Use & Care Guide
Manual de Uso y Cuidado
Guide d'Utilisation et d'Entretien
English / Español / Français
Models/Modelos/Modèles: 795.7102*
Bottom Freezer Refrigerator
Congelador Inferior Refrigerador
Congélateur Inférieur Réfrigérateur
*
= color number, número de color, le numéro de la couleur
P/N MFL37933570
Sears Brands Management Corporation
Hoffman Estates, IL 60179 U.S.A.
www.kenmore.com
www.sears.com
Sears Canada Inc.
Toronto, Ontario, Canada M5B 2B8
www.sears.ca

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 795.7102 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kenmore 795.7102 Series

Summary of Contents for Kenmore 795.7102 Series

  • Page 1 Bottom Freezer Refrigerator Congelador Inferior Refrigerador Congélateur Inférieur Réfrigérateur = color number, número de color, le numéro de la couleur P/N MFL37933570 Sears Brands Management Corporation Hoffman Estates, IL 60179 U.S.A. www.kenmore.com www.sears.com Sears Canada Inc. Toronto, Ontario, Canada M5B 2B8 www.sears.ca...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com TABLE OF CONTENTS English Version Removing Humidity Controlled Crisper Spanish Version Glide‘N’Serve French Version Modular Door Bin Warranty Dairy Bin ❿¤Freezer Section Protection Agreements Safety Instructions 5–6 Extra Ice Bin Grounding Requirements Durabase Parts And Features Durabase Divider Refrigerator Installation...

  • Page 3: Warranty

    All manuals and user guides at all-guides.com WARRANTY BOTTOM FREEZER REFRIGERATOR WARRANTY Kenmore Appliance Warranty One Year Limited Warranty When installed, operated and maintained according to all instructions supplied with the product, if this appliance fails due to a defect in material or workmanship within one year from the date of purchase, call 1-800-4-MY-HOME ®...

  • Page 4: Protection Agreements

    You can call Congratulations on making a smart purchase. Your new anytime day or night, or schedule a service appointment Kenmore ® product is designed and manufactured for online. years of dependable operation. But like all products, it The Master Protection Agreement is a risk free purchase.

  • Page 5: Safety Instructions

    All manuals and user guides at all-guides.com IMPORTANT SAFETY INSTRUCTIONS BASIC SAFETY PRECAUTIONS This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others, or cause damage to the product.

  • Page 6: Grounding Requirements

    All manuals and user guides at all-guides.com IMPORTANT SAFETY INSTRUCTIONS This appliance is not intended for use by persons Children should be supervised to ensure that they do not (including children) with reduced physical, sensory or play with the appliance. mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible...

  • Page 7: Parts And Features

    All manuals and user guides at all-guides.com PARTS AND FEATURES Use this page to become more familiar with the parts and features. Page references are included for your convenience. NOTE: This guide covers several different models. The refrigerator you have purchased may have some or all of the items listed below.

  • Page 8: Refrigerator Installation

    All manuals and user guides at all-guides.com REFRIGERATOR INSTALLATION INSTALLATION w w WARNING • To minimize noise and vibration, the refrigerator MUST be installed on a solidly constructed floor. Excessive Weight Hazard • Carpeting and soft tile surfaces are not recommended. Use two or more people to move and install •...
  • Page 9 All manuals and user guides at all-guides.com REFRIGERATOR INSTALLATION NOTE: It is ALWAYS recommended to remove the refrigerator doors when it is necessary to move the refrigerator through a narrow opening. If necessary, follow the directions below to remove the door handles. HOW TO REMOVE DOOR HANDLES NOTE: Handle appearance may vary from illustrations on this page.
  • Page 10 All manuals and user guides at all-guides.com REFRIGERATOR INSTALLATION HOW TO REPLACE DOOR HANDLES NOTE: Handle appearance may vary from illustrations on this page. 1. Replacing Refrigerator Door Handle • Place the handle on the door, fitting it over the mounting fasteners and tighten the set screws with a 3/32"...

  • Page 11: Removing And Replacing

    All manuals and user guides at all-guides.com REFRIGERATOR INSTALLATION REMOVING AND REPLACING 6. Rotate hinge lever (6) counterclockwise. Lift the top hinge (7) free of the hinge lever latch (8). REFRIGERATOR DOORS w w CAUTION: When lifting the hinge free of the latch, be w w CAUTION: Before you begin, unplug the refrigerator careful that the door does not fall forward.
  • Page 12 All manuals and user guides at all-guides.com REFRIGERATOR INSTALLATION ❿ Left Door Reinstalling the Refrigerator Door ❿ Right Door 1. Lower the door onto middle hinge pin (10). 2. Fit top hinge (7) over hinge lever latch (8) and into place. 1.
  • Page 13 All manuals and user guides at all-guides.com REFRIGERATOR INSTALLATION HOW TO REMOVE AND INSTALL THE • With both hands, grasp the sides of the door and pull it up to separate it from the rails. FREEZER DRAWER IMPORTANT: To avoid possible injury or product or property damage, you will need two people to perform the following instructions.
  • Page 14 All manuals and user guides at all-guides.com REFRIGERATOR INSTALLATION HOW TO REMOVE AND INSTALL THE • Make sure you have the correct rail cover for each side. FREEZER DRAWER Right Rail Cover 2. Installing Freezer Drawer • Fully extend the rails by grasping the center bar with Left both hands and pulling straight out.

