CONNECT YOUR PC FOR INITIAL SETUP

• Initial setup must be done from a PC connected to the appliance's
management interface via the included Ethernet cable. The management
interface is marked as MGMT on the appliance front panel.
Windows 8 & 10 configuration:
1. Right-click a network adapter to
assign an IP address and click
Properties.
2.
Select Internet Protocol Version 4
(TCP/IPv4) and click the
Properties button.
3.
In the IP address field,
enter 192.168.1.2.
4.
In the Subnet mask field,
enter 255.255.255.0.
5. Leave the Default gateway and
DNS settings fields empty.
6. Click OK and close the dialog boxes.
After completing the initial connection, the First Time Configuration Wizard
guides you through the process of configuring the appliance.
Figure 1
Internet Protocol (TCP/IP) Properties
