Model: 3PT-45-PRO-4 (5303246)
(45 Gallon, 12 Volt, Bolt-Together, Professional 3 Point Sprayer w/4-Nozzle Boom)
Professional Grade Pump (2.2 GPM):
Ideal for Harsh Chemicals &
Oil Based Chemicals with Surfactants
Long Range 22" PRO SERIES Handgun
38' Horizontal Spray & 27' Vertical
Roundup® Ready
General Information
Thank you for purchasing this product. The purpose of this
manual is to assist you in operating and maintaining your
3-Point sprayer.
BEFORE RETURNING THIS PRODUCT
FOR ANY REASON, PLEASE CALL
1-800-831-0027
MONDAY-FRIDAY, 8:00 AM TO 5:00 PM CST
If you should have a question or experience a problem with
your Fimco Industries Product: Visit our website @
www.fimcoindustries.com or call the Toll free number above. Our
technical support representatives will be happy to help you.
In most cases a customer service rep. can resolve
the problem over the phone.
To obtain prompt, efficient service, always remember to give the
following information....
• Correct Part Description and/or part number
• Model number and Serial Number
Part descriptions and numbers can be obtained from the
illustrated parts list section(s) of this manual.
Retain a copy of your receipt for your unit, as it will be required
to validate any warranty service.
Warranted against manufacturer or workmanship defects from
date of purchase with copy of receipt:
Homeowner Usage: One Year.
Commercial Usage: 90 Days.
OWNER'S MANUAL
IMPORTANT:
Occasionally check your strainer screen to ensure it is
clean and clear of any debris. Use protective gear when
removing and cleaning the strainer.
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
[5195647
Category I
(01/22)]
Page 1
Advertisement
Related Manuals for Fimco PRO Series
Summary of Contents for Fimco PRO Series
- Page 1 Warranted against manufacturer or workmanship defects from date of purchase with copy of receipt: www.fimcoindustries.com 1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049 Homeowner Usage: One Year. Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440 Commercial Usage: 90 Days.
- Page 2 Pro Series Sprayer w/4-Nozzle Boom) Technical Specifications 45 Gal. Corrosion-Resistant Polyethylene Tank Pro Series 2.2 GPM - 100 PSI, 12V Pump 22” High Pressure Spray Gun w/25’ Hose (3/8” ID) 27 Ft. Vertical Throw, 38 Ft. Horizontal Throw ...
- Page 3 Contents of Sprayer Carton: Tank/Plumbing Pre-Assembly Owner’s Manual Multi-LID Boom Mounts 3-PT Welded Front Frame 3-PT Back Plate Bolt Together 3-PT Sides 4-Nozzle Boom Assembly Contents of Parts Bag (#5282441) Contents of Square Boom Parts Bag (#5282433) Contents of Bolt Bag (#5282434) Page 3...
- Page 4 Assembly Instructions: Step 1 Install the lower hitch pins into the bracket lift arm. Place these pins through the holes in the pin plates, slip the lock washers on and thread the nuts onto the pin. Tighten securely. Step 2 Bolt the frame together as shown.
- Page 5 Assembly Instructions: Step 4 Next, attach the center boom member of the 4-nozzle boom to the boom mounts, centering it on the unit, using the (2) U-Bolts and (4) 5/16”-18 Hex Whiz Nuts. Important: Make sure the outer boom members fold ‘backwards’.
- Page 6 IMPORTANT: Remove tank lid and be sure the tank is clean and free of any foreign material. Rinse tank out of any tank residue before filling with water to test. Testing the Sprayer NOTE: It is VERY important to test the sprayer with plain water before actual spraying is attempted. This will enable you to check the sprayer for leaks without the possibility of losing any expensive chemicals.
- Page 7 Drain and then refill half full, add the recommended amount of a good quality tank cleaner, such as FIMCO Tank Neutralizer and Cleaner. (If no tank cleaner is available, you may substitute dish soap for this step, about 1-2 oz.
- Page 8 Tank Care & Maintenance Warning: Do not use the tank as a container for fuel oils, kerosene, gasoline or any other petroleum distillate product. All polyolefins are softened and permeated by such products. In an enclosed area the vaporization of these materials from the outside surface of the tank could create a dangerous condition.
- Page 9 Model: 5151075 Available Replacement Parts (Replacement Pump: 5281325) DON’T Clean and rinse your pump after each use with Fimco Use to pump bleach. Tank Neutralizer. Use to pump petroleum products such as diesel fuel, Winterize your pump or sprayer by rinsing, draining gasoline or kerosene.
- Page 10 Exploded View: 3PT-45-PRO-4 (5303246) NOTE: Bolt frame together as shown, with the proper hardware. See Assembly Instructions earlier in this manual. Bypass Boom Hose Hose Intake Hose Spray Gun Detail Pump Assembly Detail Manifold Detail Strainer Detail Page 10...
- Page 11 Parts List: 3PT-45-PRO-4 (5303246) Page 11...
- Page 12 4-Nozzle Boom Assembly (5302290) (with 3/8” Hose, 1” Sq. Tubing & AIXR11002VP Tips) Opposite side has typical hardware & nozzle configuration. See Hinge Detail Clamp Bag of 4: 5277728 Hinge Detail Elbow 110° wide, tapered flat spray angle with air induction technology for better drift management. ...
- Page 13 Long Range Pro Series Spray Gun • No Drip Shut Off • Easy Pull Trigger Handle • Chemical Resistant Construction • 38’ Horizontal Throw & 27’ Vertical Throw To adjust the spray pattern, the nut needs to be adjusted (Ref. A). Spinning it off, towards the lever, will make a cone pattern and spinning it on, away from the lever, will make a stream.
- Page 14 WHAT REMEDIES ARE AVAILABLE UNDER THIS LIMITED WARRANTY. If the conditions set forth above are fulfilled and the Equipment or any part thereof is found to be defective, Fimco, Ind. shall, at its own cost, and at its option, either repair or replace the defective Equipment or part.
