78-3694-250
8/18
Lionel
Trolley
Ready-to-Run Set
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Trolley Ready-to-Run and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lionel Trolley Ready-to-Run

Summary of Contents for Lionel Trolley Ready-to-Run

  • Page 1 78-3694-250 8/18 Lionel Trolley Ready-to-Run Set Owner's Manual...
  • Page 2 Thank You! elcome to the world of Lionel trains! Your new trolley set comes with everything you need to add some excitement to your current layout or the perfect item to include with your Christmas home decor. Use this Owner’s Manual to learn how to set up, operate, and maintain your trolley set for years of reliable operation.

  • Page 3: Table Of Contents

    Activating the announcements Operating your trolley set Running your trolley set Safety information Operating your wall-pack power supply safely Wall Pack Power Supply Trolley maintenance Lubricating the gears Replacing the headlight and interior lamp Troubleshooting Tips Lionel Limited Warranty Policy & Service...

  • Page 4: Getting Ready To Run Your Trolley

    Getting ready to run your trolley Building your Lionel layout our set comes with four 10" FasTrack straights, one FasTrack Terminal section, one 15" FasTrack Trolley Announcement section and two earthen bumpers. Figure 1 shows the included layout that you can build with these track sections. You may choose to add more FasTrack track sections to create an endless number of exciting track arrangements for more fun, action, and variety.

  • Page 5: Recording Announcements

    Getting ready to run your trolley Recording announcements our Special Trolley Announcement Track has the ability to record 3 unique user-record- able announcements. 1. To begin recording, hold down button and release once you hear a beep. 2. The LED light will illuminate and you can begin recording. 3.

  • Page 6: Activating The Announcements

    Getting ready to run your trolley Activating the announcements our Trolley Announcement track will play the announcements in sequence from Button 1 to Button 3. Button 1 Button 2 Button 3 Figure 4. Announcement track sequence buttons The trolley will stop on the track section and it will play the 1st announcement. Once the announcement has completed playback, the trolley will start moving again (If you have addi- tional Trolley Announcement Track pieces installed on your layout, the Trolley will stop at the next Announcement Track section).

  • Page 7: Operating Your Trolley Set Running Your Trolley Set

    Operating your trolley set Running your trolley set With track power unplugged, place your trolley set on the track. Plug in your wall-pack power supply to your trolley control box. Then plug in your trolley control box to the FasTrack terminal section.

  • Page 8: Safety Information

    Safety information Operating your wall-pack power supply safely our Lionel wall-pack power supply is listed by Underwriter’s Laboratory Inc. and has been carefully designed to ensure peak performance. When using electrical products, basic safety precautions should be maintained. Be sure to observe the following guidelines: •...

  • Page 9: Wall Pack Power Supply

    Safety information Wall-pack power supply CAUTION-ELECTRIC TOY Not recommended for children under 14 years of age. As with all electric products,precautions should be observed during handling and use to prevet electric shock. MODEL: S030A1202000U INPUT: 100-240V~50/60Hz OUTPUT: 12V – 2000mA Keep these instrutions for futher reference.

  • Page 10: Trolley Maintenance

    Lionel oil sparingly Figure 7. Lubrication points Replacing the headlight and interior lamp our trolley is equipped with LEDs that are designed for longer life. Please contact your nearest Lionel Service Center or Lionel Customer Service if they need replacing.

  • Page 11: Troubleshooting Tips

    Trolley maintenance Troubleshooting Tips Problem: The trolley activates the announcement but it does not stop on the track. Resolution: Reduce the speed of the trolley. Problem: The Trolley stops on the announcement track and the announce- ment plays but the trolley does not move. Resolution: Turn the trolley around.

  • Page 12: Lionel Limited Warranty Policy & Service

    Lionel LLC or any Lionel Authorized Service Station MUST be accompanied by the original receipt for purchase (or copy) from an Authorized Lionel Retailer*, will at the discretion of Lionel LLC, be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a suitable replacement is not available, Lionel will offer to replace the product with a comparable model (determined by Lionel LLC), if available.
