Jura Z6 Disassembling Manual
  1. Manuals
  2. Brands
  3. Jura Manuals
  4. Coffee Maker
  5. Z6
  6. Disassembling manual

Jura Z6 Disassembling Manual

Hide thumbs Also See for Z6:
Table of Contents

Advertisement

Quick Links

Elektroapparate AG
Language
1
Disassembling of single components: ......................................................................................................................... 2
2
View machine side, Left: ........................................................................................................................................... 10
3
View machine side, Right: ......................................................................................................................................... 11
4
View back of the machine: ........................................................................................................................................ 12
5
View top of machine: ................................................................................................................................................. 13
6
View of the front: ...................................................................................................................................................... 14
7
Fluid system Z6 OT TFT: ............................................................................................................................................ 15
8
Block schematic: ........................................................................................................................................................ 16
8.1
Wiring: ......................................................................................................................................................................... 16
8.2
Overview 1: .................................................................................................................................................................. 17
8.3
Display: ........................................................................................................................................................................ 18
8.4
Logic:........................................................................................................................................................................... 19
8.5
Power: ......................................................................................................................................................................... 20
Revision:
A:
Author: Patrik Studer
Date:
Rev. A:
30.04.2015
Disassembling manual
EN
Checked:
Rev. B:
Rev. C:
Z6 OT TFT

Table of contents

:
Approved:
Docu.-name:
L:\Geräte\Linie_Z_Neu\Z6_OT_TFT\Schulungsunterlagen\E\
Demontageanleitung_Z6_EN.docx
Rev. D:
Rev. E:
Technical Support
Demontageanleitung_Z6_EN.docx
Rev. F:
Page 1/20

Advertisement

Table of Contents
loading

Related Manuals for Jura Z6

Summary of Contents for Jura Z6

  • Page 1: Table Of Contents

    View machine side, Right: ............................11 View back of the machine: ............................12 View top of machine: ..............................13 View of the front: ..............................14 Fluid system Z6 OT TFT: ............................15 Block schematic: ................................ 16 Wiring: ..................................16 Overview 1: .................................. 17 Display: ..................................

  • Page 2: Disassembling Of Single Components

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language Disassembling of single components: Remove water tank, tray, aroma preservation cover, beans  1. Front view: 2. Unscrew and remove finger protection with a slot screw driver 3. View: Finger protection removed 4.
  • Page 3 Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 5. Unscrew 4x Oval-screws 6. Remove service cover 2 towards you 7. Unscrew 2x TORX 10 8. Remove coffee powder chute Author: Patrik Studer Checked: Approved: Docu.-name: Demontageanleitung_Z6_EN.docx L:\Geräte\Linie_Z_Neu\Z6_OT_TFT\Schulungsunterlagen\E\ Demontageanleitung_Z6_EN.docx Date: Rev.
  • Page 4 Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 9. Slide upper housing part towards you 10. Remove upper housing part 11. View: Upper housing part removed 12. Slide Left side case towards you Author: Patrik Studer Checked: Approved: Docu.-name:...
  • Page 5 Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 13. Remove 2x cable (capacity sensor/LED) 14. Slide Right side case towards you 15. Right side case removed 16. Remove brewing unit (BU): Unscrew 2x TORX 15  Unscrew 2x TORX 10 ...
  • Page 6 Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 17. Detach BU with VC (Vacuum Clean) 18. Detach hose 19. Remove thermoblock: 20. Detach Thermoblock towards you Unscrew INBUS 4  Unscrew TORX 10  21. View: Thermoblock cover removed 22.
  • Page 7 Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 23. View: From above 24. Remove coffee powder chute support: Unscrew 2x TORX 10  25. Remove coffee powder chute 2: 26. Remove grinder: Unscrew TORX 10 Unscrew 3x TORX 10 ...
  • Page 8 Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 29. Remove display: 30. View: Display removed Unscrew 2x TORX 10  31. Remove front cover Middle: 32. Remove front cover Left: Detach with screw driver Slide to the left ...
  • Page 9 Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 35. Remove front part towards you 36. Remove dual spout: Unscrew 4x TORX 10 at support  Unscrew 4x TORX 10 at slider  No picture 37. Remove Rotary Switch towards you: 38.

