Table of Contents

Advertisement

Quick Links

Feb.2004

TABLE OF CONTENTS

CAUTIONARY NOTES ...................................................2
SPECIFICATIONS.............................................................3
LOCATION OF CONTROLS ..........................................4
LOCATION OF CONTROLS PARTS LIST ...................5
EXPLODED VIEW ............................................................6
EXPLODED VIEW PARTS LIST .....................................7
WIRING DIAGRAM.........................................................8
PARTS LIST........................................................................9
CHECKING THE VERSION NUMBER.......................17
CARD ................................................................................17
USERS DATA SAVE AND LOAD................................17
TEST MODE.....................................................................19
RESTORING THE FACTORY SETTINGS...................23
Revise Information
Oct 14, 2008 (p. 2)
(p. 17, p. 19, p. 23) Important notes on different program versions added
(p. 24)
Copyright © 2004 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission
of ROLAND CORPORATION.
BLOCK DIAGRAM.........................................................27
CIRCUIT BOARD (MAIN) ............................................30
CIRCUIT DIAGRAM (MAIN) ......................................34
VOLUME) ........................................................................52
CIRCUIT DIAGRAM (PANEL-U) ...............................56
CIRCUIT DIAGRAM (PANEL-L) ................................58
CIRCUIT DIAGRAM (MASTER) .................................60
CIRCUIT DIAGRAM (VOLUME) ................................62
CIRCUIT DIAGRAM (COAXIAL) ...............................68
CIRCUIT DIAGRAM (TRIG) ........................................70
CIRCUIT DIAGRAM (LCD CN) ..................................76
ERROR MESSAGES ........................................................77
CAUTIONARY NOTES added
Process of Updating the TD-20 corrected, with partial deletions
17058228E0
SERVICE NOTES
Issued by RJA
Printed in Japan (0500) (TP)
TD-20