  • Page 15: Leveling And Door Alignment

    All manuals and user guides at all-guides.com REFRIGERATOR INSTALLATION LEVELING AND DOOR ALIGNMENT 3. Open both doors again and check to make sure that they close easily. If not, tilt the refrigerator slightly more Leveling to the rear by turning both leveling legs clockwise. It may take several more turns, and you should turn both After installing, secure the stability of the product with the leveling legs the same amount.

  • Page 16: Using Your Refrigerator

    All manuals and user guides at all-guides.com USING YOUR REFRIGERATOR SETTING THE CONTROLS Door Alarm • When power is connected to the refrigerator, the door Temperature alarm is initially set to ON and the door alarm display will • Your refrigerator has a control pad on the dispenser that show the (ON).

  • Page 17: Airflow

    All manuals and user guides at all-guides.com USING YOUR REFRIGERATOR AIRFLOW 2. To remove the in-door ice bin, grip the front handle, slightly lift the lower part, and slowly pull out the bin as In order to ensure proper temperatures, air must flow shown.

  • Page 18: Adjusting Control Settings

    All manuals and user guides at all-guides.com USING YOUR REFRIGERATOR ADJUSTING CONTROL SETTINGS FOOD STORAGE GUIDE It is best to wait for 24 hours for the refrigerator to cool Wrap or store food in the refrigerator in airtight and down completely before making any adjustments to the moisture-proof material unless otherwise noted.

  • Page 19: Storing Frozen Food

    All manuals and user guides at all-guides.com USING YOUR REFRIGERATOR STORING FROZEN FOOD REFRIGERATOR SECTION NOTE: For further information about preparing food for WATER DISPENSER freezing or food storage times, check a freezer guide or a reliable cookbook. To remove the drip tray, pull up on the front and pull it out. Packaging Successful freezing depends on correct packaging.

  • Page 20: Refrigerator Shelves

    All manuals and user guides at all-guides.com USING YOUR REFRIGERATOR REFRIGERATOR SHELVES • To reinstall a shelf—Tilt the front of the shelf up and guide the shelf hooks into the slots at a desired height. The shelves in your refrigerator are adjustable to meet Then lower the front of the shelf so that the hooks drop your individual storage needs.

  • Page 21: Humidity Controlled Crisper

    All manuals and user guides at all-guides.com USING YOUR REFRIGERATOR HUMIDITY CONTROLLED CRISPER GLIDE‘N’SERVE The crispers provide fresher-tasting fruit and vegetables The Glide‘N’Serve provides storage space with a variable by letting you easily control humidity inside the drawer. temperature control that keeps the compartment colder than the refrigerator temperature.

  • Page 22: Modular Door Bin

    All manuals and user guides at all-guides.com USING YOUR REFRIGERATOR MODULAR DOOR BIN FREEZER SECTION The door bins are removable for easy cleaning and EXTRA ICE BIN adjusting. 1. To remove the ice bin from the upper drawer, pull out the 1.

  • Page 23: Durabase

    All manuals and user guides at all-guides.com USING YOUR REFRIGERATOR DURABASE PULLOUT DRAWER 1. To remove the Durabase, push it to the back as much To remove the drawer, push in the tabs on both sides as possible. Tilt up the front of the Durabase and pull of the drawer and lift up on the front and pull it straight straight out.

  • Page 24: Filter

    All manuals and user guides at all-guides.com FILTER REPLACING THE WATER FILTER 2. Replace with a new cartridge. Take the new cartridge out of its packaging and Replace the water filter when the Filter Reset indicator remove protective cover from the o-rings. light turns on, or when your water dispenser or icemaker performance decreases noticeably.
  • Page 25 All manuals and user guides at all-guides.com FILTER Performance Data Sheet For Model 5231JA2006A-S Using Replacement Cartridge 5231JA2006A This system has been tested according to NSF/ANSI Standard 42 for the reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system as specified in NSF/ANSI Standard 42.

  • Page 26: Care And Cleaning

    All manuals and user guides at all-guides.com CARE AND CLEANING INSIDE WALLS (allow freezer to warm up so w w WARNING the cloth will not stick) To help remove odors, you can wash the inside of the refrigerator with a mixture of baking soda and warm water. Mix 2 tablespoons baking soda to 1 quart of water (26 g soda to 1 liter water.) Be sure the baking soda is completely dissolved so it does not scratch the surfaces of...