  • Page 10: View Machine Side, Left

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language View machine side, Left: Condenser BU Vacuum Clean Brewing unit CLARIS Smart filter module CLARIS Smart filter Antenna Author: Patrik Studer Checked: Approved: Docu.-name: Demontageanleitung_Z6_EN.docx L:\Geräte\Linie_Z_Neu\Z6_OT_TFT\Schulungsunterlagen\E\ Demontageanleitung_Z6_EN.docx Date: Rev. A: Rev.

  • Page 11: View Machine Side, Right

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language View machine side, Right: Multi-valve Thermoblock Gear-motor Micro-switch Tray detection Flowmeter Drain motor and reject- valve Pump with membrane controller and thermostat Thermo-fuse Thermo sensor Author: Patrik Studer Checked: Approved: Docu.-name:...

  • Page 12: View Back Of The Machine

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language View back of the machine: Service plug Combi-print Tray detector Transformer 230 V~ feeder Author: Patrik Studer Checked: Approved: Docu.-name: Demontageanleitung_Z6_EN.docx L:\Geräte\Linie_Z_Neu\Z6_OT_TFT\Schulungsunterlagen\E\ Demontageanleitung_Z6_EN.docx Date: Rev. A: Rev. B: Rev. C: Rev.

  • Page 13: View Top Of Machine

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language View top of machine: Micro-switch Coffee powder detection Display Consistency of grind adjuster Bean monitor Grinder Zero Energy Switch Rotary Switch Consistency of grind in middle position Author: Patrik Studer...

  • Page 14: View Of The Front

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language View of the front: Magnet in spout cover REED contact integrated Spout cover detection Dual spout Micro-switch Tray detection Water tank illumination Author: Patrik Studer Checked: Approved: Docu.-name: Demontageanleitung_Z6_EN.docx L:\Geräte\Linie_Z_Neu\Z6_OT_TFT\Schulungsunterlagen\E\ Demontageanleitung_Z6_EN.docx...

  • Page 15: Fluid System Z6 Ot Tft

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language Fluid system Z6 OT TFT: Text Komponent / Component / Composant Heisswasser/Hot water/Eau chaude a) Wassertank / Water tank / Réservoir d’eau TB entleeren/discharge/décharger b) Flowmeter / Flowmeter / Débitmètre...

  • Page 16: Block Schematic

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language Block schematic: 8.1 Wiring: CL3A CL2E CL2A CL3B CL3C CL4E CL2D CL4F CL4G CL2G CL2C CL2H CL4C CL2J CL4D CL4B CL2I CL4A CL4I CL4H CL2K Author: Patrik Studer Checked: Approved: Docu.-name:...

  • Page 17: Overview 1

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 8.2 Overview 1: Author: Patrik Studer Checked: Approved: Docu.-name: Demontageanleitung_Z6_EN.docx L:\Geräte\Linie_Z_Neu\Z6_OT_TFT\Schulungsunterlagen\E\ Demontageanleitung_Z6_EN.docx Date: Rev. A: Rev. B: Rev. C: Rev. D: Rev. E: Rev. F: Page 17/20 30.04.2015...

  • Page 18: Display

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 8.3 Display: Author: Patrik Studer Checked: Approved: Docu.-name: Demontageanleitung_Z6_EN.docx L:\Geräte\Linie_Z_Neu\Z6_OT_TFT\Schulungsunterlagen\E\ Demontageanleitung_Z6_EN.docx Date: Rev. A: Rev. B: Rev. C: Rev. D: Rev. E: Rev. F: Page 18/20 30.04.2015...

  • Page 19: Logic

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 8.4 Logic: Author: Patrik Studer Checked: Approved: Docu.-name: Demontageanleitung_Z6_EN.docx L:\Geräte\Linie_Z_Neu\Z6_OT_TFT\Schulungsunterlagen\E\ Demontageanleitung_Z6_EN.docx Date: Rev. A: Rev. B: Rev. C: Rev. D: Rev. E: Rev. F: Page 19/20 30.04.2015...

  • Page 20: Power

    Disassembling manual Technical Support Elektroapparate AG Z6 OT TFT Language 8.5 Power: Author: Patrik Studer Checked: Approved: Docu.-name: Demontageanleitung_Z6_EN.docx L:\Geräte\Linie_Z_Neu\Z6_OT_TFT\Schulungsunterlagen\E\ Demontageanleitung_Z6_EN.docx Date: Rev. A: Rev. B: Rev. C: Rev. D: Rev. E: Rev. F: Page 20/20 30.04.2015...
