Warranty
EDGE. Graphics and logos are trademarks or trade dress of EDGE audio or its subsidiaries. EDGE’s trademarks and trade dress may not be used in connection with any product or service that is not EDGE’s, in any manner that is likely to cause confusion among cus- tomers or in any manner that disparages or discredits EDGE. -
Page 4: Mounting Guidelines
Mounting Guidelines Your EDGE amplifier is designed with a swift installation routine in mind. Please mount the amplifier in a dry location on a solid surface. NEVER mount the amplifier upside down as this will cause the amplifier to over heat and will eventually damage the amplifier. -
Page 5: Power Cable
Power Cable • At least 0 gauge cable should be used for the power connection to the amplifier. • The power cable should be taken directly from the battery. Rubber grommets should be used when passing through any bulkheads to prevent the cable from becoming chaffed or cut. - Page 6 EDA4500.2AB-E6 Terminals And Connections 10 11 12 1. Power / protect LED If the amplifier is operating normally, the GREEN LED will illuminate. If the amplifier is in protection mode the RED LED will illuminate. 2. Low level input For connection to any source (head unit) with a low level output. This is your RCA output from the source (headunit) 3.
-
Page 7: Wiring Diagram
EDA4500.2AB-E6 Wiring Diagram Bridged operation Stereo operation Minimum speaker impedance 2Ω Minimum speaker impedance 1Ω Multi speaker operation Minimum speaker impedance 2Ω... - Page 8 EDA2000.4AB-E6 Terminals And Connections 12 13 14 17 18 19 20 1. Low level input For connection to any source (head unit) with a low level output. This is your RCA output from the source (headunit) 2. CH1 / 2 Gain control This control is used to match the input signal of the source to the amplifier.
- Page 9 EDA2000.4AB-E6 Terminals And Connections (Cont) 12. CH3 / 4 Gain control This control is used to match the input signal of the source to the amplifier. See the setup section for more details. 13. CH3 / 4 Subsonic filter This control is used to set the subsonic filter which is used to limit the very low frequency information passed to the subwoofer.
- Page 10 EDA2000.4AB-E6 Wiring Diagram 4 Channel operation Minimum speaker impedance 2Ω...
- Page 11 EDA2000.4AB-E6 Wiring Diagram 3 Channel operation Minimum speaker impedance 2Ω...
-
Page 12: Set Up Section
Note: By using the crossovers correctly you will not only lengthen the life of your speakers but you will also get better performance from them. To optimise your setup seek the advise of a professional installation engineer or visit your local EDGE audio dealer. -
Page 13: Specification
Specification EDA4500.2AB-E6 Model Stereo amplifier Configuration 2.3” (58mm) x 33.9” (860mm) x 9.9” Dimensions (HxWxD) (251mm) 2 x 850 watts RMS @ 4Ω Stereo 2 x 1450 watts RMS @ 2Ω Stereo 2 x 2250 watts RMS @ 1Ω Stereo 1 x 2900 watts RMS @ 4Ω... - Page 14 UK Technical Enquiries Call 09067031420 Calls cost 50p per minute. Call costs correct at date of publication (01/02/12) Hours of business 9.00am - 5.30pm GMT Monday - Friday. All calls are recorded for training purposes. MIDBASS Distribution PO Box 11000 B75 7WG International Technical Enquiries For international technical support please contact the...
