Pentair ONGA VF150 Owner's Manual

Cast iron vortex submersible drainage pump
Hide thumbs Also See for ONGA VF150:

Advertisement

Table of Contents

OWNER'S
MANUAL
VF150
CAST IRON VORTEX SUBMERSIBLE
DRAINAGE PUMP
An earth leakage or residual current protection device
must be fitted to all installations.
Should the installer or owner be unfamiliar with the correct installation or operation of
this type of equipment, contact the distributor or manufacturer for the correct advice
before proceeding with the installation or operation of this product.
ONGA.COM.AU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONGA VF150 and is the answer not in the manual?

Questions and answers

Related Manuals for Pentair ONGA VF150

Summary of Contents for Pentair ONGA VF150

  • Page 1 OWNER’S MANUAL VF150 CAST IRON VORTEX SUBMERSIBLE DRAINAGE PUMP An earth leakage or residual current protection device must be fitted to all installations. Should the installer or owner be unfamiliar with the correct installation or operation of this type of equipment, contact the distributor or manufacturer for the correct advice before proceeding with the installation or operation of this product.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TECHNICAL INFORMATION Page Model VF150 Pump discharge connection 1 ¼” BSPF thread Technical Information ..................1 Supplied fitting 1”, 1¼” & 1½” hose tail Power supply 230V - 1Ph - 50Hz Warning ......................2 Voltage limits 207V - 253V (230V ± 10%) Maximum flow rate 150lpm Installation .....................

  • Page 3: Warning

    Preparation for installation Inspect your VF150 for shipping damage. Report any damage to your Pentair Water dealer. Securely connect a stainless steel wire cable or a rope to the handle of the pump ensuring VF150 is designed to be used with clear or grey water in a residential that the wire/cable exceeds the safe working load of 10kg.

  • Page 4: Operation

    OPERATION SERVICE & MAINTENANCE Connect the pump to a suitable power outlet. You should regularly inspect your Onga VF150 for any damage or deterioration due to either fair wear and tear or misuse. Operation check If the supply cord is damaged, it must be replaced by the manufacturer, its service agent Ensure that the pump is completely submerged.

  • Page 5: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING SYMPTOM Cause Remedy SYMPTOM Cause Remedy Float switch isn’t in the ‘ON’ Float switch is trapped in Ensure that the float switch can Pump will not position. the “UP” position. operate freely. stop even Wait until there is more water in the pit to start the pump.

  • Page 6: Warranty Terms & Conditions

    WARRANTY TERMS & CONDITIONS WARRANTY TERMS & CONDITIONS 10. Service Calls Pentair Australia Pty Ltd ACN 004 856 204 and its related 6. What the warranty does not cover ii. Any infield issues determined not to be covered by this warranty will result in all associated costs for the entities (“Pentair”) warrants that, subject to the terms...
  • Page 7 Information contained here-in remains the property of Pentair Australia Pty Ltd. Any reproduction,display, publication, modification or distribution is strictly prohibited without the prior written permission of Pentair Australia Pty Ltd. Disclaimer: Pentair reserves the right to change product specifications and products details.
