IPS Detect

2 Prescribed Operation of IPS Detect

The IPS Detect module is a remote sensor that is easily attached to the pump.
The sensor is an ideal solution for vibration velocity measurement in accordance with
DIN/ISO 10816, 5199, 9905. The unit also monitors the condition of the pump at
frequencies in excess of those cited within DIN/ISO10816 (sometimes known as noise) in
order to predict long(er) term failure through process upset that can lead to vibration and
consequent failure.
Monitoring of these parameters allows the user to optimise Life Cycle Cost by controlling
the effects caused by bearing failure, imbalance, misalignment, detrimental pipe-work
forces, and cavitation, etc.
Simply put, the sensing module compares actual running values with a pre-defined
threshold in order to notify the user about any alarming conditions. There are two ways to
get this information. Firstly, there is an LED display on the module with a traditional Green,
Yellow, and Red lamp arrangement. Secondly, the 4-20mA signal can be connected to
site-standard control modules.
With the same interface, digital communication can be achieved through an FSK-Modem
(FSK STERLING link) for further information and calibration (HART
can be used). A software tool is also available for use with a WINDOWS
Features:
Output of vibration velocity (RMS 10Hz 1kHz; 0
10816, 5199, 9905
Condition monitoring up to 5.6 kHz (normal / unacceptable operating mode)
4 ... 20 mA interface
Installation up to 160 °C surface temperature by use of cooling elements
LED display green, yellow and red
Digital communication through FSK* modem (HART
information or the professional software IPS Vibrosoft
EDD driver for Siemens SIMATIC PDM and Emerson AMS
DTM driver for FDT frame applications
Integrated error memory
Simple mounting on the pump
Requires no experience of vibration analysis technology
II 2G Ex ia IIC T4 Gb
IECEx Ex ia IIC T4 Gb
* FSK Frequency Shift Keying
OIM_FLS_IPS Detect_EN_14
Page 4 of 35
Subject to technical changes!
®
compatible modems
®
20 mm/s ) according to DIN/ISO
®
compatible) for additional
FLOWSERVE
operated PC.
