Apr.2005

TABLE OF CONTENTS

SPECIFICATIONS............................................................. 2
LOCATION OF CONTROLS .......................................... 4
LOCATION OF CONTROLS PARTS LIST ................... 5
EXPLODED VIEW ............................................................ 6
EXPLODED VIEW PARTS LIST ..................................... 7
WIRING DIAGRAM......................................................... 8
PARTS LIST........................................................................ 9
CHECKING THE VERSION NUMBER....................... 16
USERS DATA SAVE AND LOAD................................ 16
FACTORY RESET INSTRUCTIONS ............................ 17
TEST MODE..................................................................... 19
BLOCK DIAGRAM......................................................... 24
CIRCUIT BOARD(MAIN ) ............................................ 26
CIRCUIT DIAGRAM(MAIN 1/9) ............................... 28
Copyright © 2005 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission
of ROLAND CORPORATION.
CIRCUIT DIAGRAM(MAIN 2/9) ................................ 30
CIRCUIT DIAGRAM(MAIN 3/9) ............................... 32
CIRCUIT DIAGRAM(MAIN 4/9) ............................... 34
CIRCUIT DIAGRAM(MAIN 5/9) ............................... 36
CIRCUIT DIAGRAM(MAIN 6/9) ............................... 38
CIRCUIT DIAGRAM(MAIN 7/9) ............................... 40
CIRCUIT DIAGRAM(MAIN 8/9) ............................... 42
CIRCUIT DIAGRAM(MAIN 9/9) ............................... 44
CIRCUIT BOARD(PANEL) .......................................... 46
CIRCUIT DIAGRAM(PANEL) .................................... 48
CIRCUIT BOARD(JACK)............................................... 50
CIRCUIT DIAGRAM(JACK 1/3).................................. 52
CIRCUIT DIAGRAM(JACK 2/3).................................. 54
CIRCUIT DIAGRAM(JACK 3/3).................................. 56
ERROR MESSAGES........................................................ 58
17058329E0
SERVICE NOTES
Issued by RJA
Printed in Japan (0500) (AS)
