2.4 Connection with Next board
J4 and J2 on terminal block are used to connect more amplifier board.
Connector Mark
J4
VDD
J2
GND
Notice:
It is allowed to connect more amplifier boards in series, but it would be better to limit that number to 4.
Remember to use AWG12-compliant cable or equivalent for series connection.
2.5 Mute Setting
To mute the output audio signal, connect "+5V" and "MUTE" of the terminal block with a piece of
lead. In normal use, "MUTE" shall be left unconnected.
Connector Mark
J6
MUTE
Notice:
When you select power supply for the board, the appropriate voltage is DC 10-36V. Never connect
"MUTE" on the terminal block to any power supply or any other voltage higher than 5V.
2.6 Gain Settings
The on-board 4-slide DIP switch, which is marked as "SW1", is used to set the gain of amplifier
board. 4 slides are marked as K1, K2, K3 and K4 respectively. K1 and K2 are used to set the gain of
channel 1 while K3 and K4 are used for channel 2. The following table lists the gain values on different
settings:
C
h
a
n
n
l e
1
S
e
t t
n i
g
K1
K2
ON
ON
OFF
ON
ON
OFF
OFF
OFF
Tips:
High: Portable MP3/CD player with built-in volume control.
Medium: General-purpose use
Low: Preamplifier with fairly high output signal
2.7 DC Offset
If it is not quite necessary, DO NOT trim the output offset by adjusting "R5" and"R26"-two
AA-AB013_Ver1.2_Page 6
Description
Positive (+) of DC 10-36V Power Supply to next board
Negative (GND) of DC 10-36V Power Supply to next board
Description
When "MUTE" is connected with "+5V", both amplifiers will
be muted and enter into idle mode. When connected to
ground or left disconnected, both amplifiers will resume to
regular operation.
C
h
a
n
n
l e
2
S
e
t t
n i
g
K3
K4
ON
ON
OFF
ON
ON
OFF
OFF
OFF
A
m
Gain
Power Gain (dB)
Level
Typical
High
24
Medium
30
Medium
30
Low
34
p
i f i l
r e
G
a
n i
Voltage Gain (V/V)
Typical
16
32
32
48
