- Page 1 World Class Design | World Class Function | 30 Years Expertise in Industrial Motor Control ENCLOSED DC DRIVE 370E / 400E / 800E / 1200E 400ER / 800ER / 1200ER 1 11 Product Manual HG105275EN00 Issue 1 (04/2022)
- Page 2 Please read this information before installing or using the product. Install, use and maintain this product following the procedures provided. The manual(s) cannot provide all details, variations and contingencies required for your installation, operation and maintenance of this product or the apparatus with this product installed.
- Page 3 WARNING! Only qualifi ed personnel must install, operate and maintain this equipment. A qualifi ed person is someone technically competent and familiar with all safety information, established safety practices, installation, operation, maintenance and the hazards involved with this equipment and any associated machinery. Hazards This equipment can endanger life through rotating machinery and high voltages.
- Page 4 Weight Consideration should be given to the weight of our heavier products when handling. Weight Consideration should be given to the weight of our heavier products when handling. Risk assessment Under fault conditions or conditions not intended: the motor speed may be incorrect; the Risk assessment motor speed may be excessive;...
-
Page 5: Table Of Contents
Contents 1 Introduction 1 Introduction Enclosure controls 2 Mechanical dimensions 2 Mechanical dimensions 3 Guide for systems used in the EU 3 Guide for systems used in the EU 4 Multiple drives 4 Multiple drives 5 Requirements for EMC compliance 5 Requirements for EMC compliance 6 Installation 6 Installation... -
Page 7: Introduction
1 Introduction Introduction APPLICATION AREA: Industrial (non-consumer) "Motor speed control utilising DC Motors". The enclosure contains a Sprint-Electric 370, 400, 800 or 1200 DC drive. The drive is a non- isolated DC drive for controlling the speed of small brushed shunt wound or permanent magnet DC motors. -
Page 8: Mechanical Dimensions
Backplate mounting details: 4 off holes for M5 fixings . Heatsink: The backplate acts as the heatsink for the all-aluminium construction of the IP22 rated enclosure. SPRINT ELECTRIC LTD. does not Health and Safety at Work accept any liability whatsoever for Devices constitute a safety hazard. -
Page 9: Guide For Systems Used In The Eu
3 Guide for systems used in the EU Guide for systems used in the EU Special consideration must be given to installations in member states of the European Union regarding noise suppression and immunity. According to IEC 1800-3 (EN61800-3) the drive units are classified as complex components only for professional assemblers, with no CE marking for EMC. -
Page 10: Requirements For Emc Compliance
5 Requirements for EMC compliance Requirements for EMC compliance • Keep parallel runs of power and control cables at least 0.3 metres apart. Cross-overs must be at right angles. • Keep sensitive components at least 0.3 metres from the drive and power supply cables. •... -
Page 11: Installation
6 Installation Installation SUPPRESSION: The drives have excellent noise immunity. However, installations involving electrical welding or RF induction WARNING! heating may require additional filters on the line and armature terminals. Contactor coils ELECTRIC SHOCK HAZARD and sparking contacts may also require Disconnect the mains supply suppression. -
Page 12: Enclosure Terminals
6.3 Enclosure terminals 6.3.1 370E 370E Enclosure Drive 1 2 3 4 5 6 A+ A- F- F+ N L speed earth fuse ac supply tacho motor (optional) to switch Connection Terminal Common. 0 V (zero). Internal 12K pull-up resistor to +10 V. - Page 13 6.3.2 400E / 800E / 1200E 400/800/1200E Enclosure 66 65 64 63 62 61 56 55 54 53 52 51 Drive 1 2 3 4 5 6 7 8 9 10 11 12 13 speed earth fuse ac supply motor tacho to switch (optional)
- Page 14 6.3.3 400ER / 800ER / 1200ER 400/800/1200ER units Enclosure STOP 66 65 64 63 62 61 56 55 54 53 52 51 28 27 26 25 24 23 22 21 Reversing Unit Drive 1 2 3 4 5 6 7 8 9 10 11 12 13 31 32 33 34 35 36 37 38 speed earth...
-
Page 15: Fusing
The enclosure contains an integral high-speed fuse mounted in a fuse holder on the drive assembly to protect the drive unit only: Internal fuses for drive units in models 370E, 400E, 400ER 6.3 A fuse, 5 x 20 mm, Part number CH0036A3... - Page 16 We may, at our discretion, raise a charge for any faults without notifi cation. repaired that fall outside the warranty cover. www.sprint-electric.com Sprint Electric Limited, Peregrine House, Ford Lane, Ford, Arundel BN18 0DF, U.K. Tel: +44 (0)1243 558080 Fax:+44 (0)1243 558099 Email: info@sprint-electric.com...
