5.3 Monitoring operation

You can simply check the pump operation by taking a quick glance at the pump and
viewing the LED display.
Online detection is possible with a 4-20mA interface directly connected to conventional
control equipment.

5.3.1 Vibration velocity

LED
Display
Normal operation
failure
warning
normal
4-20mA Interface
Measurement range
Vibration velocity 0...10 mm/s
Vibration velocity 0...20 mm/s
CM-mode
[CM = Condition Monitoring]

5.3.2 Condition monitoring

LED
Display
Normal operation
( FALSE)
failure
warning
normal
4-20mA Interface
Condition monitoring
FALSE
TRUE
OIM_FLS_IPS Detect_EN_14
Page 19 of 35
Warning
failure
warning
normal
Interface display Calculation
10...20 mA
10...20 mA
9,10,11 and
12 mA
Condition monitoring
(TRUE)
failure (flashing)
warning
normal
Interface display
Vibration velocity (see topic. 5.3.1)
9 mA
Subject to technical changes!
Failure
failure
warning
normal
v
[mm/s] = i[mA] - 10
eff
v
[mm/s] = 2 * i[mA]
eff
9 mA
(flashing)
CM-TRUE
10 mA
normal
11 mA
warning
12 mA
failure
