Chapter 1 – Introduction
The XVME-977 Hard Disk/Floppy Disk Module provides an easy way to integrate both
hard and floppy disk drives into a VMEbus system. Constructed for the industrial mar-
ket, where high levels of shock and vibration are the norm, the module is a single-slot
VME form factor disk drive with a 3.5-inch floppy drive and a 2.5-inch hard drive.
Compact and easy to install, the XVME-977 Hard Disk/Floppy Disk Module is an ideal
mass storage solution for a variety of VMEbus systems. This module is built to commu-
nicate with Xycom's XVME-65x VMEbus PC/AT processors.
Power for the XVME-977 is provided by the P1 and P2 connectors. Signals are routed
through P2. Figure 1-1 illustrates this in a block diagram of the XVME-977.
P2 Connector

Module Features

The XVME-977 Hard Disk/Floppy Disk Module offers the following features:
•
Occupies one VMEbus slot
•
Hard drive activity LED
•
Needs only +5V
•
IDE hard drive
•
3.5-inch, 1.44 Mbyte high-density floppy drive

Specifications

This section contains the hardware and environmental specifications for the XVME-977.
(50pin 2mm RTA conn.)
Figure 1-1. XVME-977 Block Diagram
Floppy Drive
(26pin FFC conn.)
Hard Drive
1-1
