Telit Wireless Solutions GL865-DUAL V3 Hardware User's Manual
  1. Manuals
  2. Brands
  3. Telit Wireless Solutions Manuals
  4. Wireless modules
  5. GL865-DUAL V3
  6. Hardware user's manual

Telit Wireless Solutions GL865-DUAL V3 Hardware User's Manual

Hide thumbs Also See for GL865-DUAL V3:
Table of Contents

Advertisement

Quick Links

Download this manual
GL865-DUAL/QUAD V3 Hardware User
Guide
1vv0301018 Rev.11 – 2015-05-25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GL865-DUAL V3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telit Wireless Solutions GL865-DUAL V3

Summary of Contents for Telit Wireless Solutions GL865-DUAL V3

  • Page 1 GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05-25...
  • Page 2 GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- APPLICABILITY TABLE PRODUCT GL865-DUAL V3 GL865-QUAD V3 Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 2 of 79 Mod. 0805 2011-07 Rev.2...
  • Page 3 GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Notice While reasonable efforts have been made to assure the accuracy of this document, Telit assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein.
  • Page 4 GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- Usage and Disclosure Restrictions License Agreements The software described in this document is the property of Telit and its licensors. It is furnished by express license agreement only and may be used only in accordance with the terms of such an agreement.

  • Page 5: Table Of Contents

    GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- Contents Introduction ......................9 Scope ..........................9 1.1. Audience ........................9 1.2. Contact Information, Support ..................9 1.3. Document Organization ....................10 1.4. Text Conventions ......................11 1.5. Related Documents ....................... 11 1.6.
  • Page 6 GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- Transmission line design ....................33 7.2.1. Transmission line measurements ...................... 34 GSM Antenna - Installation Guidelines................36 7.3. Logic level specifications ..................37 Reset signal ........................38 8.1. Serial Ports ......................39 MODEM SERIAL PORT .....................
  • Page 7 14.2.2. Moisture sensibility ....................71 14.3. Conformity Assessment Issues ................72 15.1. GL865-DUAL V3 ...................... 74 15.2. GL865-QUAD V3 ...................... 75 Safety Recommendations ..................78 Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 7 of 79...
  • Page 8 GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- Document History ....................79 Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 8 of 79 Mod. 0805 2011-07 Rev.2...

  • Page 9: Introduction

    GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- Introduction 1.1. Scope The aim of this document is the description of some hardware solutions useful for developing a product with the Telit GL865-DUAL/QUAD V3 module. 1.2. Audience This document is intended for Telit customers, who are integrators, about to implement their applications using our GL865-DUAL/QUAD V3 modules.

  • Page 10: Document Organization

    GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- 1.4. Document Organization This document contains the following chapters: Chapter 1: “Introduction” provides a scope for this document, target audience, contact and support information, and text conventions. Chapter 2: “Overview” provides an overview of the document. Chapter 3: “GL865-DUAL/QUAD V3 Mechanical Dimensions”...

  • Page 11: Text Conventions

    GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- 1.5. Text Conventions Danger – This information MUST be followed or catastrophic equipment failure or bodily injury may occur. Caution or Warning – Alerts the user to important points about integrating the module, if these points are not followed, the module and end user equipment may fail or malfunction.

  • Page 12: Overview

    GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- Overview The aim of this document is the description of some hardware solutions useful for developing a product with the Telit GL865-DUAL/QUAD V3 module. In this document all the basic functions of a mobile phone will be taken into account; for each one of them a proper hardware solution will be suggested and eventually the wrong solutions and common errors to be avoided will be evidenced.

  • Page 13: Gl865-Dual/Quad V3 Mechanical Dimensions

    GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- GL865-DUAL/QUAD V3 Mechanical Dimensions The GL865-DUAL/QUAD V3 overall dimensions are: • Length: 24.4 mm • Width: 24.4 mm • Thickness: 2.6 mm • Weight 2.8 g Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 13 of 79 Mod.

  • Page 14: Gl865-Dual/Quad V3 Module Connections

    GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- GL865-DUAL/QUAD V3 module connections 4.1. PIN-OUT Signal Function Note Type Audio EAR- Earphone signal output, phase - Audio EAR+ Earphone signal output, phase + Audio MIC- Mic. signal input; phase- Audio MIC+ Mic.
  • Page 15 GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- Signal Function Note Type GPIO 80KΩ- GPIO01 Configurable GPIO GPIO_01 / DVI_WA0 CMOS 1.8V 110KΩ PD / Digital Audio Interface (WA0) GPIO02 I/O pin 18KΩ- GPIO_02 / JDR / / Jammer Detect Report CMOS 1.8V 25KΩ...
  • Page 16 GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- NOTE: If not used, almost all pins should be left disconnected. The only exceptions are the following pins: signal 38, 37 VBATT & VBATT_PA 32, 33, 35, 36, 46 AGND V_AUX / PWRMON RESET* TXD_AUX RXD_AUX...

  • Page 17: Pin Layout

    GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- 4.2. Pin Layout TOP VIEW NOTE: The pins defined as NC/RFU shall be considered RESERVED and must not be connected to any pin in the application. Reproduction forbidden without written authorization from Telit Communications S.p.A. - All Rights Reserved. Page 17 of 79 Mod.

  • Page 18: Hardware Commands

    GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- Hardware Commands 5.1. Auto-Turning ON the GL865-DUAL/QUAD V3 To Auto-turn on the GL865-DUAL/QUAD V3, the power supply must be applied on the power pins VBATT and VBATT_PA, after 1000 m-seconds, the V_AUX / PWRMON pin will be at the high logic level and the module can be considered fully operating.
  • Page 19 GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- NOTE: The power supply must be applied either at the same time on pins VBATT and VBATT_PA, or first applied on VBATT_PA and then on VBATT. The opposite sequence shall be avoided. The reverse procedure applies for powering down the module: first disconnect VBATT, then VBATT_PA, or both at once.

  • Page 20: Turning Off The Gl865-Dual/Quad V3

    GL865-DUAL/QUAD V3 Hardware User Guide 1vv0301018 Rev.11 – 2015-05- 5.2. Turning OFF the GL865-DUAL/QUAD V3 Turning off of the device can be done in two ways: • General turn OFF • Processor turn OFF General turn OFF – disconnect the power supply from the both power pins VBATT and VBATT_PA at the same time.
