PLEASE REVIEW THIS ENTIRE MANUAL PRIOR TO INSTALLATION
Right side shower head installation shown as example
IMPORTANT!
DreamLine
reserves the right to alter, modify or redesign products at any time without prior notice for the
®
purpose of product improvement and customer experience. Please refer to the model's web page on
DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional
product details.
Do Not Return Product to the Store. Contact DreamLine® with any questions
ALLIANCE PRO ML Shower Door Manual Ver 1 4/2021
ALLIANCE PRO ML
D
I
OOR
NSTALLATION
I
NSTRUCTIONS
Available in Shower and Tub Height. Installation methods are identical.
SHOWER MODEL #s:
SDAM48W700
SDAM48W740
SDAM54W700
SDAM58W700
SDAM60W670
SDAM60W700
SDAM60W740
SDAM60W780
TUB MODEL #s:
TDAM60W620
Available in:
01 - Chrome
04 - Brushed Nickel
06 - Oil Rubbed Bronze
09 - Satin Black
