Hunter 23920 Parts Manual

Hardware
(Drawn to Scale)
x 2
x 4
x 2
x 3
x 4
x 1
x 11
x 16
x 16
Balancing
x 1 x 3
Kit
x 3
Wire
x 4
Connector
3" Wood Screw
Flat Washer
Hanger
Bracket
Assembly
1.5" Wood Screw
Locking Screw
Canopy Screw
Set Screw
Screw, Blade
Iron Armature
Screw, Blade Blade
Assembly Assembly
Blade
Grommet
Screw, Switch
Housing Assembly
Switch
Housing
Screw,
Assembly
Machine, 6-32
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
R
SINCE 1886
Using this Parts Guide, make sure all
parts are included in the box.
If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model #

Parts List

Asm. Dwg. #
Finish
Item Name Qnty
* Hanging System Kit
Ceiling Plate
Canopy
Canopy Trim Ring
Hanger Ball / Downrod Assembly
Setscrew
Canopy Screw
Wood Screw
Flat Washer
Mounting Isolator
* Locking Screw
Blade Iron Set 1
Blade Set 1
Light Kit Assembly 1
Screw, Blade Iron Armature 11
Hardware Kit 1
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Screw, Switch Housing Assembly
Balancing Kit 1
Pull Chain Pendant 2
Pull Chain 1
Bottom Cap 1
Finial 1
Globe/Shade 1
Hunter Fan Company • 2500 Frisco Avenue • Memphis, TN 38114 • www.hunterfan.com •
23920
97757-01
Tuscan Gold
Part #
96970-81
97759-05
75480-08
97760-02
63755-05
97757-00-860
07570-01
74393-08
63756-10
77008-01
65956-01
87922-01
98000-01-812 08-16-2007 • 2007
©
