To install the XVME-977 in a card cage...
1. Turn off power to the chassis.
2. Connect the jumper cable from the CPU slot to the XVME-977 slot on the rear of the
P2 backplane, as shown in Figure Chapter 2 -1.
It should not be necessary to use excessive force or pressure
to engage the connectors. If the board does not connect prop-
erly with the backplane, remove the module and inspect all
connectors and guide slots for possible damage or obstruc-
tions.
3. Apply straightforward pressure to the handles on the front of the panel, until the
connectors are fully engaged and properly seated.
4. Once the board is properly seated, secure it to the chassis by tightening the machine
screws at the top and bottom of the XVME-977 board.
5. Turn on power to the unit.

Configuring the XVME-977

To set floppy and hard drive specifications...
1. Turn on power to the unit.
2. Press
3. Using the arrow keys, move down the screen to the Diskette A: option and set it as
follows:
4. Move to the IDE Adapter 0 Master option, and press
Adapter Sub-menu.
5. Press
information printed on the label affixed to the hard drive. An example of the label in-
formation is shown below:
FIXED DISK:0 TYPE: USER CY920 HD10 ST17 LZ920 WP0
6. Press
7. Once the specifications have been set, reboot the system. The operating system can
now be loaded. The hard drive is preformatted with a 1:1 interleave, so low-level
formatting is not required.
Installation and configuration of the XVME-977 is now complete.
Technical Note
2 to enter the Main Setup menu.
F
Diskette A: [1.44 MB, 3½"]
Diskette B: [Not Installed]
to auto-configure the hard drive, or type in specific parameters. Use the
ENTER
after all changes have been made.
ESC
Chapter 2 – Installation
to display the IDE
ENTER
2-3
