Figure 10. Functioning of DoorSwitch Input Wired to Supervisory Input

Wiring Motion Sensors/Exit Push Buttons

You may wire up to eight of the 32 supervisory inputs to motion sensors
or exit buttons. You wire them the same way you wire DoorSwitch in-
puts, only the motion sensor requires an external power supply of 12
VDC or 24
wire you may use is 500 ft of #18 gauge wire (152 m of 1.0 mm
or 200 ft of #22 gauge wire (60 m of 0.35 mm
24 Andover Controls Corporation
Technical Manuals Online! - http://www.tech-man.com
Normally Open DoorSwitch
Access
Controller
Access
Controller
±
VDC (UL listed under APHV). The maximum length
2
firealarmresources.com
Ω
10 K
Normally Open DoorSwitch
Ω
10 K
Detects
Door Open
2
Hardware Installation
Door Closed
(Normal)
±
2
wire)
wire).
2
