- Page 1 InlIne mIxed-flow fan Primo USER'S MANUAL...
-
Page 2: Table Of Contents
Primo www.blaubergventilation.com.au CONTENTS Safety requirements ..................................3 Purpose ........................................ 5 Delivery set ......................................5 Designation key ....................................5 Technical data ....................................6 Mounting and set-up .................................. 7 Connection to power mains ..............................9 Technical maintenance ................................10 Troubleshooting ........................................11 Storage and transportation regulations .......................... 11 Manufacturer’s warranty ................................ -
Page 3: Safety Requirements
Primo www.blaubergventilation.com.au SAFETY REQUIREMENTS All user’s manual requirements as well as the provisions of all the applicable local and national construction, electrical, and technical norms and standards must be observed when installing and operating the unit. Disconnect the unit from the power supply prior to any connection, servicing, maintenance, and repair operations. - Page 4 Primo www.blaubergventilation.com.au CAUTION: In order to avoid a safety hazard due to inadvertent resetting of the thermal cut- out, this unit must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility. Precautions must be taken to avoid the back-flow of gases into the room from the open flue of gas or other fuel-burning appliances.
-
Page 5: Purpose
Primo www.blaubergventilation.com.au PURPOSE The product described herein is a mixed-flow inline fan for supply or extract ventilation of premises. The fan is designed for connection to ø 315, 355 and 400 mm air ducts. Transported air must not contain any flammable or explosive mixtures, evaporation of chemicals, sticky substances, fibrous materials, coarse dust, soot and oil particles or environments favourable for the formation of hazardous substances (toxic substances, dust, pathogenic germs). -
Page 6: Technical Data
The unit is rated as a class I electric appliance. The unit design is constantly being improved, thus some models may be slightly different from those described in this manual. Overall dimensions of the unit [mm] ød øD ød Dimensions [mm] Weight Model [kg] Primo 315 Primo 355 Primo 400 18.5... -
Page 7: Mounting And Set-Up
Primo www.blaubergventilation.com.au MOUNTING AND SET-UP READ THE USER'S MANUAL BEFORE INSTALLING THE UNIT. BEFORE MOUNTING, MAKE SURE THERE ARE NO VISIBLE DEFECTS ON THE UNIT, SUCH AS MECHANICAL DAMAGES, MISSING PARTS, IMPELLER JAMMING ETC. WHEN MOUNTING THE UNIT, IT IS NECESSARY TO PROVIDE PROTECTION AGAINST CONTACT WITH HAZARDOUS ZONES OF THE FAN BY INSTALLING AIR DUCTS OF THE NECESSARY LENGTHS AND PROTECTIVE GRILLES. - Page 8 Primo www.blaubergventilation.com.au SURFACE MOUNTING Fasten the fan to the surface using the screws with the dowels of appropriate size (not included in the delivery set). Make sure the fan is fastened securely. Connect the air ducts of the appropriate diameter to the fan (connections must be airtight). Air motion in the system must be in compliance with the direction of the arrow on the fan label.
-
Page 9: Connection To Power Mains
Primo www.blaubergventilation.com.au CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL. -
Page 10: Technical Maintenance
Primo www.blaubergventilation.com.au TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE PROTECTION Clean the product surfaces regularly (once in 6 months) from dust and dirt. Disconnect the fan from power mains prior to any maintenance operations. -
Page 11: Troubleshooting
Primo www.blaubergventilation.com.au TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line is connected correctly, No power supply. otherwise troubleshoot the connection error. The fan(s) do(es) not Disconnect the fan from power supply. Troubleshoot Jammed motor. get started. the motor jamming. Restart the fan. Disconnect the fan from power supply. -
Page 12: Manufacturer's Warranty
Primo www.blaubergventilation.com.au MANUFACTURER’S WARRANTY Blauberg Warranty: • This warranty is given by Blauberg Australasia Pty Ltd, with an office at Unit 5, 45A Eastern Creek Drive, Eastern Creek, New South Wales 2766, Australia. Phone 1300 475-504. • From the date of purchase, the original purchaser is entitled to free replacement parts, or a new unit for a period of 24 months years from the date of purchase. -
Page 13: Certificate Of Acceptance
Primo www.blaubergventilation.com.au CERTIFICATE OF ACCEPTANCE Unit Type Inline mixed-flow fan Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 14 Primo www.blaubergventilation.com.au...
- Page 15 Primo www.blaubergventilation.com.au...
- Page 16 www.blaubergventilation.com.au BlaubergAustralasia208EN-06...