  • Page 27: Light Bulb Replacement

    All manuals and user guides at all-guides.com CARE AND CLEANING LIGHT BULB REPLACEMENT POWER INTERRUPTIONS 1. If the power will be out for 24 hours or less, keep w w WARNING all refrigerator doors closed to help foods stay cold and frozen. Electrical Shock Hazard 2.

  • Page 28: About The Automatic Icemaker

    All manuals and user guides at all-guides.com ABOUT THE AUTOMATIC ICEMAKER AUTOMATIC ICEMAKER w w WARNING The icemaker will produce 6 cubes per cycle— approximately 100 cubes in a 24-hour period, depending Personal Injury Hazard on freezer compartment temperature, room temperature, Avoid contact with the moving parts of the ejector number of door openings and other operating conditions.
  • Page 29 All manuals and user guides at all-guides.com ABOUT THE AUTOMATIC ICEMAKER WHEN YOU SHOULD SET THE ICEMAKER w w CAUTIONS POWER SWITCH TO OFF (O) • The first ice and water may include particles or odor from the water supply line or the water tank. •...

  • Page 30: Connecting The Water Line

    All manuals and user guides at all-guides.com CONNECTING THE WATER LINE BEFORE YOU BEGIN WHAT YOU WILL NEED This water line installation is not warranted by the • Copper Tubing, 1/4" outer refrigerator or icemaker manufacturer or retailer. Follow diameter to connect the refrigerator these instructions carefully to minimize the risk of to the water supply.
  • Page 31 All manuals and user guides at all-guides.com CONNECTING THE WATER LINE INSTALLATION INSTRUCTIONS 5. TIGHTEN THE PIPE CLAMP Tighten the clamp screws until the sealing washer Install the shutoff valve on the nearest frequently used begins to swell. drinking water line. NOTE: Do not overtighten or you may crush the tubing.
  • Page 32 All manuals and user guides at all-guides.com CONNECTING THE WATER LINE 8. FLUSH OUT THE TUBING 10. TURN THE WATER ON AT THE SHUTOFF VALVE Turn the main water supply on and flush out the tubing until the Tighten any connections that leak. water is clear.

  • Page 33: Troubleshooting Guide

    All manuals and user guides at all-guides.com TROUBLESHOOTING GUIDE UNDERSTANDING SOUNDS YOU MAY HEAR • A clicking noise may come from the electronic control switching the cooling system on and off. Your new refrigerator may make sounds that your old one did •...
  • Page 34 All manuals and user guides at all-guides.com TROUBLESHOOTING GUIDE VIBRATION OR RATTLING NOISE Check if… Then… The refrigerator is not resting solidly on Floor is weak or uneven or leveling legs need adjusting. the floor. See INSTALLATION section on page 8 and 15. LIGHTS DO NOT WORK Check if…...
  • Page 35 All manuals and user guides at all-guides.com TROUBLESHOOTING GUIDE DOORS WILL NOT CLOSE COMPLETELY Check if… Then… The refrigerator is not level. See LEVELING AND DOOR ALIGNMENT section on page 15. Food packages are blocking the door open. Rearrange food containers to clear door and door shelves. The ice bin, crisper cover, pans, shelves, door bins Push bins all the way in and put crisper cover, pans, shelves or baskets are out of position.
  • Page 36 All manuals and user guides at all-guides.com TROUBLESHOOTING GUIDE THE REFRIGERATOR SEEMS TO MAKE TOO MUCH NOISE Check if… Then… The sounds may be normal for your refrigerator. Refer to the UNDERSTANDING SOUNDS YOU MAY HEAR section on page 33. THE ICEMAKER IS NOT PRODUCING ICE OR NOT ENOUGH ICE Check if…...
  • Page 37 All manuals and user guides at all-guides.com TROUBLESHOOTING GUIDE NOT DISPENSING ICE Check if… Then… All the doors are not closed completely. Ice will not dispense if any of the refrigerator doors are left open. The dispenser display is locked. Press and hold the Lock ( ) for 3 seconds to unlock the control panel and dispenser.
  • Page 38 All manuals and user guides at all-guides.com TROUBLESHOOTING GUIDE NOT DISPENSING WATER Check if… Then… The dispenser panel is locked. Press and hold the Lock ( ) for 3 seconds to unlock the control panel and dispenser. New installation. Flush and fill the water system. Refrigerator or freezer doors are not closed Water will not dispense if any of the refrigerator doors are left properly.
  • Page 39 All manuals and user guides at all-guides.com TROUBLESHOOTING GUIDE TEMPERATURE IS TOO WARM OR THERE IS INTERIOR MOISTURE BUILDUP Check if… Then… The air vents are blocked. Cold air circulates from Locate air vents by using your hand to sense airflow and move the freezer to the fresh food section and back all packages that block vents and restrict airflow.

  • Page 40: Spanish Version
