SL869-V3 EVK
User Guide
1VV0301306 Rev.0 2016-08-19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL869-V3 EVK and is the answer not in the manual?

Questions and answers

Related Manuals for Telit Wireless Solutions SL869-V3 EVK

Summary of Contents for Telit Wireless Solutions SL869-V3 EVK

  • Page 1 SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-19...
  • Page 2 SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 APPLICABILITY TABLE PRODUCT SL869-V3 Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 2 of 26 Mod. 0810 2011-07 Rev.2...
  • Page 3 SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Notice While reasonable efforts have been made to assure the accuracy of this document, Telit assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein.
  • Page 4 SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 Usage and Disclosure Restrictions License Agreements The software described in this document is the property of Telit and its licensors. It is furnished by express license agreement only and may be used only in accordance with the terms of such an agreement.

  • Page 5: Table Of Contents

    3.1. SL869-V3 EVK Contents ..................11 3.2. SL869-V3 Evaluation Board components............... 12 3.3. SL869-V3 EVK Board Component Identification ............ 13 3.4. SL869-V3 EVK Board schematic diagram.............. 14 3.5. SL869-V3 EVK Unit Connections ................16 4. Step-by-Step: First Time Running the SL869-V3 Evaluation Board ....... 17 4.1.
  • Page 6 SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 7.1. Commands ......................24 7.2. Messages Description .................... 24 7.3. Commands Description ..................25 8. Document History ....................... 26 Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 6 of 26...
  • Page 7 Figure 5-9 User Menu Command Manager ..................21 Figure 6-1TESEOIII X-Loader ......................22 Tables Table 3-1 SL869-V3 EVK Board Component Identification ............. 13 Table 7-1 Output messages ......................24 Table 7-2 Commands ........................25 Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.

  • Page 8: Introduction

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 Introduction 1.1. Purpose The purpose of this document is to provide information for using the SL869-V3 Evaluation Kit. 1.2. Contact Information, Support For general contact, technical support, to report documentation errors and to order manuals, contact Telit Technical Support Center (TTSC) at: TS-EMEA@telit.com...

  • Page 9: Text Conventions

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 1.3. Text Conventions Danger – This information MUST be followed or catastrophic equipment failure or bodily injury may occur. Caution or Warning – Alerts the user to important points about integrating the module, if these points are not followed, the module and end user equipment may fail or malfunction.

  • Page 10: Evaluation Kit Requirements

    .NET Framework 4.0 2.1. Installing the USB Drivers Before connecting the SL869-V3 EVK, install the necessary USB drivers 1. Double-click the USB driver executable and follow the onscreen directions for installation. Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved.

  • Page 11: Evaluation Kit Description

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 Evaluation Kit Description 3.1. SL869-V3 EVK Contents Cable GNSS Antenna SL869-V3 Eval Unit Flash Drive Figure 3-1 SL869-V3 Evaluation Kit Contents Description SL869-V3 Eval Unit: Evaluation Unit including the Telit SL869-V3 GNSS Antenna: An active antenna powered by the EVK.

  • Page 12: Sl869-V3 Evaluation Board Components

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 3.2. SL869-V3 Evaluation Board components DL101 DL102 PL104 PL107 PL102 PL101 TX LED 1PPS LED Vcc Supply Vbatt Supply UART-USB1 USB2 On/Off 1PPS SMA SL869 BOOT Vant Supply Antenna SMA SW201 SO102 PL108...

  • Page 13: Sl869-V3 Evk Board Component Identification

    Pins 2 & 3: Power LDO_Enable with module Pin 4 output SO 101 Antenna SMA Antenna: RF Input + Vant Table 3-1 SL869-V3 EVK Board Component Identification Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 13 of 26 Mod. 0810 2011-07 Rev.2...

  • Page 14: Sl869-V3 Evk Board Schematic Diagram

    1VV0301306 Rev.0 2016-08-199 3.4. SL869-V3 EVK Board schematic diagram Figure 3-3 SL869-V3 EVK Board schematic diagram - Page 1 / 2 Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 14 of 26 Mod. 0810 2011-07 Rev.2...
  • Page 15 SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 Figure 3-4 SL869-V3 EVK Board schematic diagram - Page 2 / 2 Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 15 of 26 Mod. 0810 2011-07 Rev.2...

  • Page 16: Sl869-V3 Evk Unit Connections

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 3.5. SL869-V3 EVK Unit Connections Figure 3-5 EVK Unit connections Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 16 of 26 Mod. 0810 2011-07 Rev.2...

  • Page 17: Step-By-Step: First Time Running The Sl869-V3 Evaluation Board

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 Step-by-Step: First Time Running the SL869-V3 Evaluation Board 4.1. Step-by-Step: First Time Connection 1. Before connecting the evaluation board, ensure that the USB drivers are installed. 2. Ensure that jumpers are installed on J2, J6, and J7.

  • Page 18: Telitview

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 TelitView Launch the TelitView application Figure 5-1TelitView application 5.1. Main Interface After launching TelitView, first notice the application’s main interface. Connecting to the EVK 5.1.1. Main Menu Bar Under the “Tools” option on the Main Menu Bar, select “Connect to GPS.” This will open the ‘Connect to GPS’...

  • Page 19: Connect To Gps' Window

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 5.1.3. ‘Connect to GPS’ Window Figure 5-4 Connect to GPS Window 1. Select the correct Communication Port 2. Select the correct baud rate (default – 9600) 5.2. TelitView Tabular View TelitView implements a tabular view. Switching between tabs displays different information parsed from the receiver.

  • Page 20: Front Panel Status

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 5.2.1. Front Panel Status The Front Panel Status Tab displays satellite information as well as position information. Figure 5-6 Front Panel Status Tab 5.2.2. Scatter Plot The Scatter Plot displays position points that are updated every second. The position points are compared to each other in an axis in meters.

  • Page 21: Nmea Monitor

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 5.2.3. NMEA Monitor The NMEA Monitor displays the NMEA output of the receiver. The user can also type in commands in the Transmit toolbar. TelitView automatically adds a checksum to the command being sent.

  • Page 22: Flashing Firmware With Teseoiii X-Loader

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 Flashing Firmware with TeseoIII X-Loader Note that X-loader requires use of the BOOT pin. If this pin is not available in a user’s design, you will need to run the FW Upgrade Tool (UPG).
  • Page 23 SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 5. Click on the Load button, then locate and select the software provided by Telit. 6. Verify selections as follows: a. “Target device” is SQI flash “Erase NVM” is selected c. “STA8090FG Only” is selected d.

  • Page 24: Communication Interface

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 Communication Interface The SL869-V3 offers several ways of communication between itself and the host processor. For simplicity in this document, the interface described in the examples is in UART mode. 7.1. Commands A command is a defined Data Packet sent from a host processor to the GPS-Baseband Controller.

  • Page 25: Commands Description

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 7.3. Commands Description The table below summarizes the set of commands for the SL869: Command ID Description $PSTMINITGPS Initialize GPS position and time $PSTMCLREPHS Clear all ephemeris data $PSTMDUMPEPHEMS Dump ephemeris data $PSTMEPH...

  • Page 26: Document History

    SL869-V3 EVK User Guide 1VV0301306 Rev.0 2016-08-199 Document History Revision Date Changes 2016-08-19 First Issue Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 26 of 26 Mod. 0810 2011-07 Rev.2...
