INSTRUCTIONS–PARTS LIST
Portable Hydra-Spray
Supply Pumps
Model 224-623, Series A
Basic Sprayer, with 20:1 Ratio King
1800 psi (124 bar) Maximum Fluid Working Pressure
90 psi (6.3 bar) Maximum Air Input Pressure
Model 224-621, Series A
Basic Sprayer, with 30:1 Ratio Bulldog
Severe-Duty* Pump
3000 psi (210 bar) Maximum Fluid Working Pressure
100 psi (7 bar) Maximum Air Input Pressure
Model 231-154
Same as 224-621 except includes hose, gun,
and RAC
IV DripLess
Model 224-622, Series A
Basic Sprayer, with 45:1 Ratio King
Severe-Duty* Pump
4050 psi (280 bar) Maximum Fluid
Working Pressure
90 psi (6.3 bar) Maximum Air Input Pressure
Model 231-153
Same as 224-622 except includes hose, gun,
and RAC
IV DripLess
*
Severe-Duty Displacement Pumps have an
abrasion and corrosion resistant displacement
rod and sleeve. Refer to Technical Data in the
separate pump or displacement pump manual
for "Wetted Parts" information.
